Manageable - 10 Gigabit Ethernet - 10GBase-X - 4 Layer Supported - Modular - 90 W Power Consumption - Optical Fiber - 1U - Rack-mountable - 3 Year Limited Warranty
MSRP$5,199.00
$2,840.07
Save 45%Special order — estimated OEM lead time 3–8 weeks. Order today and we expect to receive stock between Oct 29 and Dec 3, then process your delivery right after.
Genuine Quanta Computer, lnc through authorized distribution — NDAA §889 screened before checkout.
Country of origin is manufacturer-reported and can vary by production lot. Where TAA applies to your purchase, we verify the shipping unit's origin on request.
A Powerful Top-of-Rack Switch for Datacenters and Cloud Computing
The QuantaMesh T3024-P05 is a high performance and low latency layer 2/3/4 Ethernet switch with 24 1/10GbE SFP+ and 2 40GbE QSFP+ ports
located in a half-rack width and 1U height rack unit size. The 2 40GbE ports provide 80Gbps to aggregate bandwidth up to the core switch. Each 40 Gigabit Ethernet port can be independently configured as 40GbE or 4 x 10GbE for total 32 ports of 10GbE.
Simplicity
The QuantaMesh T3024-P05 can be managed through an industry standard command-line interface (CLI) which reduces training and operating costs. The QuantaMesh T3024-P05 also supports Simple Network Management Protocol (SNMP) both from standard MIB and private MIB for easy configuration, monitoring, and remote management for the network administrator. The Auto-Installation feature implemented in the QuantaMesh T3024-P05 helps centralized management to simplify deployment of a truly plug-and-play experience. With the evolution from IPv4 to IPv6, the QuantaMesh T3024-P05 is a IPv6 integrated management device.
High Availability
The QuantaMesh T3024-P05 is designed for high availability from both hardware and software perspective. The key features include:
• 1+1 hot-swappable power supplies
• 2+1 hot-swappable fans
• Spanning Tree with Guarding Features
• Up to 64 gropus of LACP with per group 32 member ports
• Multi-chassis Link Aggregation (MLAG)
• Up to 32 paths ECMP routing for load balancing and redundancy
• Virtual Router Redundancy Protocol (VRRP)
High-Performance L2/L3 access deployments
With the compact 1U form factor, high density 24 1/10G SFP+ and 2 40G QSFP+ ports in the front panel, front to back or back to front airflow design, the QuantaMesh T3024-P05 is ideal for top-of-rack deployments in high-performance, highly demanding datacenters. The 640 gigabits per second switching capacity and 476Mpps forwarding rate with low power consumption make the QuantaMesh T3024-P05 a powerful solution to aggregate high-performance servers in the datacenter.
Software Defined Network (SDN)
SDN has emerged as a new approach to support open, vendor-agnostic, and programmable networks. T3024-P05 is equipped with OpenFlow v1.3 features to fulfill the needs of modern data center applications.
Limited Warranty: 3 Year
| General Information | |
|---|---|
| Manufacturer | Quanta Computer, lnc |
| Manufacturer Part Number | 1P05BZZ0ST1 |
| Brand Name | QCT |
| Product Line | QuantaMesh |
| Product Series | T3000 |
| Product Model | T3024-P05 |
| Product Name | A Powerful Top-of-Rack Switch for Data Center and Cloud Computing |
| Product Type | Layer 3 Switch |
| Interfaces/Ports | |
| Modular | Yes |
| Stack Port | No |
| Port/Expansion Slot Details | 24 x 10 Gigabit Ethernet Expansion Slot, 2 x 40 Gigabit Ethernet Expansion Slot |
| Management & Protocols | |
| Manageable | Yes |
| Media & Performance | |
| Media Type Supported | Optical Fiber |
| Ethernet Technology | 10 Gigabit Ethernet, 40 Gigabit Ethernet |
| Network Technology | 10GBase-X, 40GBase-X |
| Network & Communication | |
| Layer Supported | 4 |
| Physical Characteristics | |
| Compatible Rack Unit | 1U |
| Form Factor | Rack-mountable |
| Height | 1.6" |
| Width | 8.7" |
| Depth | 16.6" |
| Weight (Approximate) | 7.05 lb |
| Power Description | |
| Power Source | Power Supply |
| Redundant Power Supply Supported | Yes |
| Power Consumption | 90 W |
| Warranty | |
| Limited Warranty | 3 Year |
| I/O Expansions | |
| Total Number of Expansion Slots | 26.0 |
| Expansion Slot Type | SFP+, QSFP+ |
| Shared SFP Slot | No |
| Number of SFP+ Slots | 24 |
| Miscellaneous | |
| Environmentally Friendly | Yes |
| Environmental Compliance | Waste Electrical and Electronic Equipment Directive (WEEE), Restriction of Hazardous Substances (RoHS) |
| Country of Origin | China |
