Genuine Quanta Computer, lnc through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.
SKU
1LY9UZZ000V
Category
Switches & Bridges
Overview
Datacenter networks is facing a major paradigm shift toward the disaggregation of software and hardware. This move, combined with the benefits of software-defined networking (SDN) allows network administrators respond quickly to changing business requirements at a lower capital cost as well as reducing the network operations complexity.
QuantaMesh BMS products offer higher performance, increased availability, and better serviceability to meet datacenter installation environment. QuantaMesh T3048-LY9 supports 48 100/1000/10GBase-T ports and 6 40G QSFP+ ports in a compact rack unit size. By levering the new generation merchant silicon chips, T3048-LY9 is a high performance high density Ethernet switch with an affordable price for the deployment of data center infrastructure. Moreover, the CPU board design of T3048-LY9 provides option for 3rd party software choose. Finally, with ONIE (Open Network Installation Environment) pre-loaded, it provides the flexibility and allows choice of network operating system supported by different software vendors. This provides agile installation process and faster response for the changing business demand.
Warranty
Limited Warranty: 3 Year
Highlights
10GBT
ONIE Pre-loaded
x86 CPU Board Support
ONL Ready
Cumulus Linux Ready
Specifications
General Information
Manufacturer
Quanta Computer, lnc
Manufacturer Part Number
1LY9UZZ000V
Brand Name
QCT
Product Line
QuantaMesh
Product Model
T3048-LY9
Product Name
A Powerful 10GBASE-T Top-of-Rack Switch for Data Center and Cloud Computing
Product Type
Ethernet Switch
Interfaces/Ports
Total Number of Network Ports
48
Modular
Yes
Stack Port
No
Port/Expansion Slot Details
48 x 10 Gigabit Ethernet Network, 6 x 40 Gigabit Ethernet Expansion Slot
Management & Protocols
Manageable
Yes
Media & Performance
Media Type Supported
Twisted Pair, Optical Fiber
Ethernet Technology
10 Gigabit Ethernet, 40 Gigabit Ethernet
Network Technology
10GBase-T, 40GBase-X
Network & Communication
Layer Supported
2
Physical Characteristics
Form Factor
Rack-mountable
Height
1.7"
Width
17.1"
Depth
20"
Weight (Approximate)
20.92 lb
Power Description
Power Source
Power Supply
Redundant Power Supply Supported
Yes
Power Consumption
330 W
Warranty
Limited Warranty
3 Year
I/O Expansions
Total Number of Expansion Slots
6.0
Expansion Slot Type
QSFP+
Shared SFP Slot
No
Miscellaneous
Environmentally Friendly
Yes
Environmental Compliance
Waste Electrical and Electronic Equipment Directive (WEEE), Restriction of Hazardous Substances (RoHS)
