48 Ports - Manageable - Gigabit Ethernet, 10 Gigabit Ethernet - 10/100/1000Base-T, 10GBase-X - 2 Layer Supported - Modular - 740 W PoE Budget - Optical Fiber, Twisted Pair - PoE Ports - Desktop - 1 Year Limited Warranty - TAA Compliant
MSRP$2,436.86
$1,844.14
Save 24%In stock: 3
Genuine Black Box through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.
The Gigabit Ethernet Managed Switches add high-speed ports while offering the management and security features your enterprise network needs. Provides 10/100/1000BASE-T UTP ports and 1G/10G SFP+ ports.
Fully Manageable
The switch is fully managed, supporting SNMP versions 1, 2c, and 3. The embedded RMON software agents support RMON groups 1 (history), 2 (statistics), 3 (alarms), and 9 (events).
The integral webserver enables web-based management via a web browser. This GUI interface enables switch configuration, system dashboard, maintenance, and monitoring.
The wide range of management and support features also includes dual image, port mirroring, LLDP, sFlow®, UPnP®, IPv6, SSH, RADIUS, DHCP Client/DHCPv6 Client, SNTP, cable diagnostics, ping, Syslog, and Telnet client with SSH security.
Support for VLAN and QoS
Support for up to four simultaneous VLANs enables you to segment traffic with port-based, 802.1Q tag-based, or MAC-based VLANs. VoIP traffic is automatically assigned to a voice-specific VLAN to maintain quality. 802.1p Layer 2 quality of service (QoS) enables prioritization of time-sensitive applications such as VoIP and video.
Secure
You get enterprise-class security features, too. 802.1X port-based network access control authenticates devices connecting to your network. The switch also supports SNMPv3 cryptographic security, SSH, and SSL. Plus, you can set up a guest VLAN that enables visitors to access the Internet without also giving them access to the corporate network.
10-GE Uplinks
This switch features 10-GE uplinks that increase backplane capacity.
Super-Fast Switch Control Processor
The Gigabit Ethernet Managed Switch has a powerful switch control processor that improves IGMP performance.
Green
The PoE+ Gigabit Managed Switch Eco features IEEE 802.3az energy-efficient Ethernet, which scales down power consumption during periods of low data activity. This feature adds up to energy savings of up to 50%.
Cable length detection adjusts signal strength to the cable length, reducing power consumption on shorter cable runs.
This product is covered by one or more of the following: United States Patent Nos. 7,457,250; 8,902,760; and/or 9,019,838.
| Package Contents |
|
|---|---|
| Product Type | Ethernet Switch |
| Manufacturer Part Number | LPB3052A |
| Packaged Quantity | 1 |
| Power Source | Power Supply |
| Limited Warranty | 1 Year |
| Layer Supported | 2 |
| Weight (Approximate) | 12.39 lb |
| Form Factor | Desktop |
| Manufacturer | Black Box Corporation |
| Product Name | LPB3000 Ethernet Switch |
| Network Technology | 10/100/1000Base-T, 10GBase-X |
| Product Series | LPB3000 |
| Brand Name | Black Box |
| Expansion Slot Type | SFP+ |
| Country of Origin | Taiwan |
| Height | 1.7" |
| Width | 17.4" |
| Depth | 14.8" |
| Manageable | Yes |
| Environmentally Friendly | Yes |
| Ethernet Technology | Gigabit Ethernet, 10 Gigabit Ethernet |
| Network (RJ-45) | Yes |
| Number of SFP+ Slots | 4 |
| Modular | Yes |
| Uplink Port | Yes |
| Media Type Supported | Optical Fiber, Twisted Pair |
| Total Number of Network Ports | 48 |
| PoE (RJ-45) Port | Yes |
| Port/Expansion Slot Details | 48 x Gigabit Ethernet PoE+, 4 x 10 Gigabit Ethernet SFP+ Expansion Slot |
| Total Number of Expansion Slots | 4.0 |
| TAA Compliant | Yes |
| PoE Budget | 740 W |
| Networking Standards | IEEE 802.3at, IEEE 802.3af, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1x, IEEE 802.3az |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS), Waste Electrical and Electronic Equipment Directive (WEEE) |
