60 x HDD Supported - 60 x SSD Supported - 2 x 12Gb/s SAS Controller - RAID Supported - 0, 1, 3, 5, 6, 10 RAID Levels - 60 x Total Bays - 60 x 3.5" Bay - Gigabit Ethernet - 2 USB Port(s) - Network (RJ-45) - iSCSI, SSH, SMI-S, SNMP, SSL, LDAP - 8 SAS Port(s) External - 4U - Rack-mountable
SKU
Category
Storage Arrays & Servers
$37,174.34
Back-ordered
Special order — estimated OEM lead time 3–8 weeks. Order today and we expect to receive stock between Oct 4 and Nov 8, then process your delivery right after.
Genuine Lenovo through authorized distribution — NDAA §889 screened before checkout. TAA verified on request.
SKU
Category
Storage Arrays & Servers
Overview
Lenovo ThinkSystem DE6000H is a scalable, hybrid mid-range storage system that is designed to provide high performance, simplicity, capacity, security, and high availability for medium to large businesses. The ThinkSystem DE6000H delivers enterprise-class storage management capabilities in a performance-optimized system with a wide choice of host connectivity options, flexible drive configurations, and enhanced data management features. The ThinkSystem DE6000H is a perfect fit for a wide range of enterprise workloads, including big data and analytics, video surveillance, technical computing, backup and recovery, and other storage I/O-intensive applications.
ThinkSystem DE6000H models are available in a 2U rack form-factor with 24 small form-factor (2.5-inch SFF) drives (2U24 SFF) or a 4U rack form-factor with 60 LFF drives (4U60 LFF) and include two controllers, each with 16 GB or 64 GB system memory for a system total of 32 GB or 128 GB. Host interface cards provide 12 Gb SAS, 10/25 Gb iSCSI, 8/16/32 Gb FC or NVMe/FC, or 25/40/100 Gb NVMe/RoCE host connections.
Warranty
Additional Warranty Information: Three-year Customer-replaceable Unit And Onsite Limited Warranty With 9x5 Next Business Day (Nbd) Parts Delivered. Limited Warranty: 3 Year
About Lenovo
Join Lenovo Transformation is a Team Sport When you work at Lenovo, you make powerful things happen here — for you, for Lenovo, and for the world.
Highlights
SAN Storage System is the single answer to all your desired storage needs
Holds up to 60 HDDs to let you expand limitlessly
Through RAID levels (0, 1, 3, 5, 6, 10), RAID provides data reliability, fault tolerance and improves overall performance
RAID technology - data reliability, fault tolerance and improved overall performance
Rack-mountable san storage system allows a clutter-free, convenient usage with increased efficiency
Gigabit Ethernet is very resourceful when a large number of file transfers are required, such as when performing backups over a network
Videos
Lenovo ThinkSystem DE6000H SAN Storage System
Specifications
Controllers
Number of Controllers
2
Controller Type
12Gb/s SAS
RAID Supported
Yes
RAID Levels
0, 1, 3, 5, 6, 10
General Information
Manufacturer
Lenovo Group Limited
Manufacturer Part Number
7Y80A00LWW
Brand Name
Lenovo
Product Line
ThinkSystem
Product Series
DE
Product Model
DE6000H
Product Name
ThinkSystem DE6000H SAN Storage System
Product Type
SAN Storage System
I/O Expansions
Number of Total Expansion Bays
60
Number of 3.5" Bays
60
Interfaces/Ports
Host Interface
12Gb/s SAS
Number of SAS Ports (External)
8
Total Number of USB Ports
2
Network (RJ-45)
Yes
Number of Network (RJ-45) Ports
2
Fibre Channel
Yes
Management & Protocols
Protocols
iSCSI, SSH, SMI-S, SNMP, SSL, LDAP
Network & Communication
Ethernet Technology
Gigabit Ethernet
Physical Characteristics
Height
6.9"
Width
17.7"
Depth
36.3"
Form Factor
Rack-mountable
Rack Height
4U
Weight (Approximate)
239.18 lb
Power Description
Number of Power Supplies Installed
2
Plug/Connector Type
C19 to IEC 320-C20
Maximum Power Supply Wattage
2325 W
Redundant Power Supply
Yes
Storage
Number of Hard Drives Supported
60
Number of Hard Drives Installed
No
Number of Solid State Drive Supported
60
Number of Solid State Drive Installed
No
Warranty
Limited Warranty
3 Year
Additional Warranty Information
Three-year Customer-replaceable Unit And Onsite Limited Warranty With 9x5 Next Business Day (Nbd) Parts Delivered.
