Lenovo ThinkSystem DE2000H DAS/SAN Storage System
Lenovo

Lenovo ThinkSystem DE2000H DAS/SAN Storage System

24 x HDD Supported - 0 x HDD Installed - 24 x SSD Supported - 0 x SSD Installed - 2 x 12Gb/s SAS Controller - RAID Supported - 0, 1, 3, 5, 6, 10 RAID Levels - 24 x Total Bays - 24 x 2.5" Bay - Gigabit Ethernet - 2 USB Port(s) - Network (RJ-45) - FCP, SSH, SMI-S, SNMP, SSL, LDAP - 4 SAS Port(s) External - 2U - Rack-mountable

SKU
7Y71A00QWW
Category
Storage Arrays & Servers

Request pricing

Confirmed with stock and TAA status before any payment.

Request a quote

Genuine Lenovo through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.

SKU
7Y71A00QWW
Category
Storage Arrays & Servers

Overview

Lenovo ThinkSystem DE2000H is a low-cost, hybrid entry-level storage system that is designed to provide performance, simplicity, capacity, security, and high availability for small to large businesses. It delivers enterprise-class storage management capabilities with a wide choice of host connectivity options, flexible drive configurations, and enhanced data management features.

This product guide provides essential technical and pre-sales information on the Lenovo ThinkSystem DE2000H Hybrid Storage Array, its key features and specifications, components and options, and configuration guidelines.

This guide is intended for technical specialists, sales specialists, sales engineers, and IT architects who want to learn more about the ThinkSystem DE2000H Hybrid Storage Array and consider its use in their solutions.

Highlights

  • DAS/SAN Storage System offers maximum storage efficiency and convenience
  • Holds up to 24 HDDs to let you expand limitlessly
  • Through RAID levels (0, 1, 3, 5, 6, 10), RAID provides data reliability, fault tolerance and improves overall performance
  • Rack-mountable form factor allows hassle-free and easy usage with increased efficiency
  • Gigabit Ethernet is very resourceful when a large number of file transfers are required, such as when performing backups over a network

Specifications

Host Interface12Gb/s SAS
Product TypeDAS/SAN Storage System
Manufacturer Part Number7Y71A00QWW
ProtocolsFCP, SSH, SMI-S, SNMP, SSL, LDAP
Weight (Approximate)60.85 lb
Form FactorRack-mountable
ManufacturerLenovo Group Limited
Product ModelDE2000H
Product NameThinkSystem DE2000H DAS/SAN Storage System
Product LineThinkSystem
RAID Levels0, 1, 3, 5, 6, 10
Controller Type12Gb/s SAS
Product SeriesDE
Rack Height2U
Brand NameLenovo
Fibre ChannelYes
Plug/Connector TypeC14
Number of Controllers2
Height3.3"
Width17.7"
Depth21.8"
Number of Power Supplies Installed2
Redundant Power SupplyYes
RAID SupportedYes
Ethernet TechnologyGigabit Ethernet
Number of Total Expansion Bays24
Number of Network (RJ-45) Ports1
Network (RJ-45)Yes
Maximum Power Supply Wattage913 W
Total Number of USB Ports2
Number of Hard Drives Supported24
Number of Hard Drives Installed0
Number of Solid State Drive Supported24
Number of Solid State Drive Installed0
Number of 2.5" Bays24
Number of SAS Ports (External)4
SSD Cache Capacity16 GB
