Genuine Lenovo through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.
SKU
7Y71100CNA
Category
Storage Arrays & Servers
Overview
Lenovo ThinkSystem DE2000H is a low-cost, hybrid entry-level storage system that is designed to provide performance, simplicity, capacity, security, and high availability for small to large businesses. It delivers enterprise-class storage management capabilities with a wide choice of host connectivity options, flexible drive configurations, and enhanced data management features.
This product guide provides essential technical and pre-sales information on the Lenovo ThinkSystem DE2000H Hybrid Storage Array, its key features and specifications, components and options, and configuration guidelines.
This guide is intended for technical specialists, sales specialists, sales engineers, and IT architects who want to learn more about the ThinkSystem DE2000H Hybrid Storage Array and consider its use in their solutions.
Warranty
Additional Warranty Information: Three-year customer-replaceable unit and onsite limited warranty with 9x5 next business day (NBD) parts delivered.
Limited Warranty: 3 Year
About Lenovo
Join Lenovo
Transformation is a Team Sport
When you work at Lenovo, you make powerful things happen here — for you, for Lenovo, and for the world.
Highlights
DAS/SAN Storage System is the single answer to all your desired storage needs
Robust scalability up to 24 drives to let you expand limitlessly
Through RAID levels (0, 1, 3, 5, 6, 10), RAID provides data reliability, fault tolerance and improves overall performance
RAID technology - data reliability, fault tolerance and improved overall performance
Rack-mountable das/san storage system allows maximum space utilization with easy and convenient access and retrieval of the data
Gigabit Ethernet enables higher aggregate data transfer capacity which results in a better overall performance
Specifications
Controllers
Number of Controllers
2
Controller Type
12Gb/s SAS
RAID Supported
Yes
RAID Levels
0, 1, 3, 5, 6, 10
General Information
Manufacturer
Lenovo Group Limited
Manufacturer Part Number
7Y71100CNA
Brand Name
Lenovo
Product Line
ThinkSystem
Product Series
DE
Product Model
DE2000H
Product Name
ThinkSystem DE2000H DAS/SAN Storage System
Product Type
DAS/SAN Storage System
I/O Expansions
Number of Total Expansion Bays
24
Number of 2.5" Bays
24
Interfaces/Ports
Host Interface
12Gb/s SAS
Number of SAS Ports (External)
4
Total Number of USB Ports
2
Network (RJ-45)
Yes
Number of Network (RJ-45) Ports
1
Fibre Channel
Yes
Management & Protocols
Protocols
FCP, SSH, SMI-S, SNMP, SSL, LDAP
Network & Communication
Ethernet Technology
Gigabit Ethernet
Physical Characteristics
Height
3.3"
Width
17.7"
Depth
21.8"
Form Factor
Rack-mountable
Rack Height
2U
Power Description
Number of Power Supplies Installed
2
Plug/Connector Type
C14
Maximum Power Supply Wattage
913 W
Redundant Power Supply
Yes
Storage
Number of Hard Drives Supported
24
Number of Hard Drives Installed
0
Number of Solid State Drive Supported
24
Number of Solid State Drive Installed
0
SSD Cache Capacity
16 GB
Warranty
Limited Warranty
3 Year
Additional Warranty Information
Three-year customer-replaceable unit and onsite limited warranty with 9x5 next business day (NBD) parts delivered.
