Lenovo ThinkSystem DE2000H DAS/SAN Storage System
12 x HDD Supported - 0 x HDD Installed - 12 x SSD Supported - 0 x SSD Installed - 2 x 12Gb/s SAS Controller - RAID Supported - 0, 1, 3, 5, 6, 10 RAID Levels - 12 x Total Bays - 12 x 3.5" Bay - Gigabit Ethernet - 2 USB Port(s) - Network (RJ-45) - FCP, SSH, SMI-S, SNMP, SSL, LDAP - 4 SAS Port(s) External - 2U - Rack-mountable
- SKU
- 7Y701008NA
- Category
- Storage Arrays & Servers
$20,970.29
Back ordered — ships when restocked.
Genuine Lenovo through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.
- SKU
- 7Y701008NA
- Category
- Storage Arrays & Servers
Overview
Lenovo ThinkSystem DE2000H is a low-cost, hybrid entry-level storage system that is designed to provide performance, simplicity, capacity, security, and high availability for small to large businesses. It delivers enterprise-class storage management capabilities with a wide choice of host connectivity options, flexible drive configurations, and enhanced data management features.
This product guide provides essential technical and pre-sales information on the Lenovo ThinkSystem DE2000H Hybrid Storage Array, its key features and specifications, components and options, and configuration guidelines.
This guide is intended for technical specialists, sales specialists, sales engineers, and IT architects who want to learn more about the ThinkSystem DE2000H Hybrid Storage Array and consider its use in their solutions.
Highlights
- DAS/SAN Storage System offers maximum storage efficiency and convenience
- Robust scalability up to 12 drives to let you expand limitlessly
- Through RAID levels (0, 1, 3, 5, 6, 10), RAID provides data reliability, fault tolerance and improves overall performance
- RAID technology - data reliability, fault tolerance and improved overall performance
- Rack-mountable das/san storage system allows a clutter-free, convenient usage with increased efficiency
- Gigabit Ethernet enables higher aggregate data transfer capacity which results in a better overall performance
Specifications
| Additional Warranty Information | Three-year customer-replaceable unit and onsite limited warranty with 9x5 next business day (NBD) parts delivered. |
|---|---|
| Package Contents |
|
| Host Interface | 12Gb/s SAS |
| Product Type | DAS/SAN Storage System |
| Manufacturer Part Number | 7Y701008NA |
| Protocols | FCP, SSH, SMI-S, SNMP, SSL, LDAP |
| Limited Warranty | 3 Year |
| Form Factor | Rack-mountable |
| Manufacturer | Lenovo Group Limited |
| Product Model | DE2000H |
| Product Name | ThinkSystem DE2000H DAS/SAN Storage System |
| Product Line | ThinkSystem |
| RAID Levels | 0, 1, 3, 5, 6, 10 |
| Controller Type | 12Gb/s SAS |
| Product Series | DE |
| Rack Height | 2U |
| Brand Name | Lenovo |
| Fibre Channel | Yes |
| Plug/Connector Type | C14 |
| Number of Controllers | 2 |
| Height | 3.3" |
| Width | 17.6" |
| Depth | 19" |
| Environmentally Friendly | Yes |
| Number of Power Supplies Installed | 2 |
| Redundant Power Supply | Yes |
| RAID Supported | Yes |
| Ethernet Technology | Gigabit Ethernet |
| Number of Total Expansion Bays | 12 |
| Number of 3.5" Bays | 12 |
| Number of Network (RJ-45) Ports | 1 |
| Network (RJ-45) | Yes |
| Maximum Power Supply Wattage | 913 W |
| Total Number of USB Ports | 2 |
| Number of Hard Drives Supported | 12 |
| Number of Hard Drives Installed | 0 |
| Number of Solid State Drive Supported | 12 |
| Number of Solid State Drive Installed | 0 |
| Number of SAS Ports (External) | 4 |
| SSD Cache Capacity | 16 GB |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
