60 x HDD Supported - 60 x SSD Supported - 2 x Serial Attached SCSI (SAS) Controller - RAID Supported - 0, 1, 3, 5, 6, 10 RAID Levels - 60 x Total Bays - 60 x 3.5" Bay - Gigabit Ethernet - 2 USB Port(s) - Network (RJ-45) - FCP, SSH, SMI-S, SNMP, SSL, LDAP - 64 GB Flash Memory Capacity - 4U - Rack-mountable
SKU
Category
Storage Arrays & Servers
$48,955.97
Back-ordered
Special order — estimated OEM lead time 3–8 weeks. Order today and we expect to receive stock between Oct 29 and Dec 3, then process your delivery right after.
Genuine Lenovo through authorized distribution — NDAA §889 screened before checkout.
SKU
Category
Storage Arrays & Servers
Overview
Lenovo ThinkSystem DE4000H is a scalable, hybrid entry-level storage system that is designed to provide performance, simplicity, capacity, security, and high availability for medium to large businesses. It delivers enterprise-class storage management capabilities with a wide choice of host connectivity options, flexible drive configurations, and enhanced data management features. The ThinkSystem DE4000H is a perfect fit for a wide range of enterprise workloads, including big data and analytics, video surveillance, technical computing, backup and recovery, and other storage I/O-intensive applications.
ThinkSystem DE4000H models are available in a 2U rack form-factor with 24 small form-factor (2.5-inch SFF) drives (2U24 SFF), 12 large form-factor (3.5-inch LFF) drives (2U12 LFF), or a 4U rack form-factor with 60 LFF drives (4U60 LFF) and include two controllers, each with 8 GB or 32 GB memory for a system total of 16 GB or 64 GB. Host interface cards provide 12 Gb SAS, 10/25 Gb iSCSI, or 8/16/32 Gb FC connections.
The ThinkSystem DE4000H Storage Array scales up to 192 drives with the attachment of Lenovo ThinkSystem DE120S 2U12, DE240S 2U24 SFF, and DE600S 4U60 LFF Expansion Enclosures. It also offers flexible drive configurations with the choice of 2.5-inch (SFF) and 3.5-inch (LFF) form factors, 10 K rpm SAS and 7.2 K rpm NL SAS hard disk drives (HDDs), and SAS solid-state drives (SSDs).
Warranty
Additional Warranty Information: Three-year customer-replaceable unit and onsite limited warranty with 9x5 next business day (NBD) parts delivered. Limited Warranty: 3 Year
About Lenovo
Join Lenovo Transformation is a Team Sport When you work at Lenovo, you make powerful things happen here — for you, for Lenovo, and for the world.
Highlights
DAS/SAN Storage System offers maximum storage efficiency and convenience
Robust scalability up to 60 drives to let you expand limitlessly
Through RAID levels (0, 1, 3, 5, 6, 10), RAID provides data reliability, fault tolerance and improves overall performance
RAID technology - data reliability, fault tolerance and improved overall performance
Rack-mountable das/san storage system allows easy and convenient usage without any trouble
Gigabit Ethernet enables higher aggregate data transfer capacity which results in a better overall performance
Videos
Lenovo ThinkSystem DE4000H DAS/SAN Storage System
Specifications
Controllers
Number of Controllers
2
Controller Type
Serial Attached SCSI (SAS)
RAID Supported
Yes
RAID Levels
0, 1, 3, 5, 6, 10
General Information
Manufacturer
Lenovo Group Limited
Manufacturer Part Number
7Y77A00BWW
Brand Name
Lenovo
Product Line
ThinkSystem
Product Series
DE
Product Model
DE4000H
Product Name
ThinkSystem DE4000H DAS/SAN Storage System
Product Type
DAS/SAN Storage System
I/O Expansions
Number of Total Expansion Bays
60
Number of 3.5" Bays
60
Interfaces/Ports
Total Number of USB Ports
2
Network (RJ-45)
Yes
Number of Network (RJ-45) Ports
2
Fibre Channel
Yes
Management & Protocols
Protocols
FCP, SSH, SMI-S, SNMP, SSL, LDAP
Network & Communication
Ethernet Technology
Gigabit Ethernet
Physical Characteristics
Height
6.9"
Width
17.7"
Depth
36.3"
Form Factor
Rack-mountable
Rack Height
4U
Power Description
Number of Power Supplies Installed
2
Plug/Connector Type
C19 to IEC 320-C20
Maximum Power Supply Wattage
2325 W
Redundant Power Supply
Yes
Storage
Number of Hard Drives Supported
60
Number of Hard Drives Installed
No
Number of Solid State Drive Supported
60
Number of Solid State Drive Installed
No
Flash Memory Capacity
64 GB
Warranty
Limited Warranty
3 Year
Additional Warranty Information
Three-year customer-replaceable unit and onsite limited warranty with 9x5 next business day (NBD) parts delivered.
