Network & data center services

Low Voltage Cabling for Data, PoE and Security

Low voltage is where the data network, the powered devices and the security system share one pathway and one install day.

We quote the cable, the patch panels, the keystones and the terminations for all three on a single bill of materials — Cat6 and Cat6A drops, PoE runs, and the cabling behind cameras, readers and door hardware.

Get a low voltage quote See what's inside

Scope: Data drops · PoE runs · camera and reader cabling
Category choice: Set by PoE class and bundle size, not by habit
Counts come from: The floor plan and the door and camera schedule
Boundary: We supply and coordinate — permits and inspection stay on site

Tell us the project — Low voltage cabling

Tell us where to reach you and a Uniqcli specialist follows up by email to scope the work with you — what has to be covered, how many sites or buildings, and what already exists — then comes back with a quoted bill of materials across the equipment, the software licensing and the deployment work.

Priced against your own site rather than a package tier, sourced through authorized US distribution and screened line by line. We specify, supply, stage and integrate; internet access is scoped separately from the equipment on this page, and operating the network stays with your team or the provider you contract.

The first number is our real one, not an opening one.

Tell us the scope and we come back with the best price we can do on it.

Supporting federal, state & local purchasers
GPC & P-Card accepted
TAA & NDAA-889 screening before every quote

Live catalog prices for in-stock hardware, shown as a starting point — your quote is scoped to the site and includes the licensing and services the job needs.

Overview

One pathway, three systems, one install day

Low voltage is a category defined mostly by what it is not: not line voltage, not the electrician's scope, and in most buildings not any single vendor's responsibility. In practice it is three systems sharing one set of pathways — the data drops, the powered devices riding those drops, and the security devices that were specified by somebody else on a different drawing.

Continue readingShow less

They get installed in the same ceiling in the same week by the same crew, and they fail in the same handful of ways: a run that is longer than the channel allows, a bundle of powered runs that gets warm in the middle, a patch panel terminated in a style nothing else on site uses, or a door that needed four conductors nobody counted. Quoting all three from one bill of materials does not make the install easy, but it does mean the parts agree with each other when they arrive.

The bill of materials

What the quote covers

Data, powered devices and security cabling are usually bought from three suppliers on three schedules. Priced together, the overlaps show up while they are still cheap to fix.

Cat6 and Cat6A data drops

Cable in the category the run actually needs and the jacket rating the pathway requires, with boxes and reels counted against the drop schedule rather than estimated.

Continue readingShow less

Keystones, faceplates, surface-mount boxes and blanks for reserved positions are ordered as a matching family, because a keystone that does not seat in the faceplate is a return, not a workaround.

Patch panel installation materials

Flat or angled panels, 110 punch-down or feed-through keystone, port density checked against the rack units the closet has left, and horizontal managers so the field stays legible after the third moves-and-changes ticket.

Continue readingShow less

Patch cords in specified lengths and colors, plus label stock and the scheme itself, are quoted rather than left to whoever is holding the crimp tool.

PoE runs and powered devices

The class a device draws shapes the cabling more than the switch does. Higher 802.3bt classes across a shared bundle raise temperature in the middle of that bundle, and heat costs you distance.

Continue readingShow less

Where a run or a power budget will not reach, midspan injectors, PoE extenders and the switching headroom to support them are quoted alongside the cable rather than discovered on commissioning day.

Camera, reader and door cabling

Cameras ride the same drops as everything else, but their positions are set by sightlines rather than by desks — exterior corners, high bays and gates, which is where outdoor-rated cable, surge protection and grounding enter the bill.

Continue readingShow less

Access control adds composite and multi-conductor runs for the reader, request-to-exit, door position switch and lock power at each opening, so the counts come off the door schedule rather than the floor plan.

One drawing, one bill of materials

Go to the form

Cat6 installation

Choosing the category per run, not per building

The channel has a fixed budget: 90 metres for the permanent link and 100 metres for the full channel once the patch cords at both ends are counted. That single number does more to shape a low voltage design than any product decision in it — it sets where the telecom room has to be, it decides whether the far corner of a floor plate needs an intermediate closet, and it is the reason a handful of awkward runs sometimes justify a fiber link or a second rack rather than a longer copper pull that will never certify.

Continue readingShow less

Category choice sits on top of that. Cat6 remains entirely adequate for a large share of ordinary drops; Cat6A earns its place where the application demands it, where higher PoE classes are running in dense bundles, or where the run is long enough that thermal derating starts eating into the margin. The comparison that misleads people is the one made on cable price alone, because Cat6A generally costs more to install than to buy — larger outside diameter, tighter bend radius, more pathway fill and slower terminations all land in labor. We flag the runs that genuinely need it instead of upgrading a whole floor as insurance.

Heat is the part that gets underestimated. A bundle carrying many high-class powered runs is warmer in the middle than at the edges, a warmer conductor carries more insertion loss, and the loss shows up as a link that certifies marginally and then degrades. The mitigations are all cheap while the ceiling is open — smaller bundles, better separation, a higher category on the affected runs, shorter runs to a closer closet — and all expensive once it is closed.

Lines we quote

Where the parts come from

Naming a manufacturer describes the lines we quote, not a Uniqcli partnership, authorization or endorsement. Availability is stated per line and the quote says which lines are priced today.

Panduit and Leviton

Jacks, faceplates, patch panels, cable management and labeling systems — the connectivity family that has to be specified together so the parts seat, stack and label consistently across every closet in the portfolio.

Continue readingShow less

Both carry live-priced rows across that estate, which is what lets a drop schedule turn into a per-line quote quickly.

Tripp Lite, C2G and Black Box

Patch cords and cable assemblies in real lengths and colors, racks and cable management, and extension or media conversion for the runs that copper alone will not carry.

Continue readingShow less

Tripp Lite is an Eaton line. All three price across the assembly and rack estate rather than only at a few headline part numbers.

Sourced on request

Bulk reels in a specific jacket rating, composite security cable, outdoor-rated and gel-filled runs, custom-length assemblies and crew consumables are quoted through authorized US distribution rather than listed with a shelf price.

Continue readingShow less

Where a category has no priced rows we say so and quote it rather than naming a line we cannot verify.

What's included

What's included in a low voltage bill of materials

One bill of materials covering the data drops, the powered devices and the security-device runs together. This is one bill of materials for all three.

Cat6 and Cat6A drops in the category each run actually needs and the jacket rating the pathway requires, counted against the drop schedule rather than estimated
Patch panels — flat or angled, punch-down or feed-through — with port density checked against the rack units the closet has left, and horizontal managers
Keystones, faceplates and the terminations behind every drop
PoE runs sized by the class each device draws, including the heat a bundle carries
Camera, reader and door cabling, with outdoor-rated, composite and gel-filled runs where the position calls for them
Bulk reels in a specific jacket rating, custom-length assemblies and crew consumables sourced through authorized US distribution

How buying works

From a drawing to a screened order

The fastest quotes start from a schedule rather than a description. Anything that names counts, distances or openings is enough to work with.

Send the floor plan and drop schedule — plus the door and camera schedule if security devices are in scope
Counts are worked per system: data drops, powered devices and their class, and the runs each opening needs
One bill of materials comes back — cable, keystones, panels, cords, management, pathway and labeling, availability per line
Where the project scope includes installation, it is coordinated against your site schedule rather than sold as hourly labor
TAA (FAR 52.225-5) and NDAA §889 screening is performed on every line before the quote goes out, which matters most on the camera and reader side
GPC / P-Card accepted up to your cardholder threshold; purchase orders otherwise, with the final total confirmed before you commit

Security devices

Where cameras and readers change the cabling conversation

Cameras are network endpoints, so they ride the same drops as everything else — but their positions are chosen for what has to be seen, which puts them at exterior corners, in high bays, at gates and on poles rather than at desks. Those positions bring their own bill: outdoor-rated or gel-filled cable where a run leaves the conditioned envelope, surge protection and grounding where it leaves the building entirely, and mounting and pathway that a floor plan does not show. Outdoor positions are also where power stops being free, which is why coverage designs tend toward fewer, better-chosen positions rather than more of them.

Continue readingShow less

Access control is not a data-only run. A single controlled opening commonly needs the reader, the request-to-exit device, the door position switch and lock power, which is why composite cable exists and why the count comes off the door schedule rather than the floor plan. Getting that schedule before the cable order is one of the cheapest hours on the project: an opening discovered late is a return trip through a ceiling that has already been closed.

This is also the part of a low voltage order where NDAA §889 screening does the most work, because covered equipment turns up in video surveillance more than in any other category — including inside hardware that carries somebody else's label. Screening is per line and before the quote leaves, with alternates named for anything that does not clear.

Quote the drops, the PoE and the door cabling together

Send the floor plan, and the door and camera schedule if cameras or readers are in scope. One bill of materials comes back with the data, PoE and security-device cabling priced as readable lines, screened before it goes out.

Get a low voltage quote Build a cabling BOM

Limits

Where our line falls

We are a national supplier and integrator, not a local low-voltage or electrical contractor bidding hourly labor. We specify the cabling, source it through authorized US distribution, quote it as a bill of materials, and coordinate installation as part of the projects whose scope includes it. Permits, inspections, firestop penetration sign-off and code compliance stay with the licensed trades performing the work and with the authority having jurisdiction, and no supplier can carry those on your behalf.

Continue readingShow less

Supplying the cabling behind a camera or a reader is also not the same as running a security program. We do not monitor cameras, review footage, respond to alarms, issue credentials or hold credentials on your system after handover — that stays with your organization or the provider you contract. We make no uptime or response-time commitment on the plant or on anything riding it, and availability is stated per line rather than promised in general terms.

The systems that share the pathway

Low voltage touches the network and the security system at the same time. These are the scopes most often quoted alongside it.

Structured cabling services Fiber optic cabling PoE network infrastructure Video surveillance Access control Network installation services Patch panels in the catalog Security package estimator

Go to the form

Questions

Low voltage cabling questions

What counts as low voltage cabling?

In practice it is the structured data cabling, the powered devices riding it over PoE, and the low-voltage side of security and audiovisual systems — network drops, camera and reader runs, door hardware wiring, speaker and display cabling. What it is not is line-voltage electrical work, which is a licensed electrician's scope with its own permits and inspections. We quote the low-voltage materials and coordinate installation inside a project; the electrical scope stays where it belongs.

Cat6 or Cat6A for a PoE deployment?

Decide per run. Cat6 is adequate for a large share of ordinary drops; Cat6A earns its place where higher 802.3bt classes run in dense bundles, where runs are long enough for thermal derating to matter, or where the application genuinely needs the bandwidth. The trap is comparing on cable price alone — Cat6A generally costs more to install than to buy, because the diameter, bend radius and pathway fill all show up in labor. We flag the runs that need it instead of upgrading the floor as insurance.

How long can a Cat6 run be?

The permanent link is capped at 90 metres and the full channel at 100 metres once the patch cords at both ends are counted, so anything measured on a plan needs slack for the route the cable actually takes through the ceiling. Past that, the answer is not a longer pull — it is an intermediate closet or a fiber link back to the main room. We flag the runs that are close to the limit during scoping, because a link that certifies marginally is a fault waiting for a warm summer.

Can one order cover the data drops and the camera cabling?

Yes, and it usually should. Cameras and readers ride the same pathways as the data drops and get installed by the same crew in the same week, so pricing them separately is how a site ends up with mismatched panels, two labeling schemes and a door that needed conductors nobody ordered. Send the floor plan with the door and camera schedule and both come back on one bill of materials.

Do you supply the cameras and readers themselves, or only the cabling?

Both. Camera, reader, credential and panel lines are quoted through our distribution network against your own scope rather than listed with a shelf price, because what a system costs depends on the door count, the sightlines and the retention period rather than on a part number. The cabling, the devices and the switching that powers them can be quoted as one package or as separate orders, whichever suits how you are buying.

Is low voltage hardware TAA and §889 screened?

Every line, before the quote goes out — and it matters most here. Video surveillance is the category where NDAA §889 covered equipment most often turns up, including inside rebadged hardware, and the prohibition has no low-dollar exemption. Manufacturer-stated country of origin is recorded per line and the maker with its parent and affiliates is checked against the covered-entity list, with alternates named for anything that does not clear.
