Unmanaged Gigabit Ethernet Switch 8 10/100/1000Base-T Ports
UNMANAGED SWITCH, 8-PORT GIGABIT ETHERNET W/NA
- SKU
- S8TB-NA
- Category
- Switches & Bridges
MSRP$132.00
$102.59
Save 22%In stock: 19
Genuine Transition Networks through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.
- SKU
- S8TB-NA
- Category
- Switches & Bridges
Overview
This (8) 10/100/1000Base-T port switch with Auto-MDI/MDIX is an unmanaged multi-port switch that can be used to build high-performance switched networks. This switch is a store-and-forward device that offers low latency for high speed networking. It is designed for the core of the network backbone computing environment to solve traffic block problems at SME (small, medium enterprise) businesses. NDAA Compliant, TAA Compliant
Highlights
- Small Form Factor
- Internal Power Supply
- Auto-Negotiation
- Auto-MDI/MDIX
- Supports full and half-duplex for 10/100Mbps and full-duplex for 1000Mbps
- Wire-speed packet filtering and forwarding rate
- Support Jumbo Frame up to 9K bytes
- Supports IEEE 802.3az energy efficient Ethernet
Specifications
| Package Contents |
|
|---|---|
| Product Type | Ethernet Switch |
| Manufacturer Part Number | S8TB-NA |
| Power Source | Power Supply |
| Limited Warranty | 5 Year |
| Layer Supported | 2 |
| Weight (Approximate) | 9.60 lb |
| Form Factor | Desktop |
| Manufacturer | Lantronix, Inc |
| Product Model | S8TB |
| Product Name | Unmanaged Switch |
| Network Technology | 10/100/1000Base-T |
| Brand Name | Transition Networks |
| Country of Origin | Taiwan |
| Height | 1.3" |
| Width | 3.9" |
| Depth | 6.3" |
| Manageable | No |
| Environmentally Friendly | Yes |
| Ethernet Technology | Gigabit Ethernet |
| Modular | No |
| Uplink Port | No |
| Stack Port | No |
| Media Type Supported | Twisted Pair |
| Total Number of Network Ports | 8 |
| Port/Expansion Slot Details | 8 x Gigabit Ethernet Network |
| Redundant Power Supply Supported | No |
| TAA Compliant | Yes |
