Overview
The Next Wave 100G Ethernet Switch for Data Center and Cloud
Data center networks face the changes with hardware and meet the requirements of the software it hosts. Quanta Cloud Technology provides a series of Ethernet Switches, the QCT QuantaMesh switch product line, that addresses these changes and provides the advanced features that meet the demands for the contemporary data center applications. The QCT QuantaMesh product lines provide the connections from 1G to 100Gbps speeds on its Ethernet Switches. To meet the requirements of high performance, high availability, fast scale out, low latency performance, and continuous serviceability for data center applications. The QCT QuantaMesh Ethernet Switch product line supported with QNOS (Quanta Network OS) to provide the advanced features, which is the best choice for Data Center application.
QCT T7032-IX7D is a high-performance and low latency layer 3 managed switches deployed as the Data Center Leaf Switch to connect to 100G servers or deployed as Data Center Spine Switch to aggregate 100G connections from Leaf Switches to expend the network scalability. T7032-IX7D supports 32 QSFP28, each supporting 1 x 100GbE or 1 x 40GbE, or via breakout cables, 2 x 50GbE, 4 x 25GbE, or 4 x 10GbE. It equipped with BMC in a 1-Rack-Unit (1RU) switch and supports 3.2 Terabits per second (Tbps) of bandwidth. By levering merchant silicon chip, T7032-IX7D is a high performance and high density Ethernet switch with advanced features such as smart table, dynamic load balancing, and VxLAN/RIOT support. T7032-IX7D also support larger tables size, improves the performance for larger packet buffers and reduced the latency. With QNOS (Quanta Network OS) supported, T7032-IX7D is the best fit for Data Center application.
Highlights
Effectively increases available bandwidth on your network
Can work as layer 3 routing for scalable network design
Rail mounting is ideal for factory areas, in vehicles and marine applications
Managed switch provides a reliable foundation for your network
40 Gigabit Ethernet for efficient data transfer and fast connectivity
Supports optical fiber cable to span longer distances and provided high data transmission rates between servers and network components
Specifications
General Information
Manufacturer
Quanta Computer, lnc
Manufacturer Part Number
1IX7U7Z0003
Brand Name
QCT
Product Line
QuantaMesh
Product Model
T7032-IX7D
Product Name
QuantaMesh T7032-IX7D Ethernet Switch
Product Type
Ethernet Switch
Interfaces/Ports
Port/Expansion Slot Details
32 x 40/100 Gigabit Ethernet QSFP28 Expansion Slot, 1 x RJ-45 Console Port
Management & Protocols
Manageable
Yes
Media & Performance
Media Type Supported
Optical Fiber
Ethernet Technology
40 Gigabit Ethernet, 100 Gigabit Ethernet
Network Technology
40GBase-X, 100GBase-X
Fiber Optic Cable Wavelength
1310 nm, 850 nm
Maximum Data Transfer Rate
12.50 GB/s
Network & Communication
Layer Supported
3
Physical Characteristics
Product Material
Metal
Compatible Rack Unit
1U
Form Factor
Rail-mountable, Rack-mountable
Height
1.7"
Width
17.3"
Depth
20"
Weight (Approximate)
20.57 lb
Power Description
Input Voltage
120 V AC, 230 V AC
Power Source
Power Supply, AC
Number of Power Supplies Installed
2
Power Consumption
293 W
Technical Information
Features
Zero-Touch Provisioning (ZTP)
I/O Expansions
Total Number of Expansion Slots
32
Expansion Slot Type
QSFP28
Miscellaneous
Environmental Compliance
Restriction of Hazardous Substances (RoHS), Waste Electrical and Electronic Equipment Directive (WEEE), China Restriction of Hazardous Substances (China RoHS), Taiwan Restriction of Hazardous Substances (Taiwan RoHS), Restriction of Hazardous Substances (RoHS) 6
