Genuine Fortinet through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.
SKU
FS-524D
Category
Switches & Bridges
Overview
FortiSwitch Secure Access switches deliver outstanding security, performance and manageability for threat conscious small to mid-sized businesses, distributed enterprises and branch offices. Tightly integrated into the FortiGate® Network Security Platform, the FortiSwitch Secure Access switches can be managed directly from the familiar FortiGate interface. This single pane of glass management provides complete visibility and control of all users and devices on the network, regardless of how they connect.
When a device connects to a Secure Access Switch Ethernet port, it is first identified, and then the user is authenticated. Once authenticated, access to the network is granted based non pre-defined security policy from the FortiGate, ensuring secure network access across the enterprise, without impacting the user experience.
Secure Managed Switches for Wire Closet Installation
The FortiSwitch D-Series switches are ideal for the next generation applications, where increased productivity can be achieved through faster network access speeds via dedicated Gigabit Ethernet ports. With a compact 1RU form factor, these switches are ideally suited for high density enterprise or classroom wire closet installations, delivering a truly secure network access platform for wired Ethernet devices.
Simple Network Deployment and Compliance
The Power over Ethernet (PoE) capability enables simple installation of wireless Access Points and IP phones in the network, with power and data being delivered over the same network cable. There is no need to contract electricians to install power for your PoE capable devices anymore, reducing your overall network TCO.
By leveraging the FortiSwitch VLAN segmentation feature of the switches, enterprise networks can support the convergence of voice, data and wireless traffic onto a single network platform. FortiSwitch network segmentation can even be managed from the FortiGate interface, simplifying the process of meeting compliance requirements for data separation.
Highlights
Ethernet Switch supports network continuity by maintaining data transmission during operation
Features 24 networking ports to support the connection requirements of larger workgroups using wired infrastructure
Built?in power supply supports internal components by providing required operating voltage
Layer 2 switching supports defined functions including IGMP snooping, port mirroring, and spanning tree operation
Rack?mountable design supports installation within standard equipment racks to accommodate organized hardware placement
Managed capability enables configuration and monitoring functions that support structured network operation
40 Gigabit Ethernet supports efficient data transfer and consistent network connectivity
Optical fiber support enables network connections across longer distances for data transmission between network components
Specifications
General Information
Manufacturer
Fortinet, Inc
Manufacturer Part Number
FS-524D
Brand Name
Fortinet
Product Line
FortiSwitch
Product Model
524D
Product Name
FortiSwitch 524D Ethernet Switch
Product Type
Ethernet Switch
Interfaces/Ports
Total Number of Network Ports
24
Uplink Port
No
Modular
Yes
Stack Port
No
Port/Expansion Slot Details
24 x Gigabit Ethernet Network, 4 x 10 Gigabit Ethernet Expansion Slot, 2 x 40 Gigabit Ethernet Expansion Slot
