SKU
QGD-1600-8G-US
Category
Switches & Bridges
Overview
QNAP?s QGD-1600 is the world?s first managed switch that supports Virtual Machines (VMs). It features multiple Gigabit ports for highly flexible networking environment deployment. With a dual-CPU design, the QGD-1600 provides both Layer 2 management functions for VM and QTS applications. The QGD-1600 also features Software-Defined Networking (SDN), enabling it to function as a NAS, NVR, router and firewall for IP surveillance, network security and storage expansion applications. Therefore, the QGD series offers SMBs a cost-optimized and centrally managed LAN deployment solution.
Gigabit RJ45/SFP ports
Multiple Gigabit and RJ45/SFP combo ports provide computers, LAN switches and NAS with higher bandwidth to empower applications like virtualization, 4K video editing and file sharing.
Layer 2 network
QGD-1600 provides comprehensive Layer 2 management features, such as VLAN, LACP, QoS IGMP Snooping, and Wake-on-LAN for IT administrators to efficiently control the network bandwidth and enhance security via the user-friendly switch management web interface.
User-friendly management interface
QuNetSwitch offers a user-friendly web interface to help IT administrators efficiently control Layer 2 networks. Additionally, the overview dashboard and graphical statistics analysis show IT administrators all switch information and pored devices at a glance, making central management of network devices intuitive and easy.
Two SATA drive bays
Supports up to two SATA drives.
Flexible PCIe expansion
PCIe expandability allows for 10GbE network cards, QM2 dual-port M.2 SSD/10GbE cards, USB 3.1 Gen 2 (10Gbps) cards, or Wireless Adapters.
Virtualization applications
Host containerized applications and virtual machines with various operating systems. Flexibly install virtual router, firewall, or wireless LAN management software for various networking management applications.
Highlights
Ethernet Switch provides reliable, efficient connectivity to ensure maximum feasibility
Create your own LAN and connect your PC, laptop, printer and other peripherals with the help of 14 ports
Layer 2 switch provides a complete lineup of features including IGMP snooping, port mirroring, and spanning tree
Rack mounting enables you to organize wires & secure cables for professional installation
Management capability provides control over setup and configuration of your network
Gigabit Ethernet port for ultra-fast network speeds
Supports optical fiber cable to span longer distances and provided high data transmission rates between servers and network components
Specifications
Package Contents
QGD-1600-8G Ethernet Switch
Power Cord
6 x Flat head screw (for 2.5" HDD)
Rackmount kit
Rubber feet
1 x Ethernet Cable
Product Type
Ethernet Switch
Input Voltage
120 V AC, 230 V AC
Manufacturer Part Number
QGD-1600-8G-US
Power Source
Power Supply, AC, PoE++
Limited Warranty
2 Year
Layer Supported
2
Weight (Approximate)
9.72 lb
Features
Reset Button
Form Factor
Rack-mountable
Manufacturer
QNAP Systems
Product Model
QGD-1600-8G
Product Name
QGD-1600-8G Ethernet Switch
Network Technology
10/100/1000Base-T, 1000Base-X
Power Consumption
100 W
Product Series
QGD
Brand Name
QNAP
Expansion Slot Type
SFP
Height
1.9"
Width
17.2"
Depth
12.8"
Manageable
Yes
Compatible Rack Unit
1U
Maximum Data Transfer Rate
125 MB/s
Ethernet Technology
Gigabit Ethernet
Network (RJ-45)
Yes
Number of SFP Slots
2
Media Type Supported
Twisted Pair, Optical Fiber
Total Number of Network Ports
14
Port/Expansion Slot Details
14 x Gigabit Ethernet PoE++ RJ-45 Network Port, 2 x Gigabit Ethernet SFP Combo Expansion Slot, 1 x Gen 1 USB 3.2 Port, 2 x USB 2.0 Port, 1 x Gigabit Ethernet Management Port
