24 Ports - Manageable - 25 Gigabit Ethernet - 10GBase-T, 10/100/1000Base-T, 25GBase-X - 3 Layer Supported - Modular - 750 W Power Consumption - 290 W PoE Budget - Optical Fiber, Twisted Pair - PoE Ports - 1U - Rack-mountable, Table Top
MSRP$8,863.43
$6,046.73
Save 32%In stock: 1
Genuine Netgear through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.
Introducing the NETGEAR AV and IT M4350 Switches, engineered and certified for audio/video over IP with dedicated service and support. The M4350 brings all the simplicity from the M4250 AV Line packed in more Enterprise-class hardware with redundant power supplies and larger fabrics with 25G and 100G uplinks. The revolutionary NETGEAR AV user interface and Engage? Controller contain pre-configured profiles for all major audio, video, and lighting protocols.
NETGEAR listens to and supports the Pro AV community
• IGMP Plus? means AV-over-IP multicasting will work out of the box and not flood your network
• Auto-LAG and Auto-Trunk automatically configure the uplinks between multiple switches
• The Engage? Controller manages all M4250, M4300, and M4350 switches for your AV installations
• NETGEAR ProAVDesign team tohelp with system design andimplementation toensure theproject will work
• AVB, Dante, Q-SYS, AES67, NVX, AMX, Q-SYS, NDI 4, NDI 5, ZeeVee, Aurora Multimedia, Kramer, Atlona, LibAV, Visionary, SDVoE, and many others!
• SMPTE ST 2110 supported on select models, always with the same simplicity from the AV UI
Enterprise-class hardware
• From 1G to 2.5G, to 10G, to 25G, to 100G always within 40cm (15.7in) depth
• Controlled thermal and acoustics (intelligent fans configurable in Quiet Mode to minimize noise, or Cool Mode to minimize heat)
Other IT use cases
• Edge to core stackable platform, from 1 Gigabit to 100 Gigabit for midsize organizations
• Non-stop forwarding (NSF) provides advanced High Availability (HA) with hitless failover across the stack
Industry standard management
• Industry standard command line interface (CLI), main NETGEAR IT web interface (GUI)
• SNMP, sFlow and RSPAN - the entire feature set is available without license
Industry leading warranty
• NETGEAR M4350 series is covered under NETGEAR ProSAFE Limited Lifetime Hardware Warranty
• 90 days of Technical Support via phone and email, Lifetime Technical Support through online chat and Lifetime Next Business Day hardware replacement
| Product Type | Ethernet Switch |
|---|---|
| Input Voltage | 120 V AC, 230 V AC |
| Manufacturer Part Number | XSM4340V-100NES |
| Power Source | Power Supply |
| Layer Supported | 3 |
| Weight (Approximate) | 17.11 lb |
| Form Factor | Rack-mountable, Table Top |
| Manufacturer | Netgear, Inc |
| Product Model | M4350-24X8F8V |
| Product Name | AV Line M4350-24X8F8V Ethernet Switch |
| Network Technology | 10GBase-T, 10/100/1000Base-T, 25GBase-X |
| Power Consumption | 750 W |
| Product Line | AV Line |
| Product Series | M4350 |
| Brand Name | Netgear |
| Plug/Connector Type | C14 |
| Expansion Slot Type | SFP28, SFP+ |
| Height | 17" |
| Width | 14.4 ft |
| Depth | 15.7" |
| Manageable | Yes |
| Compatible Rack Unit | 1U |
| Number of Power Supplies Supported | 2 |
| Number of Power Supplies Installed | 1 |
| Ethernet Technology | 25 Gigabit Ethernet |
| Network (RJ-45) | Yes |
| Number of SFP+ Slots | 8 |
| Modular | Yes |
| Uplink Port | Yes |
| Stack Port | Yes |
| Media Type Supported | Optical Fiber, Twisted Pair |
| Total Number of Network Ports | 24 |
| PoE (RJ-45) Port | Yes |
| Port/Expansion Slot Details | 24 x 10 Gigabit Ethernet PoE++, 8 x 25 Gigabit Ethernet Expansion Slots, 8 x Expansion Slots |
| Total Number of Expansion Slots | 16 |
| Redundant Power Supply Supported | Yes |
| PoE Budget | 290 W |
| Networking Standards | IEEE 802.3bt, IEEE 802.3af, IEEE 802.3at, IEEE 802.1as, IEEE 802.1Qav, IEEE 802.1Qat, IEEE 802.1ak, IEEE 802.3az, IEEE 802.3ad, IEEE 802.1AX, IEEE 802.1s, IEEE 802.1w, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1BA |
