Genuine Netgear through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.
SKU
GS316EPP-100NAS
Category
Switches & Bridges
Overview
NETGEAR Plus Switches with PoE meets business networks growing need by providing fundamental network features such as simplified VLANs, QoS set-up and IGMP Snooping that will help optimize the performance of business networks. Plus Switches are the perfect upgrade from the plugand-play unmanaged switch, delivering essential networking features at a very affordable price. These models support Power-Over-Ethernet (PoE) and can power devices such as VOIP phones, surveillance IP cameras, wireless access points and many other applications. These new PoE+ Gigabit Ethernet Plus switches models include uninterruptable PoE to help optimize the performance and troubleshooting of business networks. The new and improved business-friendly GUI allows easy management and simple configuration. With the growing deployment of applications and an all-inone solution, providing management and power to these applications would be ideal.
Highlights
• Enable network configuration and management at the price point of unmanaged switches
• Simple, yet useful network set-up on top of plug-and-play connectivity
• Business-friendly and easy-to-use web browser-based management GUI
• VLAN support for traffic segmentation
• Quality of Service (QoS) for traffic prioritization
• Auto "denial-of-service" (DoS) prevention
• Troubleshoot connection issues via cable test
• Loop prevention, loop detection, and broadcast storm controls
• Rate limiting for better bandwidth allocation
• Port mirroring for network monitoring
• Jumbo frame support
• Advanced features such as per port PoE controls
• Uninterrupted PoE keeps PoE power on even when the switch is updating firmware or performing software reboot.
• 802.3at standard offering 30W/port
• Fanless and versatile mounting option (desktop and wall-mountable)
Highlights
Effectively reduces downtime with improved network performance
Quickly and easily set up a wired network with 15 networking ports
Can work as layer 3 routing for scalable network design
Desktop form factor for your convenience and simplicity of usage
Gigabit Ethernet port for ultra-fast network speeds
Twisted Pair media support ensures maximum convenience and great usability
Specifications
Package Contents
16-Port High-Power PoE+ Gigabit Ethernet Plus Switch (231W) with 1 SFP Port
Power Adapter (Power Cable Varies by Region)
Wall Installation Kit
Rubber Feet
Installation Guide
Product Type
Ethernet Switch
Manufacturer Part Number
GS316EPP-100NAS
Power Source
Power Adapter
Limited Warranty
5 Year Lifetime
Layer Supported
3
Weight (Approximate)
1.95 lb
Form Factor
Desktop, Wall Mountable
Manufacturer
Netgear, Inc
Product Model
GS316EPP
Product Name
16-Port High-Power PoE+ Gigabit Ethernet Plus Switch (231W) with 1 SFP Port
Network Technology
10/100/1000Base-T, 1000Base-X
Product Series
300
Brand Name
Netgear
Expansion Slot Type
SFP (mini-GBIC)
Country of Origin
Thailand
Height
1.1"
Width
11.3"
Depth
4"
Manageable
Yes
Environmentally Friendly
Yes
Ethernet Technology
Gigabit Ethernet
Number of SFP Slots
1
Modular
Yes
Media Type Supported
Twisted Pair
Total Number of Network Ports
15
PoE (RJ-45) Port
Yes
Port/Expansion Slot Details
15 x Gigabit Ethernet HPoE+, 1 x Gigabit Ethernet Expansion Slot
Total Number of Expansion Slots
1.0
PoE Budget
231 W
Energy Efficiency Compliance
Energy-related Products Directive (ErP)
Environmental Compliance
Restriction of Hazardous Substances (RoHS), Waste Electrical and Electronic Equipment Directive (WEEE), Registration, Evaluation, Authorization and Restriction of Chemicals (REACH)
