Genuine Advantech through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.
SKU
EKI-2725F-AE
Category
Switches & Bridges
Overview
The EKI-2725F supports Gigabit Ethernet. The power rating is +12 ~ 48 V DC redundant input design, and is secured with a double protection mechanism: Power Polarity Reverse Protection and an Overload Current Fuse. The former tolerates reverse power wiring while the later secures the system from overload currents. Each port of EKI-2725F has 2 LED's to show the link status transmission speed and collision status. It also provides a relay output for an event alarm. In the event of a power failure, the built-in LED will activate the alarm to notify administrators. Engineers can simply verify the hardware status by checking the LED, which makes troubleshooting quick and easy. EKI-2725F comes with compact metal housing rated at IP30 to protect against dusty industrial environments.
Highlights
Effectively reduces downtime with improved network performance
Quickly and easily set up a wired network with 4 networking ports
Layer 2 switch provides a complete lineup of features including IGMP snooping, port mirroring, and spanning tree
DIN Rail Mountable form factor for your convenience and simplicity of usage
Gigabit Ethernet port for ultra-fast network speeds
Twisted Pair media support for a dependable and productive connectivity
Specifications
Product Type
Ethernet Switch
Manufacturer Part Number
EKI-2725F-AE
Layer Supported
2
Form Factor
DIN Rail Mountable, Wall Mountable
Manufacturer
Advantech Co., Ltd
Product Model
EKI-2725F
Product Name
4 GE + 1 SFP Ind. Unmanaged Switch
Network Technology
10/100/1000Base-T, 1000Base-X
Product Series
EKI-2000
Brand Name
Advantech
Expansion Slot Type
SFP (mini-GBIC)
Country of Origin
Taiwan
Height
5.5"
Width
1.2"
Depth
3.7"
Manageable
No
Ethernet Technology
Gigabit Ethernet
Number of SFP Slots
1
Modular
No
Uplink Port
No
Stack Port
No
Media Type Supported
Twisted Pair, Optical Fiber
Total Number of Network Ports
4
Shared SFP Slot
No
Port/Expansion Slot Details
4 x Gigabit Ethernet Network, 1 x Gigabit Ethernet Expansion Slot
