9 Ports - Gigabit Ethernet - 1000Base-T - 7 W Power Consumption - 95 W PoE Budget - Twisted Pair - PoE Ports - Desktop, Wall Mountable, Compact
$97.30
Special order — estimated OEM lead time 3–8 weeks. Order today and we expect to receive stock between Oct 5 and Nov 9, then process your delivery right after.
Genuine Tenda Technology through authorized distribution — NDAA §889 screened before checkout. TAA verified on request.
Simplified Deployment Easy Networking
In pair with AP, enjoy whole home WiFi easily
• Small size save more space Perfectly adapt to all kinds of weak current boxes
• Standard PoE power supply,no external power needed Plug&play, convenient and elegant wiring
• Whole home WiFi roaming,no signal dead zone Play while walking, smooth game and video anytime
• Ultra-powerful data forwarding,highly perceptable Enjoy faster and more stable network
Ultra-Small Body, Fit for All Kinds of Information/Weak Current Boxes
Based on the design of big house type and enterprise application, the body has been made smaller. It is suitable for all kinds of information and weak current boxes.
Two Modes
Support Router Mode and Controller Mode. It can manage 128 APs in Router Mode and 256 APs in Controller Mode. Automatically discover and manage Tenda APs, as well as centrally configure and manage them. It can work with 86-type in-wall and all kinds of ceiling APs. Easy to install, with no configuration required. Plug and play.
High Power Output
LAN ports support up to standard 8-port PoE power supply, 30W per port, and the power budget is 95W. It doesn't need extra power, and the wiring is simple and convenient.
Gigabit High Speed
With professional network processor, it supports forwarding acceleration, 1000M bandwidth, up to 4 gigabit WAN ports and 8 gigabit LAN ports. Meanwhile, it is able to connect multiple broadband from different operators. Easily handle bandwith access of all rates, and make full use of bandwidth performance.
1 WAN Port+3 Interchangeable WAN/LAN Ports
Support up to 4 WAN ports and broadband lines to connect, doubling the network speed. Based on load balancing, big data packet and key applications, it intelligently chooses the fastest communication path.
Millesecond-Grade Roaming
G0-8G-PoE supports fast roaming. Working with Tende AP 802.11kvr roaminng protocol, WiFi seamless roaming speed is below 50ms. When playing while walking from offices to offices or from downstairs to upstairs, your phone still enjoys high speed network all the time.
APP Remote Management and Maintenance
Log in Tenda WiFi APP, everything is on your hands. You can do network troubleshooting at home, and there is no need to go to the scene.
• Standard PoE Power Supply
• Up to 30W per Port
• Smart Bandwidth Control
• Customized URL Database
| General Information | |
|---|---|
| Manufacturer | Tenda Technology Inc |
| Manufacturer Part Number | G0-8G-POE |
| Brand Name | Tenda |
| Product Model | G0-8G-PoE |
| Product Name | G0-8G-PoE Ethernet Switch |
| Product Type | Ethernet Switch |
| Interfaces/Ports | |
| Total Number of Network Ports | 9 |
| Network (RJ-45) | Yes |
| Port/Expansion Slot Details | 8 × Gigabit Ethernet PoE+ RJ-45 Network Port, 1 x Gigabit Ethernet RJ-45 Network Port |
| Media & Performance | |
| Media Type Supported | Twisted Pair |
| Ethernet Technology | Gigabit Ethernet |
| Network Technology | 1000Base-T |
| Maximum Data Transfer Rate | 125 MB/s |
| Network & Communication | |
| Networking Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3x, IEEE 802.3af, IEEE 802.3at |
| Physical Characteristics | |
| Product Material | Galvanized Cold Rolled Steel (SGCC) |
| Form Factor | Desktop, Wall Mountable, Compact |
| Height | 1" |
| Width | 4.1" |
| Length | 7" |
| Weight (Approximate) | 14.50 oz |
| Power Description | |
| PoE (RJ-45) Port | Yes |
| PoE Budget | 95 W |
| Input Voltage | 51 V DC |
| Power Source | DC, Power Adapter, PoE+ |
| Power Consumption | 7 W |
| Technical Information | |
| Features | Reset Button, Plug and Play |
| Miscellaneous | |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
