2 Ports - Manageable - 40 Gigabit Ethernet, 100 Gigabit Ethernet - 40GBase-X, 100GBase-X - 3 Layer Supported - 293 W Power Consumption - Twisted Pair, Optical Fiber - 1U - Rack-mountable, Standalone - 3 Year Limited Warranty
$10,512.44
Special order — estimated OEM lead time 3–8 weeks. Order today and we expect to receive stock between Oct 5 and Nov 9, then process your delivery right after.
Genuine Quanta Computer, lnc through authorized distribution — NDAA §889 screened before checkout. TAA verified on request.
The Next Wave 100G Ethernet Switch for Data Center and Cloud
Data center networks face the changes with hardware and meet the requirements of the software it hosts. Quanta Cloud Technology provides a series of Ethernet Switches, the QCT QuantaMesh switch product line, that addresses these changes and provides the advanced features that meet the demands for the contemporary data center applications. The QCT QuantaMesh product lines provide the connections from 1G to 100Gbps speeds on its Ethernet Switches. To meet the requirements of high performance, high availability, fast scale out, low latency performance, and continuous serviceability for data center applications. The QCT QuantaMesh Ethernet Switch product line supported with QNOS (Quanta Network OS) to provide the advanced features, which is the best choice for Data Center application.
QCT T7032-IX7D is a high-performance and low latency layer 3 managed switches deployed as the Data Center Leaf Switch to connect to 100G servers or deployed as Data Center Spine Switch to aggregate 100G connections from Leaf Switches to expend the network scalability. T7032-IX7D supports 32 QSFP28, each supporting 1 x 100GbE or 1 x 40GbE, or via breakout cables, 2 x 50GbE, 4 x 25GbE, or 4 x 10GbE. It equipped with BMC in a 1-Rack-Unit (1RU) switch and supports 3.2 Terabits per second (Tbps) of bandwidth. By levering merchant silicon chip, T7032-IX7D is a high performance and high density Ethernet switch with advanced features such as smart table, dynamic load balancing, and VxLAN/RIOT support. T7032-IX7D also support larger tables size, improves the performance for larger packet buffers and reduced the latency. With QNOS (Quanta Network OS) supported, T7032-IX7D is the best fit for Data Center application.
Limited Warranty: 3 Year
| General Information | |
|---|---|
| Manufacturer | Quanta Computer, lnc |
| Manufacturer Part Number | 1IX7U7Z0002 |
| Brand Name | Quanta |
| Product Line | QuantaMesh |
| Product Model | T7032-IX7D |
| Product Name | QuantaMesh T7032-IX7D Ethernet Switch |
| Product Type | Ethernet Switch |
| Interfaces/Ports | |
| Total Number of Network Ports | 2 |
| Network (RJ-45) | Yes |
| Port/Expansion Slot Details | 32 x 40/100 Gigabit Ethernet QSFP28 Expansion Slot, 1 x RJ-45 Console Port, 1 x USB 2.0 Port, 1 x Gigabit Ethernet RJ-45 Management Port |
| Management & Protocols | |
| Manageable | Yes |
| Media & Performance | |
| Media Type Supported | Twisted Pair, Optical Fiber |
| Ethernet Technology | 40 Gigabit Ethernet, 100 Gigabit Ethernet |
| Network Technology | 40GBase-X, 100GBase-X |
| Fiber Optic Cable Wavelength | 1310 nm, 850 nm |
| Maximum Data Transfer Rate | 12.50 GB/s |
| Network & Communication | |
| Layer Supported | 3 |
| Networking Standards | IEEE 802.1w, IEEE 802.1s, IEEE 802.1Q, IEEE 802.1ad, IEEE 802.3ad, IEEE 802.1p, IEEE 802.1ab, IEEE 802.1Qbb |
| Physical Characteristics | |
| Product Material | Metal |
| Compatible Rack Unit | 1U |
| Form Factor | Rack-mountable, Standalone |
| Height | 1.7" |
| Width | 17.3" |
| Depth | 20" |
| Weight (Approximate) | 20.57 lb |
| Power Description | |
| Input Voltage | 120 V AC, 230 V AC |
| Power Source | Power Supply, AC |
| Number of Power Supplies Installed | 2 |
| Power Consumption | 293 W |
| Technical Information | |
| Features | Zero-Touch Provisioning (ZTP) |
| Warranty | |
| Limited Warranty | 3 Year |
| I/O Expansions | |
| Total Number of Expansion Slots | 32 |
| Expansion Slot Type | QSFP28 |
| Miscellaneous | |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) 6 |
