Genuine Quanta Computer, lnc through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.
SKU
1IX1UZZ0STH
Category
Switches & Bridges
Overview
Data center networks face changes with hardware and meeting the requirements of the software it hosts. Quanta Cloud Technology provides a series of Bare Metal Switches, the QantaMesh BMS product line, that addresses these changes in the data center market. The QuantaMesh BMS product lines support speeds up to 100G speeds on their Ethernet Switches. To meet the requirements of high performance, high availability, fast scale out, low latency performance, and continuous serviceability in data center applications, the QuantaMesh BMS product line is the best choice.
BMC (Baseboard Management Controller) embedded on the server as the core of the Intelligent Platform Management Interface (IPMI) architecture can now be implemented in the Ethernet switch. In addition to providing health monitoring of the temperature, power status, and cooling fans; BMC also aids in the deployment and management of software and hardware peripherals.
QuantaMesh T7032-IX1 supports 32 QSFP28 (10/25/40/50/100GbE speed) ports and QuantaMesh T7032-IX1B supports 32 QSFP28 (10/25/40/50/100GbE speed) ports and is equipped with BMC in a compact rack unit size. By leveraging merchant silicon chipsets, the T7032-IX1 and T7032-IX1B provides a high performance, high-density Ethernet switch at an affordable price. With ONIE (Open Network Installation Environment) pre-loade, the T7032-IX1 and T7032-IX1B can be used with multiple operating system that support ONIE installers to achieve agile installation and fast response as demands change.
Warranty
Limited Warranty: 3 Year
Highlights
ONIE Pre-loaded
x86 CPU Board Support
ONL Ready
OF-DPA Ready
BMC Built-in
Cumulus Linux Ready
Specifications
General Information
Manufacturer
Quanta Computer, lnc
Manufacturer Part Number
1IX1UZZ0STH
Brand Name
QCT
Product Line
QuantaMesh
Product Model
T7032-IX1B
Product Name
Next-Generation 100G ToR/Spine Switch for Data Center and Cloud Computing
Product Type
Ethernet Switch
Interfaces/Ports
Modular
Yes
Stack Port
No
Port/Expansion Slot Details
32 x 100 Gigabit Ethernet Expansion Slot
Management & Protocols
Manageable
Yes
Media & Performance
Media Type Supported
Optical Fiber
Ethernet Technology
100 Gigabit Ethernet
Network Technology
100GBase-X
Network & Communication
Layer Supported
2
Physical Characteristics
Form Factor
Rack-mountable, Rail-mountable
Height
1.7"
Width
17.3"
Depth
20"
Weight (Approximate)
20.75 lb
Power Description
Power Source
Power Supply
Redundant Power Supply Supported
Yes
Warranty
Limited Warranty
3 Year
I/O Expansions
Total Number of Expansion Slots
32.0
Expansion Slot Type
QSFP28
Shared SFP Slot
No
Miscellaneous
Package Contents
Next-Generation 100G ToR/Spine Switch for Data Center and Cloud Computing
Rail Kit
Environmentally Friendly
Yes
Environmental Compliance
Restriction of Hazardous Substances (RoHS), China Restriction of Hazardous Substances (China RoHS), Waste Electrical and Electronic Equipment Directive (WEEE)
