Alpine AL-324 Quad-core (4 Core) 1.70 GHz - 4 x HDD Supported - 0 x HDD Installed - 4 x SSD Supported - 0 x SSD Installed - 2 GB RAM DDR4 SDRAM - Serial ATA/600 Controller - RAID Supported - 0, 1, 5, 6, 10, Hot Spare, JBOD RAID Levels - 4 x Total Bays - 4 x 2.5"/3.5" Bay - 3 x Total Slot(s) - 10 Gigabit Ethernet - 4 USB Port(s) - Network (RJ-45) - TCP/IP, IPv4, IPv6, DHCP, NAT, STP, DDNS, HTTP, HTTPS, WEBDAV, SSL, ... - 512 MB Flash Memory Capacity - 1U - Rack-mountable
$961.07
Special order — estimated OEM lead time 3–8 weeks. Order today and we expect to receive stock between Dec 9, 2026 and Jan 13, 2027, then process your delivery right after.
Genuine QNAP Systems through authorized distribution — NDAA §889 screened before checkout. TAA verified on request.
Country of origin is manufacturer-reported and can vary by production lot. Where TAA applies to your purchase, we verify the shipping unit's origin on request.
Quad-core 1.7GHz rackmount NAS with dual 10GbE SFP+ and dual 2.5GbE ports for SMB IT environments
With 10GbE SFP+ and 2.5GbE network ports, the TS-432PXU delivers high network bandwidth to streamline team collaboration and file access. A PCIe Gen 2 ×2 slot allows for installing a QNAP expansion card to add network connectivity, SSD caching capabilities, or wireless connectivity. The TS-432PXU supports file backup and synchronization, secure snapshot protection, and Google G Suite and Microsoft 365® enterprise account backup services, while providing instant recovery whenever needed. Coupled with the support for cloud gateways, building a hybrid cloud storage solution has never been easier.
• Two 10GbE SFP+ and two 2.5GbE RJ45 network ports accelerate file sharing.
• HBS (Hybrid Backup Sync) backs up and syncs data to other NAS, servers and cloud storage for comprehensive disaster recovery planning.
• Boxafe provides an extra layer of protection by backing up emails, cloud drives, contacts, and calendars of Google G Suite and Microsoft 365®.
• Snapshots fully record system status and data, allowing you to protect files and data from accidental deletion and malware attacks.
• Expand the application potential of the TS-432PXU by installing a compatible PCIe card.
• Increase the storage capacity of the TS-432PXU with QNAP TR RAID expansion enclosures or TL JBOD.
Higher performance x faster throughput
The TS-432PXU is powered by an Annapurna Labs Alpine AL-324 ARM® Cortex®-A57 quad-core 1.7 GHz processor with 2GB DDR4 RAM (expandable to 16GB) and SATA 6Gb/s drives to deliver higher performance. With two 10GbE SFP+ and two 2.5GbE network ports, the TS-432PXU provides incredible bandwidth to fulfil high-speed file access, backup/restoration and media transfer, while also allowing the flexible allocation of network resources for individual applications and services.
Upgrade your network to increase team efficiency
QNAP provides various high-speed network solutions at attainable price points. The QSW network switches provide managed and unmanaged 10GbE and 2.5GbE options for building high-speed networks. QNAP also offers 10GbE / 5GbE / 2.5GbE network expansion cards and a USB to 5GbE adapter for Windows® / Linux® devices, allowing all of your workstations to take advantage of high-speed networks.
Boost NAS performance with SSDs
As SSDs become more affordable, using SSDs on NAS can improve performance without requiring a heavy investment. The TS-432PXU supports SSD cache technology, Qtier auto-tiering storage, and SSD over-provisioning, helping you to balance storage performance, storage allocation, and IT expenses.
Balance performance and capacity Boost NAS performance by enabling SSD caching. Coupled with Qtier auto-tiering technology, you can find the perfect storage configuration between high-performance SSD and high-capacity HDD while balancing performance and cost.
Learn more?SSD caching, Qtier auto-tiering
Extend SSD lifespan SSD Extra Over-provisioning allows for adding 1~60% reserved space to avoid performance degradation, helping to increase system stability and extend SSD lifespan.
Limited Warranty: 2 Year
| Controllers | |
|---|---|
| Controller Type | Serial ATA/600 |
| RAID Supported | Yes |
| RAID Levels | 0, 1, 5, 6, 10, Hot Spare, JBOD |
| General Information | |
| Manufacturer | QNAP Systems |
| Manufacturer Part Number | TS-432PXU-2G-US |
| Brand Name | QNAP |
| Product Series | TS-x32PXU |
| Product Model | TS-432PXU-2G |
| Product Name | TS-432PXU-2G SAN/NAS Storage System |
| Product Type | SAN/NAS Storage System |
| I/O Expansions | |
| Number of Total Expansion Bays | 4 |
| Number of 2.5"/3.5" Bays | 4 |
| Total Number of Expansion Slots | 3 |
| Expansion Slot Type | PCI Express 2.0 x2, SFP+ |
| Interfaces/Ports | |
| Total Number of USB Ports | 4 |
| Number of USB 3.2 Gen 1 Ports | 4 |
| Network (RJ-45) | Yes |
| Number of Network (RJ-45) Ports | 2 |
| Management & Protocols | |
| Protocols | TCP/IP, IPv4, IPv6, DHCP, NAT, STP, DDNS, HTTP, HTTPS, WEBDAV, SSL, SSH, Telnet, FTP, CIFS/SMB, AFP, iSCSI, SMTP, SNMP, NFS, SFTP, TFTP, SSL/TLS, FXP, MTP, RSync, RTSP, PPTP, L2TP, IPSec, UPnP |
| Memory | |
| Standard Memory | 2 GB |
| Memory Technology | DDR4 SDRAM |
| Network & Communication | |
| Ethernet Technology | 10 Gigabit Ethernet |
| Physical Characteristics | |
| Height | 1.7" |
| Width | 17.3" |
| Depth | 19.6" |
| Form Factor | Rack-mountable |
| Rack Height | 1U |
| Weight (Approximate) | 14.40 lb |
| Power Description | |
| Maximum Power Supply Wattage | 250 W |
| Processor & Chipset | |
| Processor Type | Alpine |
| Processor Model | AL-324 |
| Processor Core | Quad-core (4 Core) |
| Processor Speed | 1.70 GHz |
| Storage | |
| Number of Hard Drives Supported | 4 |
| Number of Hard Drives Installed | 0 |
| Number of Solid State Drive Supported | 4 |
| Number of Solid State Drive Installed | 0 |
| Flash Memory Capacity | 512 MB |
| Warranty | |
| Limited Warranty | 2 Year |
| Miscellaneous | |
| Package Contents |
|
| Country of Origin | Taiwan |
