Pepwave SD Ethernet Switch
16 Ports - Manageable - Gigabit Ethernet - 10/100/1000Base-T, 1000Base-X - 3 Layer Supported - Modular - 2 SFP Slots - 20 W Power Consumption - 240 W PoE Budget - Optical Fiber, Twisted Pair - PoE Ports - 1U - Rack-mountable - 1 Year Limited Warranty
- SKU
- PSW-16-240W-RUG
- Category
- Switches & Bridges
$805.39
Back ordered — ships when restocked.
Genuine Peplink through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.
- SKU
- PSW-16-240W-RUG
- Category
- Switches & Bridges
Overview
Simplified LAN Management
No more command lines. Use InControl 2 cloud management to remotely monitor, troubleshoot, and configure your network:
Monitor: Port status, connectivity, firmware version.
Troubleshoot: See all clients, search by MAC address.
Configure: Centralize VLAN, firmware, and configurations.
Ready for Any Environment
The SD-Switch Rugged can handle -40°F (-40°C) to 149°F (65°C). The fanless design enables it to function in high-particle environments .
Highlights
- PoE+ Output
- Out-Of-Band Management
Specifications
| Package Contents |
|
|---|---|
| Product Type | Ethernet Switch |
| Input Voltage | 12 V DC, 56 V DC |
| Manufacturer Part Number | PSW-16-240W-RUG |
| Power Source | Power Adapter |
| Limited Warranty | 1 Year |
| Layer Supported | 3 |
| Weight (Approximate) | 4.41 lb |
| Features | Fanless |
| Form Factor | Rack-mountable |
| Length | 7.5" |
| Manufacturer | Peplink |
| Product Name | SD Ethernet Switch |
| Network Technology | 10/100/1000Base-T, 1000Base-X |
| Power Consumption | 20 W |
| Product Series | SD |
| Brand Name | Pepwave |
| Plug/Connector Type | DIN |
| Expansion Slot Type | SFP |
| Height | 1.4" |
| Width | 8.9" |
| Manageable | Yes |
| Environmentally Friendly | Yes |
| Compatible Rack Unit | 1U |
| Number of Power Supplies Installed | 2 |
| Ethernet Technology | Gigabit Ethernet |
| Network (RJ-45) | Yes |
| Number of SFP Slots | 2 |
| Modular | Yes |
| Media Type Supported | Optical Fiber, Twisted Pair |
| Total Number of Network Ports | 16 |
| PoE (RJ-45) Port | Yes |
| Port/Expansion Slot Details | 8 x Gigabit Ethernet PoE+, 2 x Gigabit Ethernet Expansion Slot, 8 x Gigabit Ethernet Network Port |
| Total Number of Expansion Slots | 2.0 |
| Redundant Power Supply Supported | Yes |
| PoE Budget | 240 W |
| Networking Standards | IEEE 802.3at |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
