Netgear 36x10G/Multi-Gig PoE++ (280W base, up to 1,760W) and 4xSFP28 25G Managed Switch
Netgear

Netgear 36x10G/Multi-Gig PoE++ (280W base, up to 1,760W) and 4xSFP28 25G Managed Switch

36 Ports - Manageable - 10 Gigabit Ethernet, 25 Gigabit Ethernet - 10GBase-T, 25GBase-X - 3 Layer Supported - Modular - 148 W Power Consumption - 1760 W PoE Budget - Twisted Pair, Optical Fiber - PoE Ports - 1U - Table Top, Desktop, Rack-mountable - Lifetime Limited Warranty

SKU
XSM4340CV-100NES
Category
Switches & Bridges

MSRP$10,392.57

$7,088.48

Save 32%
Back ordered

Back ordered — ships when restocked.

Get a quote

Genuine Netgear through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.

SKU
XSM4340CV-100NES
Category
Switches & Bridges

Overview

POWER AND THROUGHPUT

Edge to core stackable platform, from 1 Gigabit to 100 Gigabit, all within 15.75in (40cm) of depth.

Groundbreaking AV GUI

A simplified user interface makes it easy to assign configuration profiles to each port.

Multicast in an Instant

NETGEAR IGMP Plus? provides multicast functionality right out of the box for most AV over IP applications.

Sleek, Quiet Design

Less fan noise, and mounting ears included for rack mounting.

Automatic Configuration

Auto-trunk and auto-LAG functionality auto connects with other M4350 (and M4250) switches.

FAST, EASY CONFIGURATION FOR AV PROS

A streamlined interface enables factory default AV settings or user-specified AV profiles to be assigned to individual ports with just a few clicks.

FOCUS ON THE EVENT NOT FAN NOISE

Most models have quiet mode which greatly reduces fan noise.

DESIGNED FOR AV OVER IP RIGHT OUT OFTHE BOX

With built-in NETGEAR IGMP Plus?, there's little-to-no setup required for flawless Video over IP delivery. Enable multicasting right out of the box.

MAXIMIZE PERFORMANCE WITH PRO WIFI ACCESS POINTS

Enable powerful, reliable WiFi at your location with Pro WiFi access points, powered by PoE or an external power adapter.

PRO AV RESOURCES

? All the resources you need to learn about NETGEAR AV over IP solutions, including family brochures, product data sheets, tech tips and more.

Highlights

  • 36 10G/Multi-Gig PoE++ ports with 4 25GBASE-X SFP28 uplinks
  • 750W internal power supply providing 280W of PoE budget
  • 1 slot for modular power supply (1+1 redundancy and/or EPS share)
  • Any APS600Wv3, APS1200Wv2, or APS2000Wv2 can be used
  • The PoE budget can reach 1,760W, when the redundant PoE budget remains 280W
  • Virtual Chassis stacking provides non-stop forwarding (NSF) and hitless failover
  • Layer 3 feature set includes static, policy-based, and dynamic routing
  • NETGEAR IGMP Plus?, AV User Interface, and Engage Controller speed up AV installations
  • NETGEAR ProSAFE<sup>® </sup>Limited Lifetime Hardware Warranty
  • Lifetime Next Business Day Hardware Replacement

Specifications

Package Contents
  • 36x10G/Multi-Gig PoE++ (280W base, up to 1,760W) and 4xSFP28 25G Managed Switch
  • 1 x Power Cord(s)
  • 1 x Console USB Type-C Cable
  • 1 x Rack-mounting Standard Bracket Set
  • 1 x Set of Longer Brackets for Recessed Mounting
  • 4 x Rubber Footpads for Tabletop Installation
  • 1 x Installation Guide
Product TypeEthernet Switch
Input Voltage120 V AC, 230 V AC
Manufacturer Part NumberXSM4340CV-100NES
Power SourcePower Supply
Limited WarrantyLifetime
Layer Supported3
Weight (Approximate)16.16 lb
Form FactorTable Top, Desktop, Rack-mountable
ManufacturerNetgear, Inc
Product Name36x10G/Multi-Gig PoE++ (280W base, up to 1,760W) and 4xSFP28 25G Managed Switch
Network Technology10GBase-T, 25GBase-X
Power Consumption148 W
Product SeriesM4350
Brand NameNetgear
Plug/Connector TypeC14
Expansion Slot TypeSFP28
Height1.7"
Width17.3"
Depth15.7"
ManageableYes
Compatible Rack Unit1U
Number of Power Supplies Supported2
Number of Power Supplies Installed1
Ethernet Technology10 Gigabit Ethernet, 25 Gigabit Ethernet
Network (RJ-45)Yes
ModularYes
Uplink PortYes
Media Type SupportedTwisted Pair, Optical Fiber
Total Number of Network Ports36
PoE (RJ-45) PortYes
Port/Expansion Slot Details36 x 10 Gigabit Ethernet Expansion Slots, 8 x 25 Gigabit Ethernet Expansion Slots
Total Number of Expansion Slots4
Redundant Power Supply SupportedYes
PoE Budget1760 W
Networking StandardsIEEE 802.3af, IEEE 802.3at, IEEE 802.3bt
