Full Xeon Speed Ahead! Extremely efficient and stable - Your next enterprise virtualization and storage solution
$2,772.77
Special order — estimated available by September 10, 2026.
Genuine ASUSTOR through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.
Intel Xeon Quad-Core CPU
The Lockerstor 10 Pro features a powerful Intel 9th generation Xeon with four cores. Not only is the Xeon extremely fast in both read and write speeds, but also lends incredible performance to virtual machines and Docker apps.
Powerful Hardware and Top flight performance
Intel Xeon 9th generation Quad-Core CPU.
Supports DDR4-2666 ECC RAM.
Dual M.2 NVMe SSD ports for fast caching.
Brings the smoothest work experience with 10-Gigabit Ethernet, triple 2.5-Gigabit ports and USB 3.2 Gen2 ports.
Supports Wake on LAN on 2.5-Gigabit Ethernet ports
360° Backup solution and enterprise virtualization application
• MyArchive cold storage backups
• Snapshot Center, Cloud Backup Center, DataSync Center
• Complete iSCSI/IP-SAN and NFS support
• VMware, Citrix and Hyper-V ready
• Supports virtualization and Docker apps
10-Gigabit and Triple 2.5-Gigabit ports. Extreme speeds.
The all new Lockerstor 10 Pro NAS features a powerful Aquantia 10-Gigabit Ethernet port as well as triple Aquantia 2.5-Gigabit Ethernet ports. With a managed switch that supports multiple speeds, take advantage of up to 10 Gbps of speed on the 10-Gigabit port or up to 7.5 Gbps on all 2.5-Gigabit ports.
Server-grade ECC memory
ECC memory is memory usually used in servers for detection and correction of the most common kinds of data corruption. This can help prevent data loss due to electromagnetic interference or crashes, making the Lockerstor 10 Pro our most stable NAS ever.
Ten Bays with Two M.2 SSD Slots for Flexible Cached Storage
The Lockerstor 10 Pro is a cost-effective high capacity NAS designed for enterprise environments. The Lockerstor 10 Pro is flexible, supporting online capacity expansion and replacement. Online capacity expansion enables you to replace hard drives inside the NAS without downtime. If your budget and/or storage requirements are small, the Lockerstor 10 Pro enables your NAS to grow alongside your needs by first purchasing smaller drives and then add more drives as you need. Additional drives can be purchased as your storage requirements grow and all drives can be fully replaced while continuing to use your NAS. Combining this with ASUSTOR's MyArchive cold storage technology enables you to store a virtually unlimited amount of information.
SSD Cache
SSD caching on the Lockerstor 10 Pro brings SSD-like speeds to regular hard drives. Turbocharge your NAS by adding one or two SSDs to the M.2 slots inside your Lockerstor 10 Pro. Read and write files at speeds of over 1100 MB/s and watch as even big files are transferred over in seconds.
More from the Manufacturer
Intel Xeon Quad-Core CPU
Powerful Hardware and Top flight performance
Combine Multiple Business Cloud Services
10-Gigabit and Triple 2.5-Gigabit ports
Intel Xeon Quad-Core CPU
The Lockerstor 10 Pro features a powerful Intel 9th generation Xeon with four cores. Not only is the Xeon extremely fast in both read and write speeds, but also lends incredible performance to virtual machines and Docker apps.
10-Gigabit and Triple 2.5-Gigabit ports. Extreme speeds.
The all new Lockerstor 10 Pro NAS feature a powerful Aquantia 10-Gigabit Ethernet port as well as triple Aquantia 2.5-Gigabit Ethernet ports. With a managed switch that supports multiple speeds, take advantage of up to 10 Gbps of speed on the 10-Gigabit port or up to 7.5 Gbps on all 2.5-Gigabit ports.
SSD Speeds for Hard Drive Prices - SSD Caching
SSD caching on the Lockerstor 10 Pro brings performance of hard drives, even if only using a few hard drives can increase performance to SSD-like speeds.
Product feature
Snapshot Center
Snapshot Center is a new feature for ASUSTOR NAS devices to utilize Btrfs and iSCSI volumes to take snapshots of the information inside a NAS. Snapshot Center supports up to 256 snapshots of a volume and can be done every five minutes, creating a backup that can be restored easily if data is damaged or lost.
Thumbscrews for easy M.2 SSD installation
Regular screws are difficult to handle.
Thumbscrews are easier to manipulate
Two M.2 2280, 2260 or 2242 slots supporting NVMe and AHCI SSDs
Server-grade ECC memory
ECC memory is memory usually used in servers for detection and correction of the most common kinds of data corruption. This can help prevent data loss due to electromagnetic interference or crashes, making the NAS the Lockerstor 10 Pro our most stable NAS ever.
Wake Up From Anywhere
The Lockerstor 10 Pro feature Wake on WAN technology. No specialized equipment or settings are needed to wake the NAS. Simply use ASUSTOR’s wide variety of mobile apps, including but not limited to AiMaster, AiMusic, AiVideos and AiData to turn the NAS on or off remotely. Wake on WAN helps protect data by keeping the NAS powered off when not in use; thereby helping to prevent attacks, protects data integrity by remaining powered off during power failures and Wake on WAN also saves electricity, making for an even more efficient NAS.
Protected From Ransomware
The Lockerstor 10 Pro comes with the most up-to-date version of ADM to help protect against ransomware attacks. With Snapshot Center and Btrfs providing efficient snapshots to easily restore lost data. Other security features found on the Lockerstor are the ability to create one or more replacement administrator accounts, a firewall by ADM Defender that features black and white lists and the ability to change default ports, disable SSH and Terminal to prevent remote attacks. MyArchive cold storage hard drive security can also be increased by implementing AES 256bit encryption.The AiDownload mobile App allows you to use your mobile device to search, add and manage your download tasks while on the go. BitTorrent downloads have never been this convenient.
Cross-Platform Multi-User Access
The ASUSTOR NAS provides seamless cross-platform and multi-user access, allowing you to easily connect to your NAS from Windows, Mac OS X or Unix-like operating systems no matter if you are using a PC, notebook, tablet or smartphone.
Enterprise Versatility
ASUSTOR NAS offers rich variety of services for business users. For the efficiencies of one NAS you can create a multifunctional server that is worth much more.
Comprehensive Backup Solutions
ASUSTOR’s comprehensive backup solution provides more than twelve backup options, including, but not limited to Amazon S3, Dropbox, Google Drive, and Onedrive. ASUSTOR Backup Plan for Windows as well as Time Machine for macOS provide easy backups for desktop and laptops while MyArchive removable hard drives provide long term storage. Btrfs is now supported and with Snapshot Center, can take snapshots of your information in the event of unintentional modification. Restore previous versions easily with Snapshot Center.
Limited Warranty: 5 Year
About ASUSTOR Founded in 2011, ASUSTOR Inc. was established via direct investment from ASUSTeK Computer Inc . The ASUSTOR brand name was created as a portmanteau of “ASUS” and “Storage”. ASUSTOR is a leading innovator and provider of private cloud storage (network attached storage) and video surveillance (network video recorder) solutions, also specializing in the development and integration of related firmware, hardware and applications. We are devoted to providing the world with an unparalleled user experience and the most complete set of network storage solutions possible. Company Culture At ASUSTOR we believe that our employees are our most treasured assets. We encourage creativity and welcome different voices and ideas. We are committed to creating a diverse, welcoming, happy and energetic work environment, providing a flexible space that allows you to employ your creativity and discover your potential. At ASUSTOR you will be able to see our staff's unmatched devotion to the design of network attached storage (NAS), crafting products with a unique blend of hardware and software integration. Our mission is to launch an international brand and to become a global leader in digital storage. Join us for a chance to work with the leading talents in the field, while receiving ample opportunities to display your abilities and grow together with the company.
| Controllers | |
|---|---|
| Controller Type | Serial ATA/600 |
| RAID Supported | Yes |
| RAID Levels | 0, 1, 5, 6, 10, JBOD |
| General Information | |
| Manufacturer | ASUSTOR |
| Manufacturer Part Number | AS7110T |
| Brand Name | ASUSTOR |
| Product Line | Lockerstor 10 Pro |
| Product Model | AS7110T |
| Product Name | Lockerstor 10 Pro AS7110T SAN/NAS Storage System |
| Packaged Quantity | 1 |
| Product Type | SAN/NAS Storage System |
| I/O Expansions | |
| Number of Total Expansion Bays | 10 |
| Number of 2.5"/3.5" Bays | 10 |
| Interfaces/Ports | |
| HDMI | No |
| Total Number of USB Ports | 3 |
| Number of USB 3.2 Gen 1 Ports | 1 |
| Number of USB 3.2 Gen 2 Ports | 2 |
| Network (RJ-45) | Yes |
| Number of Network (RJ-45) Ports | 4 |
| Management & Protocols | |
| Protocols | IMAP, IPSec, TCP/IP, SMTP, HTTPS, LDAP, L2TP, SFTP, UDP, SSH, CHAP, FTPS, AFP, RTSP, FTP, SMB 2.0, IPv4, PAP, WEBDAV, SSL, iSCSI, SNMP, TLS, HTTP, TFTP, NFS, UPnP, RSync, POP3, DDNS, CIFS/SMB, IPv6, PPTP |
| Memory | |
| Standard Memory | 8 GB |
| Memory Technology | DDR4 SDRAM |
| Network & Communication | |
| Ethernet Technology | 10 Gigabit Ethernet, 2.5 Gigabit Ethernet |
| Physical Characteristics | |
| Height | 8.5" |
| Width | 11.5" |
| Depth | 9.1" |
| Form Factor | Desktop |
| Weight (Approximate) | 15.65 lb |
| Power Description | |
| Number of Power Supplies Installed | 1 |
| Maximum Power Supply Wattage | 350 W |
| Redundant Power Supply | No |
| Processor & Chipset | |
| Processor Manufacturer | Intel |
| Processor Type | Xeon |
| Processor Model | E-2224 |
| Processor Core | Quad-core (4 Core) |
| Processor Speed | 3.40 GHz |
| Software | |
| Operating System | ADM 3.5 |
| Storage | |
| Number of Hard Drives Supported | 10 |
| Number of Hard Drives Installed | 0 |
| Number of Solid State Drive Supported | 10 |
| Number of Solid State Drive Installed | 0 |
| Flash Memory Capacity | 8 GB |
| Warranty | |
| Limited Warranty | 5 Year |
| Miscellaneous | |
| Package Contents |
|
