Shift into overdrive with dual Intel 10GbE, M.2 SSD Cache and 2.5GbE!
$1,555.18
Special order — estimated available by September 10, 2026.
Genuine ASUSTOR through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.
Dual 10 and 2.5 Gigabit ports. Faster than ever.
The all new Lockerstor series of NAS feature dual Intel 10-Gigabit Ethernet ports as well as dual Realtek 2.5-Gigabit Ethernet ports. With a managed switch that supports multiple speeds, take advantage of up to 20 gbps of speed with both 10-Gigabit ports or up to 5 gbps on both 2.5-Gigabit ports.
SSD Cache
The recently updated ADM features an updated Linux Kernel and additional performance enhancements. The Lockerstor series introduce M.2 PCIe NVMe SSD caching increasing performance.
1. Lockerstor NVMe SSD caching increases performance by up to 60%.
2. Lockerstor NVMe SSD caching is faster than if all bays were filled with SATA SSDs while remaining cheaper.
With dual 10-Gigabit Ethernet, bottlenecks on NVMe SSDs have been lifted, making the Lockerstor one of the fastest NAS devices ever.
Ten Bay with M.2 SSD Cache flexible storage
The AS6510T is a cost-effective large capacity NAS designed for enterprise environments.The AS6510T supports online capacity expansion, allowing for the flexible purchase of enterprise storage equipment. When your budget and storage requirements are smaller, you can purchase a smaller number of hard disks. Additional disks can be purchased as your storage requirements grow. Combined with ASUSTOR's MyArchive storage technology, this allows you to effectively achieve unlimited storage.
Powerful and high efficient cooling design
The Lockerstor utilizes PWM fans with smart speed controls and heatsinks with push-pin mounting to achieve optimal airflow, enhancing stability and maintaining high performance even under high loads.
The Lockerstor's improved design features improved heatsinks that are taller than previous models to ensure even more efficient cooling and heat dissipation.
Easily upgrade memory by opening the chassis.
The Lockerstor comes with 8 Gigabytes of DDR4 RAM and can be upgraded up to 32GB. DDR4 RAM provides up to 30% greater performance than DDR3 while also lowering energy requirements by 40%.
24/7 Reliability and Durability
All ASUSTOR NAS are designed for and are suitable for 24/7 use. ASUSTOR NAS devices have also undergone rigorous tests, such as drop tests and burn tests to test durability in extreme conditions. Heatsinks were added to sensitive components to dissipate heat, helping to maintain the longevity of the device.
Protected From the Inside and Out
Protect your data from loss, damage and attacks with the Lockerstor 10. A Lockerstor is better protected by running the Linux-based ADM, employing a built-in firewall, ClamAV Antivirus, MyArchive and ADM's various backup tools help protect ransomware even better.
More from the Manufacturer
Smallest Enterprise Intel 10-Gigabit NAS.
SSD Caching
Wake Up From Anywhere
Dual 10 and 2.5 Gigabit ports. Faster than ever.
The all new Lockerstor series of NAS feature dual Intel 10-Gigabit Ethernet ports as well as dual Realtek 2.5-Gigabit Ethernet ports. With a managed switch that supports multiple speeds, take advantage of up to 20 gbps of speed with both 10-Gigabit ports or up to 5 gbps on both 2.5-Gigabit ports.
SSD Speeds for Hard Drive Efficiency - SSD Caching
The recently updated ADM features an updated Linux Kernel and additional performance enhancements. The Lockerstor series introduce M.2 PCIe NVMe SSD caching increasing performance. 1. Lockerstor NVMe SSD caching increases performance by up to 60%. 2. Lockerstor NVMe SSD caching is faster than if all bays were filled with SATA SSDs while remaining cheaper.
Eight Bays with Flexible M.2 SSD Caching
The AS6510T is a cost-effective large capacity NAS designed for enterprise environments. The AS6510T supports online capacity expansion, allowing for the flexible purchase of enterprise storage equipment. When your budget and storage requirements are smaller, you can purchase a smaller number of hard disks. Additional disks can be purchased as your storage requirements grow.
Product feature
Snapshot Center
Snapshot Center is a new feature for ASUSTOR NAS devices to utilize Btrfs and iSCSI volumes to take snapshots of the information inside a NAS. Snapshot Center supports up to 256 snapshots of a volume and can be done every five minutes, creating a backup that can be restored easily if data is damaged or lost.
PC-less Software Installation
Mobile installation with AiMaster takes only 3 steps! Finding your NAS, system initialization and installation, power management, ADM firmware updates, system information and more are all available from the convenience of your mobile device at any time.
Effortless Connections to Your NAS
ADM 3.0 provides easy connections by supporting a new Internet Passthrough function that helps users to simplify previously complex router configurations.
Wake Up From Anywhere
The Lockerstor 8 and 10 feature Wake on WAN technology. No specialized equipment or settings are needed to wake the NAS. Simply use ASUSTOR’s wide variety of mobile apps, including but not limited to AiMaster, AiMusic, AiVideos and AiData to turn the NAS on or off remotely. Wake on WAN helps protect data by keeping the NAS powered off when not in use; thereby helping to prevent attacks, protects data integrity by remaining powered off during power failures and Wake on WAN also saves electricity, making for an even more efficient NAS.
Downloading has never been this convenient
Spending a lot of time fiddling with torrents, trackers and BitTorrent clients? Download Center provides a one stop solution that simplifies the entire download process. Powerful features allow you to easily search for and download the files that you need in the blink of an eye.
The AiDownload mobile App allows you to use your mobile device to search, add and manage your download tasks while on the go. BitTorrent downloads have never been this convenient.
Cross-Platform Multi-User Access
The ASUSTOR NAS provides seamless cross-platform and multi-user access, allowing you to easily connect to your NAS from Windows, Mac OS X or Unix-like operating systems no matter if you are using a PC, notebook, tablet or smartphone.
Enterprise Versatility
ASUSTOR NAS offers rich variety of services for business users. For the efficiencies of one NAS you can create a multifunctional server that is worth much more.
Comprehensive Backup Solutions
ASUSTOR’s comprehensive backup solution provides more than twelve backup options, including, but not limited to Amazon S3, Dropbox, Google Drive, and Onedrive. ASUSTOR Backup Plan for Windows as well as Time Machine for macOS provide easy backups for desktop and laptops while MyArchive removable hard drives provide long term storage. Btrfs is now supported and with Snapshot Center, can take snapshots of your information in the event of unintentional modification. Restore previous versions easily with Snapshot Center.
Limited Warranty: 3 Year
About ASUSTOR Founded in 2011, ASUSTOR Inc. was established via direct investment from ASUSTeK Computer Inc . The ASUSTOR brand name was created as a portmanteau of “ASUS” and “Storage”. ASUSTOR is a leading innovator and provider of private cloud storage (network attached storage) and video surveillance (network video recorder) solutions, also specializing in the development and integration of related firmware, hardware and applications. We are devoted to providing the world with an unparalleled user experience and the most complete set of network storage solutions possible. Company Culture At ASUSTOR we believe that our employees are our most treasured assets. We encourage creativity and welcome different voices and ideas. We are committed to creating a diverse, welcoming, happy and energetic work environment, providing a flexible space that allows you to employ your creativity and discover your potential. At ASUSTOR you will be able to see our staff's unmatched devotion to the design of network attached storage (NAS), crafting products with a unique blend of hardware and software integration. Our mission is to launch an international brand and to become a global leader in digital storage. Join us for a chance to work with the leading talents in the field, while receiving ample opportunities to display your abilities and grow together with the company.
| Controllers | |
|---|---|
| Controller Type | Serial ATA/600 |
| RAID Supported | Yes |
| RAID Levels | 0, 1, 5, 6, 10, JBOD |
| General Information | |
| Manufacturer | ASUSTOR |
| Manufacturer Part Number | AS6510T |
| Brand Name | ASUSTOR |
| Product Line | Lockerstor 10 |
| Product Model | AS6510T |
| Product Name | Lockerstor 10 AS6510T SAN/NAS Storage System |
| Packaged Quantity | 1 |
| Product Type | SAN/NAS Storage System |
| I/O Expansions | |
| Number of Total Expansion Bays | 10 |
| Number of 2.5"/3.5" Bays | 10 |
| Interfaces/Ports | |
| HDMI | No |
| Total Number of USB Ports | 2 |
| Number of USB 3.2 Gen 1 Ports | 2 |
| Network (RJ-45) | Yes |
| Number of Network (RJ-45) Ports | 4 |
| Management & Protocols | |
| Protocols | IMAP, IPSec, TCP/IP, SMTP, HTTPS, LDAP, L2TP, SFTP, UDP, SSH, CHAP, FTPS, AFP, RTSP, FTP, SMB 2.0, IPv4, PAP, WEBDAV, SSL, iSCSI, SNMP, TLS, HTTP, TFTP, NFS, UPnP, RSync, POP3, DDNS, CIFS/SMB, IPv6, PPTP |
| Memory | |
| Standard Memory | 8 GB |
| Memory Technology | DDR4 SDRAM |
| Network & Communication | |
| Ethernet Technology | 10 Gigabit Ethernet, 2.5 Gigabit Ethernet |
| Physical Characteristics | |
| Height | 8.5" |
| Width | 11.5" |
| Depth | 9.1" |
| Form Factor | Desktop |
| Weight (Approximate) | 14.11 lb |
| Power Description | |
| Number of Power Supplies Installed | 1 |
| Maximum Power Supply Wattage | 250 W |
| Redundant Power Supply | No |
| Processor & Chipset | |
| Processor Manufacturer | Intel |
| Processor Type | Atom |
| Processor Model | C3538 |
| Processor Core | Quad-core (4 Core) |
| Processor Speed | 2.10 GHz |
| Software | |
| Operating System | ADM 3.5 |
| Storage | |
| Number of Hard Drives Supported | 10 |
| Number of Hard Drives Installed | 0 |
| Number of Solid State Drive Supported | 10 |
| Number of Solid State Drive Installed | 0 |
| Flash Memory Capacity | 4 GB |
| Warranty | |
| Limited Warranty | 3 Year |
| Miscellaneous | |
| Package Contents |
|
