SIIG 1x8 1080p HDMI Splitter HDbitT over IP Extender Kit - 120m
8 port HDMI over Cat6 Extender Kit- 394ft (120m) - HDMI HDbitT over IP Extender 1 in 8 out - Full HD 1080p - HDCP - One to Many / Many to Many Connection - Over cat6 cable with cascade feature - Support VLAN - IR Extension - Reset Button- Metal Housing - Power/Link/Activity LED Indicator - 2x IR Extension Cable - Wall Mountable - works with Gigabit network switches - Aliminum metal housing - 2 years warranty
- SKU
- CE-H26W11-S1
- Category
- Audio & Video Consoles/Extenders
MSRP$1,299.99
$1,007.50
Save 22%In stock: 10
Genuine SIIG through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.
- SKU
- CE-H26W11-S1
- Category
- Audio & Video Consoles/Extenders
Overview
Extends 1080p HDMI signal up to 394ft over Cat6 cable to up to 8 displays, IR control, works with Gigabit network switches for more displays and extension
• With a single Cat6 cable, you can easily extend HDMI audio/video signals up to 394ft (120m) with our 1x8 HDMI Splitter HDbitT over IP Extender Kit - 120m. Direct 1-to-1 connection, 1-to-Many through Gigabit network switches. Additional receivers, part# CE-H26U11-S1, are sold separately
• Features cascade connection of up to 30 receivers per transmitter. 1-to-many configuration through 1) Unmanaged/Dedicated Gigabit switches, 2) Smart Gigabit switches with VLAN to segregate video traffic from the rest of the LAN. Many-to-many configuration is also supported via VLAN setups. Note that each VLAN can only accommodate 1 transmitter (TX). Note: We recommend using SIIG's 24-port AV Over IP Smart Ethernet Switch, part# CE-SW0111-S1, sold separately
• Delivers crystal clear Full HD content up to 1080p@60Hz resolution. Supports up to 1080p; supports 408i/480p @60Hz, 576i/576p @50Hz, 720p @50/60Hz, 1080i/1080p @50/60Hz; Auto adjustment for different cable lengths to produce the best video/audio experience. Supports 2-channel Stereo Audio. * Note: There's a 250ms or less delay/latency due to data compression. Not recommended for real-time applications, such as PC gaming
• IR remote control through Cat6 cable allow source device to recognize remote commands; You can control the HDMI source device at a secondary location with the included IR cables that forward commands over a Cat6 cable for convenience. We recommend using high performance pure COPPER Cat6 cables to ensure reliable performance
• High quality durable surface mountable metal housing with ventilation panels provides excellent heat dissipation and a higher level of RF/EMI shielding to ensure reliable performance and system stability during long hours of non-stop operation
• Plug-n-Play installation, no software installation required, backed by a 2-year limited warranty
Highlights
- Video Extender Transmitter/Receiver provides efficient and feasible audio/video transmission, decoding, and extending
- 1920 x 1080 maximum video resolution for a vivid, crystal clear display with added productivity
- HDMI in allows convenient transfer of content and data to video extender transmitter/receiver to ensure maximum dependability
- HDMI out enables you to transfer data from your devices to video extender transmitter/receiver with added efficiency
- Twisted pair media type is very easy to connect and can carry both analog and digital data at the same time for maximum connection efficiency
- 1 input devices supported for maximum feasibility and usage convenience
- 8 output devices supported to better accommodate your specific requirements
- 393.70 ft maximum operating distance to allow efficient coverage and maximum usability
- Full HD graphics mode for an immersive and sharp viewing experience
- Wall Mountable form factor for added reliability and dependability
Specifications
| Package Contents |
|
|---|---|
| Product Type | Video Extender Transmitter/Receiver |
| Manufacturer Part Number | CE-H26W11-S1 |
| Limited Warranty | 2 Year |
| Connectivity Technology | Wired |
| Form Factor | Wall Mountable, Surface-mountable |
| Manufacturer | SIIG, Inc |
| Product Name | 1x8 HDMI Splitter HDbitT over IP Extender Kit - 120m |
| Brand Name | SIIG |
| Country of Origin | China |
| Graphics Modes | Full HD |
| Environmentally Friendly | Yes |
| Maximum Video Resolution | 1920 x 1080 |
| Twisted Pair Cable Standard | Category 7 |
| Maximum Operating Distance | 393.70 ft |
| Number of Network (RJ-45) Ports | 16 |
| Network (RJ-45) | Yes |
| Number of HDMI Inputs | 1 |
| Number of HDMI Outputs | 8 |
| HDMI In | Yes |
| HDMI Out | Yes |
| Media Type Supported | Twisted Pair |
| Number of Output Devices Supported | 8 |
| Number of Input Devices Supported | 1 |
| Transmitter Height | 1.18" |
| Transmitter Width | 4.37" |
| Transmitter Depth | 11.81" |
| Receiver Height | 0.93" |
| Receiver Width | 3.70" |
| Receiver Depth | 3.81" |
| Transmitter Weight (Approximate) | 1.81 lb |
| Receiver Weight (Approximate) | 5.28 oz |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
