Overview
Lenovo ThinkSystem SR530 is an ideal 2-socket 1U rack server for small businesses up to large enterprises that need industry-leading reliability, management, and security, as well as cost-optimized performance and flexibility for future growth. Designed to handle a wide range of workloads, such as IT infrastructure, collaboration, and entry cloud, it can be the foundation of your online business.
Warranty
Limited Warranty: 3 Year
About Lenovo
Join Lenovo Transformation is a Team Sport When you work at Lenovo, you make powerful things happen here — for you, for Lenovo, and for the world.
Highlights
2 processors supported for enhanced system performance, ensuring scalability and reliability for enterprise workloads
With 16 GB memory, improve system performance to execute complex applications smoothly and shorten processing time
Rack form factor delivers added reliability and structural integrity, supporting consistent performance in enterprise setups
RAID provides redundancy to safeguard data during drive failures, ensuring maximum dependability and uninterrupted operations
With no optical drive, quickly access music, movies, and data stored on discs
2nd Gen server generation delivers improved performance for faster, more efficient computing
With TruDDR4 memory technology, achieve faster data rates and enhanced system responsiveness for enterprise applications
Gigabit Ethernet is ideal for frequent large file transfers, such as backups and replication, ensuring smooth and efficient operations
2 Network (RJ-45) Ports eliminate the need for additional wiring, streamlining deployment and reducing installation costs
4 USB ports feature a refined design and safer connectivity, ensuring reliable, secure, and easy device connections every time
Videos
Lenovo ThinkSystem SR530 7X08A0BGNA Server
Specifications
Chipset
Chipset Manufacturer
Intel
Chipset Model
C622
Controllers
Controller Type
Serial ATA/600
RAID Supported
Yes
RAID Levels
0, 1, 5, 10
Display & Graphics
Graphics Memory Capacity
16 MB
General Information
Manufacturer
Lenovo Group Limited
Manufacturer Part Number
7X08A0BGNA
Brand Name
Lenovo
Product Line
ThinkSystem
Product Series
SR530
Product Model
7X08A0BGNA
Product Name
ThinkSystem SR530 7X08A0BGNA Server
Product Type
Server
Interfaces/Ports
Total Number of USB Ports
4
Number of USB 2.0 Ports
1
Number of USB 3.0 Ports
3
Network (RJ-45)
Yes
Number of Network (RJ-45) Ports
2
Remote Management
Yes
Remote Management Controller
XClarity Controller (XCC)
Memory
Standard Memory
16 GB
Maximum Memory Supported
768 GB
Memory Technology
TruDDR4
Total Number of Memory Slots
12
Number of Occupied Memory Slots
1
Error Checking
ECC
Network & Communication
Ethernet Technology
Gigabit Ethernet
Operating System
Operating System Supported
Windows Server, Windows Server 2019, Windows Server 2016, Windows Server 2012 R2 Standard, Red Hat Enterprise Linux 7.6, Red Hat Enterprise linux 7.5, Red Hat Enterprise linux 7.4, Red Hat Enterprise Linux 7.3, Red Hat Enterprise Linux 6.9, SuSE Linux Enterprise Server 15, SUSE Linux Enterprise Server 12 SP3, Red Hat Enterprise Linux 6.1
Physical Characteristics
Form Factor
Rack
Rack Height
1U
Height
1.7"
Width
17.1"
Depth
28.1"
Weight (Approximate)
35.27 lb
Power Description
Input Voltage
120 V AC, 230 V AC
Number of Power Supplies Supported
2
Processor
Number of Processors Supported
2
Processor Type
Xeon
Processor Generation
2nd Gen
Storage
Optical Drive Type
No
Warranty
Limited Warranty
3 Year
Miscellaneous
Package Contents
ThinkSystem SR530 7X08A0BGNA Server
Rack Installation Guide
Electronic Publications Flyer
Security Features
Power-on Password
Administrator's Password
Secure Firmware Updates
Trusted Platform Module (TPM) 1.2 or 2.0 (configurable UEFI setting)
