Intel C266 Chip - 1 Processor Support - 128 GB RAM Support - TruDDR5 Up to 16 MB Graphic Card - Gigabit Ethernet - 8 x Total Bay(s) - 8 x SFF Bay(s) - 2 x 800 W - Redundant Power Supply
$5,079.95
Special order — expected back in stock the week of Sep 7–13.
Genuine Lenovo through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.
The Lenovo ThinkSystem SR250 V3 is a high-value single-socket 1U rack server for growing businesses that need optimized performance and flexibility for future growth, along with enterprise-class reliability, management, and security. The server supports the new Intel Xeon E-2400 Series processors, formerly codenamed "Raptor Lake-E".
This product guide provides essential presales information to understand the ThinkSystem SR250 V3 server, its key features and specifications, components and options, and configuration guidelines. This guide is intended for technical specialists, sales specialists, sales engineers, IT architects, and other IT professionals who want to learn more about the SR250 V3 and consider its use in IT solutions.
Additional Warranty Information: Three-year customer-replaceable unit and onsite limited warranty with 9x5 next business day (NBD). Limited Warranty: 3 Year
Join Lenovo Transformation is a Team Sport When you work at Lenovo, you make powerful things happen here — for you, for Lenovo, and for the world.
| Chipset | |
|---|---|
| Chipset Manufacturer | Intel |
| Chipset Model | C266 |
| Controllers | |
| Controller Type | Serial ATA |
| Controller Model | 5350-8i |
| Display & Graphics | |
| Graphics Memory Capacity | 16 MB |
| General Information | |
| Manufacturer | Lenovo Group Limited |
| Manufacturer Part Number | 7DCL1000NA |
| Brand Name | Lenovo |
| Product Line | ThinkSystem |
| Product Series | SR250 V3 |
| Product Model | 7DCL1000NA |
| Product Name | ThinkSystem SR250 V3 7DCL1000NA Server |
| Product Type | Server |
| I/O Expansions | |
| Number of Total Expansion Bays | 8 |
| Number of Internal 2.5" Bays | 8 |
| Number of SFF Bays | 8 |
| Total Number of Expansion Slots | 3 |
| PCI Express Details | x8 LP, x8 LP, x8 Int |
| Interfaces/Ports | |
| Total Number of USB Ports | 4 |
| Number of USB 2.0 Ports | 1 |
| Network (RJ-45) | Yes |
| Number of Network (RJ-45) Ports | 2 |
| VGA | Yes |
| Remote Management | Yes |
| Remote Management Controller | XClarity Controller (XCC2) Platinum |
| Memory | |
| Standard Memory | 32 GB |
| Maximum Memory Supported | 128 GB |
| Memory Technology | TruDDR5 |
| Memory Clock Speed | 4.80 GHz |
| Number of Occupied Memory Slots | 1 |
| Error Checking | ECC |
| Signal Processing | Unregistered (Unbuffered) |
| Network & Communication | |
| Ethernet Technology | Gigabit Ethernet |
| Operating System | |
| Operating System Supported | Windows Server 2022, Red Hat Enterprise Linux 8.8, Red Hat Enterprise Linux 8.9, Red Hat Enterprise Linux 8.10, Red Hat Enterprise Linux 9.2, Red Hat Enterprise Linux 9.3, Red Hat Enterprise Linux 9.4, SUSE Linux Enterprise Server 15 SP5, Ubuntu 22.04 LTS x64 |
| Physical Characteristics | |
| Form Factor | Rack |
| Rack Height | 1U |
| Height | 1.7" |
| Width | 17.1" |
| Depth | 22.1" |
| Weight (Approximate) | 25.22 lb |
| Power Description | |
| Input Voltage | 120 V AC, 230 V AC |
| Number of Power Supplies Supported | 2 |
| Number of Power Supplies Installed | 2 |
| Plug/Connector Type | C13 |
| Maximum Power Supply Wattage | 800 W |
| Redundant Power Supply | Yes |
| Hot Swappable Power Supply | Yes |
| Processor | |
| Number of Processors Supported | 1 |
| Number of Processors Installed | 1 |
| Processor Type | Xeon |
| Processor Model | E-2478 |
| Processor Core | Octa-core (8 Core) |
| Processor Speed | 2.80 GHz |
| Cache | 16 MB |
| Storage | |
| Number of Solid State Drives | 5 |
| Total Solid State Drive Capacity | 3.84 TB |
| Solid State Drive Interface | Serial ATA |
| Warranty | |
| Limited Warranty | 3 Year |
| Additional Warranty Information | Three-year customer-replaceable unit and onsite limited warranty with 9x5 next business day (NBD). |
| Miscellaneous | |
| Package Contents |
|
| Security Features |
|
| Energy Star | Yes |
| Environmentally Friendly | Yes |
| Environmental Certification | Electronic Product Environmental Assessment Tool Bronze (EPEAT Bronze), China Environmental Labeling Program (CELP) |
| Energy Efficiency Certification | China Energy Conservation Program (CECP), ENERGY STAR 4.0 |
| Energy Efficiency Compliance | Energy-related Products Directive Lot 9 (ErP Lot 9) |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
