Middle Atlantic Multi-Mount Rack Mounted Power Distribution Unit - 20 Amp, 16 Outlet PDU
Legrand

Middle Atlantic Multi-Mount Rack Mounted Power Distribution Unit - 20 Amp, 16 Outlet PDU

NEMA 5-20P - 16 x NEMA L5-20R - 120 V AC - 1U - Horizontal/Vertical - Rack-mountable

SKU
PDS-1620R-NS
Category
PDUs

MSRP$795.00

$471.11

Save 41%
Back ordered

Back ordered — ships when restocked.

Get a quote

Genuine Legrand through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.

SKU
PDS-1620R-NS
Category
PDUs

Overview

The Middle Atlantic PDS-1620R-NS is an excellent power distribution unit that provides built-in sequencing functions, which saves space and makes it easier to manage power distribution in your setup. This unit provides 6-step sequencing to 6 rear outlets, allowing you to turn on and off your devices in a specific order to avoid overloading your circuit. Additionally, the PDS-1620R-NS allows daisy-chaining up to 3 sequencers to act together, providing even more control over your power distribution. The intervals are adjustable, making it easy to customize your setup to your specific needs. The PDS-1620R also features remote triggering and notifications, allowing you to control it from a distance and receive updates on its status. The power distribution unit comes equipped with a 9ft SignalSAFE power cord, which minimizes potential interference from AC magnetic fields from other equipment in the rack. Overall, the Middle Atlantic PDS-1620R is an excellent choice for those who want to save space and customize their power distribution setup.

Highlights

  • Versatile design lets unit be mounted horizontally or vertically
  • Space-saving shallow 4" depth
  • 16 total outlets in small package (10 always on, 6 sequenced)
  • Includes 3-step sequencing
  • Features 9' SignalSAFE? power cord to minimize AC magnetic fields
  • Reversible, adjustable mounting ears support many mounting methods
  • Outlets have varied orientations to accommodate many plug styles

Specifications

Package Contents
  • Multi-mount Rackmount Power, 16 Outlet, 20A, 3-Step Sequencing
  • 9' 12/3 SignalSAFE? Power Cord
Product TypePDU
Input Voltage120 V AC
Manufacturer Part NumberPDS-1620R-NS
Limited Warranty3 Year
Input Current20 A
ManufacturerLegrand Group
Product ModelPDS-1620R-NS
Product NameMulti-Mount Rack Mounted Power Distribution Unit - 20 Amp, 16 Outlet PDU
Mount TypeRack-mountable
Product SeriesPDS
Rack Height1U
Brand NameMiddle Atlantic
Plug/Connector TypeNEMA 5-20P
Height1.8"
Width19"
Depth4.5"
Receptacle TypeNEMA L5-20R
Environmentally FriendlyYes
Environmental CertificationGREENGUARD
Mounting OrientationHorizontal/Vertical
Receptacle Detail16 x NEMA L5-20R
Environmental ComplianceRestriction of Hazardous Substances (RoHS)
