Point System? RS232 Remotely Managed Media Converter Module RS232 Copper to Fiber
Transition Networks

Point System? RS232 Remotely Managed Media Converter Module RS232 Copper to Fiber

MEDIA CONVERTER- RS232/DB9 TO FX CONV,SC SM LH

SKU
CRS2F3115-100
Category
Transceivers/Media Converters

MSRP$734.00

$532.47

Save 27%
Back ordered

Back ordered — ships when restocked.

Get a quote

Genuine Transition Networks through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.

SKU
CRS2F3115-100
Category
Transceivers/Media Converters

Overview

The CRS2F Series stand-alone serial RS232 to fiber converters allow you to extend the distance between serial connections with the use of fiber optic cable. These full-featured stand-alone media converters transmit the full complement of RS232 flow control/handshaking signals optically and supports full or half-duplex asynchronous data transmission at speeds up to 115 Kbps. Link a remote terminal to a host computer: Connect multiple devices, such as security scanners, POS devices, remote terminals and building access/alarming systems to a host computer. Ideal for campus or business environments where remote devices can be networked in a point-to-point configuration where distances are greater than the 15 meter limitation of conventional copper serial cables. NDAA Compliant, TAA Compliant

Highlights

  • Read/write access to remote stand-alone unit
  • Local or Remote Loopback on copper and fiber
  • DTE/DCE switch for easy installation with straight-through cabling
  • Full/Half-duplex asynchronous transmission at speeds up to 115 Kbps
  • Supports the following flow control signaling:
  • DCD - Data Carrier Detect
  • RXD - Receive Data
  • TXD - Transmit Data
  • DTR - Data Terminal Read
  • SG - Signal Ground
  • DSR - Data Set Ready
  • RTS - Request To Send
  • CTS - Clear To Send
  • Field Upgradeable Firmware Management

Specifications

Product TypeTransceiver/Media Converter
Manufacturer Part NumberCRS2F3115-100
Maximum Distance Supported40 km
Limited WarrantyLifetime
Form FactorInternal
ManufacturerLantronix, Inc
Product ModelCRS2F3115-100
Product NamePoint System RS232 Copper to Fiber Media Converter
Power Consumption5 W
Product LinePoint System
Product SeriesCRS2F
Brand NameLantronix
Height3.4"
Width3.4"
Depth5"
Number of SC Ports1
Media Type SupportedOptical Fiber
Fiber Mode SupportedSingle-mode
Total Number of Ports2
SC Port TypeDuplex
TAA CompliantYes
