SIIG ipcolor 4K HDMI 2.0 Extender Daisy Chain Transceiver - 230ft
Zero Latency, With IR Control & Auto EDID Management , Daisy Chain Transmission Kit Part# CE-H26M11-S1
- SKU
- CE-H26N11-S1
- Category
- Audio & Video Consoles/Extenders
MSRP$109.99
$79.05
Save 28%Back ordered — ships when restocked.
Genuine SIIG through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.
- SKU
- CE-H26N11-S1
- Category
- Audio & Video Consoles/Extenders
Overview
Extends 4K@60Hz HDMI signals up to 230ft with zero latency, IR, HDR, audio extraction, and ARC using industry leading ipcolor video transmission technology; receives HDMI signals from ipcolor 4K HDMI 2.0 Extender Daisy Chain Transmission Kit, part number CE-H26M11-S1, sold separately, supports daisy chain connection for additional extension and displays
• 4K HDMI Extension - Extends UHD 4K@60Hz HDMI signals up to 230ft/70m from a source device to an HDMI display via Cat6/6a/7 cable
• Advanced ipcolor Transmission Technology - ipcolor is a global leading innovative technology for ultra high definition video digital transmission and connectivity, it can extend and transmit uncompressed 4K@60Hz YUV 4:4:4 video + audio, including HDR, with zero latency
• Daisy Chain Extension - Supports daisy chain connection of up to 10 transceivers to further extend HDMI signal up to 165ft to each transceiver
• Note : Requires ipcolor 4K HDMI 2.0 Extender Daisy Chain Transmission Kit, part# CE-H26M11-S1, sold separately
• Audio Extraction - Extracts and routes digital audio from the HDMI signal through the transceiver's digital Toslink port, supports PCM, Dolby 5.1, DTS 5.1 audio output signal
• ARC - Connects through the Toslink optical port of the transceiver to the display's ARC sink
• IR Control - Built-in bi-directional IR provides full remote control capabilities, control the HDMI source device at the remote display location and vice versa, IR blaster and receiver cables included
• Auto EDID and Downscaling - The lowest EDID capability of the connected display(s) controls the resolution output to the display(s)
• Protection - Lightning Protection, Surge Protection, ESD protection
• High Quality Construction - High quality metal housing with ventilation panels improve heat dissipation and ensure system stability during long hours of operationEasy Installation - Plug and play installation, no driver installation required
Compatibility Notes :
• Does not work with routers and switches
• Requires ipcolor 4K HDMI 2.0 Extender Daisy Chain Transmission Kit, part# CE-H26M11-S1, for daisy chain connection, sold separately
Highlights
- Transmits high-quality video and provides independent stereo audio for maximum productive usability
- 3840 x 2160 maximum video resolution for a spectacular, sharp display with added reliability
- HDMI out enables you to transfer data from your devices to video extender transceiver with added efficiency
- Twisted pair media type helps minimize electromagnetic radiation and it also effectively resist external interference
- 1 output devices supported for maximum productive usability
- 230 ft maximum operating distance for feasible operation and optimal coverage
- 4K UHD graphics mode for an immersive and sharp viewing experience
Specifications
| Package Contents |
|
|---|---|
| Product Type | Video Extender Transceiver |
| Manufacturer Part Number | CE-H26N11-S1 |
| Limited Warranty | 2 Year |
| Connectivity Technology | Wired |
| Manufacturer | SIIG, Inc |
| Product Name | ipcolor 4K HDMI 2.0 Extender Daisy Chain Transceiver |
| Brand Name | SIIG |
| Country of Origin | China |
| Graphics Modes | 4K UHD |
| Environmentally Friendly | Yes |
| Maximum Video Resolution | 3840 x 2160 |
| Twisted Pair Cable Standard | Category 7 |
| Maximum Operating Distance | 230 ft |
| Number of Network (RJ-45) Ports | 2 |
| Network (RJ-45) | Yes |
| Number of HDMI Outputs | 1 |
| HDMI Out | Yes |
| Media Type Supported | Twisted Pair |
| Number of Output Devices Supported | 1 |
| Product Color | Black |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
