VanCryst USB DisplayPort HDBaseT 2.0 KVM Extender (4K@100 m)-TAA Compliant
1 Computer(s) - 1 Remote User(s) - 492.13 ft Range - 4K - 4096 x 2160 Maximum Video Resolution - 4 x Network (RJ-45) - 4 x USB - DisplayPort - Rack-mountable
SKU
CE920
Category
KVM Consoles/Extenders
MSRP$1,247.00
$906.06
Save 27%
Back-ordered
Special order — estimated available by September 10, 2026.
Genuine ATEN Technology through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.
SKU
CE920
Category
KVM Consoles/Extenders
Overview
The ATEN CE920 USB DisplayPort HDBaseT 2.0 KVM Extender integrates the latest HDBaseT 2.0 technologies to deliver 4K video, stereo audio, USB, Ethernet, and RS-232 signals up to 100 meters using a single Cat6 / 2L-2910 Cat 6 cable. The HDBaseT 2.0 guarantees the most reliable transmission on the market as well as enables the long-reach capability that extends full HD 1080P signals up to 150 meters. With an easy cable installation supporting various signals, the CE920 is ideal for applications where convenient remote access is required - such as transportation control centers, medical facilities, industrial warehouses, and extended workstations.
Highlights
Extends video, audio, USB, RS-232, and Ethernet signals via a single Cat6 / 6a / 2L-2910 Cat 6 cable
Enhanced bit error detection and correction to resist signal interference during high-quality video transmissions
Status detection and LED indication for HDBaseT signal transmission on remote unit
EDID Buffer for smooth power-up and the highest quality display
HDBaseT Standard mode up to 4K @ 100m (Cat 6 / 6a / 2L-2910)
HDBaseT Long-Reach mode up to 1080P @ 150m
Long Reach mode switch - switches between HDBaseT Standard and Long Reach modes in a snap
USB 2.0 full speed ports - ensures fast transmission speeds for peripherals
HDCP Compatible
Supports individual 2-channel stereo audio for high-quality audio applications
Specifications
General Information
Manufacturer
ATEN Technology, Inc
Manufacturer Part Number
CE920
Brand Name
VanCryst
Product Model
CE920
Product Name
USB DisplayPort HDBaseT 2.0 KVM Extender (4K@100 m)
Product Type
KVM Console/Extender
Interfaces/Ports
Network (RJ-45)
Yes
USB
Yes
DisplayPort
Yes
Number of Network (RJ-45) Ports
4
Number of USB Ports
4
Physical Characteristics
Form Factor
Rack-mountable
Transmitter Height
1.13"
Transmitter Width
4.80"
Transmitter Depth
7.17"
Receiver Height
1.13"
Receiver Width
4.80"
Receiver Depth
7.17"
Transmitter Weight (Approximate)
1.39 lb
Receiver Weight (Approximate)
1.41 lb
Technical Information
Connectivity Technology
Wired
Number of Computers Supported
1
Number of Remote Users Supported
1
Maximum Operating Distance
492.13 ft
Video
Graphic Mode
4K
Maximum Video Resolution
4096 x 2160
Miscellaneous
Package Contents
1 x CE920L USB DisplayPort HDBaseT 2.0 KVM Extender (Local Unit)
1 x CE920R USB DisplayPort HDBaseT 2.0 KVM Extender (Remote Unit)
1 x Microphone Cable
1 x Speaker Cable
1 x USB Type-A to Type-B Cable
1 x DisplayPort Cable
2 x Mounting Kits
2 x Power Adapters
1 x User Instructions
Environmentally Friendly
Yes
Environmental Compliance
Restriction of Hazardous Substances (RoHS), Waste Electrical and Electronic Equipment Directive (WEEE)
