SKU
ACU1700A
Category
KVM Consoles/Extenders
Overview
Use the KVM Extenders to send high-resolution 4K@60Hz (4:2:0 8-bit) video as well as signals for USB keyboards, mice, and other human interface devices (HID), and power and control signals. The extender includes a local unit that attaches to the CPU and a remote unit that connects the user's KVM console. But you can also plug in a monitor on the local side - which is great for monitoring and administration right at the computer. Requires only one power supply.
Warranty
Limited Warranty: 3 Year
About Black Box
For over forty years, Black Box has been a world-leading provider of premier IT infrastructure solutions. Today, we continue to design and manufacture award-winning products for Pro AV, KVM, cabling and networking known for their advanced functionality, flawless performance, outstanding reliability and fail-safe security. Our solutions are used every day in government, education, commercial enterprises and any other organization that requires the utmost quality and performance from their IT infrastructure.
On top of creating industry-leading products, Black Box demonstrates every day a complete commitment to providing our customers with the best technical support and service in the industry. Our award-winning, dedicated support staff works around the clock to ensure our customers’ systems are always up and running optimally. They are truly as important to the successful IT, communications and business operations of our customers as the powerful products and solutions we deliver.
Highlights
Extend uncompressed 4Kx2K@60Hz and 1080p@60Hz up to 100 meters over CAT6, CAT6A cables and up to 90 meters over CAT5 cable
Transmit video, analog stereo, power, RS-232 and USB 2.0 signals
With integrated 48V PoC, only one power supply is needed to power both units
Locking power supply prevents the power from being accidentally disconnected
An analog audio pass through from Transmitter to Receiver
HDMI 1.4 Compliance
Four USB Type-A inputs for keyboard, mouse, or additional peripherals
Specifications
General Information
Manufacturer
Black Box Corporation
Manufacturer Part Number
ACU1700A
Brand Name
Black Box
Product Name
KVM Extender - 4K@60Hz, HDMI 1.4, USB 2.0, CAT5e/6/6A
Product Condition
New
Product Type
KVM Extender
Interfaces/Ports
USB
Yes
HDMI
Yes
Number of HDMI Ports
2
Number of USB Ports
5
Technical Information
Connectivity Technology
Wired
Number of Computers Supported
1
Number of Local Users Supported
1
Maximum Operating Distance
328.08 ft
Device Type
KVM Extender
Video
Graphic Mode
4K
Maximum Video Resolution
4096 x 2160
Warranty
Limited Warranty
3 Year
Miscellaneous
Package Contents
1 x Transmitter
1 x Receiver
1 x 12VDC, 2A Power Supply
4 x Power Cords (US, UK, EU, AU)
2 x 3-Pin Phoenix connectors
2 x Mounting brackets + 4 screws
Environmentally Friendly
Yes
Environmental Compliance
Waste Electrical and Electronic Equipment Directive (WEEE), Restriction of Hazardous Substances (RoHS)
