KVM over IP Switches| Remote Access to KVM, USB and serial connections| 2-Year Full Coverage Factory Warranty
MSRP$8,315.00
$5,623.72
Save 32%In stock: 4
Genuine Vertiv through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.
The Vertiv Avocent MergePoint Unity Switch combines KVM over IP and serial console management technology in a single appliance delivering flexible management of connected devices and secure access from anywhere, any time. This IP KVM switch offers IT administrators remote access and control of servers, networking equipment and other devices found in data centers and branch offices. It enables users to quickly and easily diagnose, reconfigure or restore equipment to meet SLAs and minimize downtime. It has local and remote browser interface for easy setup and use. This TAA-compliant KVM switch has remote smart card/CAC reader support for advanced security requirements. This switch reduces the need to physically enter the data centers for local access and control by providing remote users the capabilities of a direct physical connection from anywhere to KVM, USB and serial ports of servers and other IT equipment. More from the Manufacturer
TRUE SERIAL CAPABILITIES
Vertiv Avocent MergePoint Unity KVM Switches support the MPUIQ-SRL module, which provides true serial capabilities through Telnet, allowing multiple remote users (1 to 8 users). An SSH session or a serial viewer can be launched from the On-Board Web Interface (OBWI) to connect the Avocent MPU’s attached target devices (8 to 32 8-pin connectors) that have an MPUIQ-SRL module.
ADDED SECURITY
Reduce the need to physically enter the data centers for local access and control. The Avocent MPU provides remote users the capabilities of a direct physical connection from anywhere to KVM, USB, and serial ports of servers and other IT equipment. Using the virtual media capabilities of the Avocent MPU, the provided smart card reader can be mapped from a desktop PC out to a remote server while still meeting advanced security requirements.
IMPROVE EFFICIENCY
Avocent MPU KVM Switches reduce the time required to remotely diagnose, reconfigure, repair, or restore servers as well as network devices and other hardware with serial configuration and/or management consoles. Complementing in-band tools create a more complete remote management solution to access servers and network equipment at remote locations. Additionally, the switches are compatible with Vertiv Avocent DSView 4.5 management software.
MPU108EDAC-400
Local Console Port: 1x VGA, 4x USB Type A
Network Ports: 2x 10/100/1000
Ethernet Power Control Ports: 2x RS232 Serial 8-pin Connector
Target Ports: 8x 8-pin connector
Supported Target Video (using modules): VGA, DVI-I, DisplayPort and HDMI
Remote Users: 1x
Local Users: 1x
Max Local Resolution : 1920x1080
Height: 1.72"
Width: 17"
Depth: 9.2"
Weight: 6.3 lbs
MPU2016DAC-400
Local Console Port: 1x VGA, 4x USB Type A
Network Ports: 2x 10/100/1000
Ethernet Power Control Ports: 2x RS232 Serial 8-pin Connector
Target Ports: 16x 8-pin connector
Supported Target Video (using modules): VGA, DVI-I, DisplayPort and HDMI
Remote Users: 2x
Local Users: 1x
Max Local Resolution : 1920x1080
Height: 1.72"
Width: 17"
Depth: 13.38"
Weight: 8.6 lbs
MPU4032DAC-400
Local Console Port: 1x VGA, 4x USB Type A
Network Ports: 2x 10/100/1000
Ethernet Power Control Ports: 2x RS232 Serial 8-pin Connector
Target Ports: 16 x 32-pin connector
Supported Target Video (using modules): VGA, DVI-I, DisplayPort and HDMI
Remote Users: 4x
Local Users: 1x
Max Local Resolution : 1920x1080
Height: 1.72"
Width: 17"
Depth: 13.38"
Weight: 8.6 lbs
MPU8032DAC-400
Local Console Port: 1x VGA, 4x USB Type A
Network Ports: 2x 10/100/1000
Ethernet Power Control Ports: 2x RS232 Serial 8-pin Connector
Target Ports: 16 x 32-pin connector
Supported Target Video (using modules): VGA, DVI-I, DisplayPort and HDMI
Remote Users: 8x
Local Users: 1x
Max Local Resolution : 1920x1080
Height: 1.72"
Width: 17"
Depth: 13.38"
Weight: 8.6 lbs
Limited Warranty: 2 Year
Digital Continuity Solutions Vertiv brings together hardware, software, analytics, and ongoing services to ensure a customer’s digital infrastructure and vital applications run continuously, perform optimally, and scale with business needs Vertiv is a U.S. based, publicly-traded (NYSE: VRT), global manufacturer of power, thermal and IT infrastructure products and services. By bringing together hardware, software and on-going services, Vertiv offers solutions that ensure uninterrupted, reliable, safe operations of vital data applications that run continuously and perform-optimally. Vertiv possesses a rare combination of expertise and solutions that ensures connectivity and availability across any and all network facilities, anywhere in the world. Our portfolio includes the most respected brands in the industry including Avocent (networking and remote management), Geist (rack PDUs, monitors, sensors), and Liebert (UPS, power and thermal). Visit Vertiv.com for more information. Our Brands Avocent The power of being there When you need to take control of multiple IT devices across a room or across geographies, you can rely on market-leading Avocent or Cybex keyboard, video, and mouse (KVM) switches and serial consoles to provide easy, single-point access to valuable system data. Since 1981 Avocent has been developing and manufacturing industry-leading KVM switches and serial consoles to deliver easy, single-point access to valuable system data in order to control and simplify management of multiple IT devices. Vertiv’s Avocent solutions have helped over 200,000 customers worldwide by providing faster provisioning, simplified management, reduced mean time to repair, enhanced security, and lower operating costs. Geist Reliable power management Ensuring data center availability and business continuity requires that the last link in the power chain, the rack power distribution unit (rPDU), operates as intended to support dynamic operations in the areas of power, cooling, monitoring, and overall data center infrastructure management (DCIM). Geist designs and manufactures industry-leading technology and software to power, cool, monitor and manage critical data center infrastructure. On-site engineering, reliability, conformance and compliance allow us to design, manufacture, and ship PDUs so they arrive when you need them. Customers have peace of mind knowing Geist’s dedicated compliance and reliability engineering team ensure conformance to global standards for reliability, safety, and accuracy. Liebert Protecting the power and environment of your mission critical electronic systems Your data center and edge computing sites are the core of your business. Intelligent, efficient power and thermal infrastructure are critical to ensuring continuous access to vital applications and data. Liebert power and thermal management systems are designed to protect your IT environment and adapt to your changing needs. Liebert provides global power and thermal management solutions with a portfolio of most efficient and reliable power and cooling technologies in the market. Liebert offers a complete line of energy-efficient and reliable technologies including UPS, racks, rack enclosures, rack cooling, and PDUs. These award-winning technologies offer unmatched efficiency and reliability for mission-critical applications, as well as controls to optimize uptime. Architects of Continuity As Architects of Continuity, Vertiv solutions help customers build future-ready digital infrastructures that deliver continuity across large infrastructure (AC power, DC power, energy storage, industrial solutions, thermal) and IT and edge infrastructure (edge systems, IT systems, rack, rack PDU, rack thermal, rack UPS) applications. Customers can choose to work with a trusted Vertiv advisor or order products online via their preferred IT distributors, resellers and marketplaces. To learn more, visit Vertiv.com today!
| Product Type | KVM Switchbox |
|---|---|
| Manufacturer Part Number | MPU2016DAC-400 |
| Limited Warranty | 2 Year |
| Manufacturer | Vertiv |
| Product Name | MPU KVM Switch | 16 port | 2 Digital Path | Dual AC Power TAA |
| Product Line | MPU |
| Brand Name | Vertiv AVOCENT |
| Country of Origin | United States |
| USB | Yes |
| Number of Computers Supported | 16 |
| TAA Compliant | Yes |
Send a bill of materials or part numbers — we confirm stock, TAA country of origin and a below-market total. No payment up front.
