StarTech 16 Port 1U Rackmount USB KVM Switch with OSD, TAA
Control up to 16 USB computers from a single keyboard, mouse and monitor - usb kvm switch - 16 port kvm switch - vga kvm switch -rack mount kvm
- SKU
- SV1631DUSBU
- Category
- KVM Switchboxes
$606.21
In stock: 13
Genuine StarTech.com through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.
- SKU
- SV1631DUSBU
- Category
- KVM Switchboxes
Overview
The SV1631DUSBU 16 Port 1U Rack Mountable USB KVM Switch with OSD lets you control 16 USB computers from a single console (USB keyboard, USB mouse, VGA monitor). Convenient push-button and hot-key controls provide quick, reliable switching between connected computers while manual and auto-scan switching modes and an On Screen Display (OSD) offer additional control options. Designed to ensure maximum space efficiency, the USB KVM switch features a slim 1U design that fits neatly into a server equipment rack/cabinet with the included brackets, and can be cascaded with multiple KVM switches to deliver control of up to 136 computers from this single switch. Rear cable connections help to eliminate cable tangles and minimize workspace disruption. This product is TAA compliant and backed by a Startech.com 3-year warranty with free lifetime technical support. The SV1631DUSBU onlyworks with specific 2-in-1 VGA and USB cables (soldseparately), a list ofStarTech.com approved cables are below: 6ft Ultra Thin USB VGA 2-in-1 KVM Cable 6ft Ultra Thin USB VGA 2-in-1 KVM Cable 10 ft Ultra Thin USB VGA 2-in-1 KVM Cable 15ft Ultra Thin USB VGA 2-in-1 KVM Cable More from the Manufacturer More from the Manufacturer
Highlights
- OS Independent No drivers or software required
- Auto-scan function automatically selects computer sequentially
- Cascade configuration expands system capability
- Front panel push-button and Hotkey switching allow easy computer access
- Identifies and selects computers by the names assigned using the OSD
- USB console connections
- OSD security allows each PC to be password protected
- Plug-and-play system configuration
- Supported Wide Screen Resolutions: 1920x1200, 1920x1080, 1680x1050, 1400x1050, 1440x900, 1360x768
- Supported 4 : 3 Resolutions: 1920x1440, 1600x1200, 1280x1024, 1024x768
Specifications
| Package Contents |
|
|---|---|
| Product Type | KVM Switchbox |
| Manufacturer Part Number | SV1631DUSBU |
| Packaged Quantity | 1 Each |
| Limited Warranty | 3 Year |
| Weight (Approximate) | 6.83 lb |
| Form Factor | Rack-mountable, Desktop |
| Manufacturer | StarTech.com |
| Product Model | SV1631DUSBU |
| Product Name | 16 Port 1U Rack Mount USB KVM Switch with OSD |
| Rack Height | 1U |
| Brand Name | StarTech.com |
| Input Voltage Range | 110V AC to 240V AC |
| Country of Origin | Taiwan |
| Height | 1.8" |
| Width | 21.3" |
| Depth | 7.1" |
| Environmentally Friendly | Yes |
| Maximum Video Resolution | 1920 x 1440 |
| USB | Yes |
| Number of USB Ports | 2 |
| Number of Computers Supported | 16 |
| TAA Compliant | Yes |
