Genuine Supermicro through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.
SKU
MBD-X11SCQ-O
Category
Motherboards
Overview
8th Generation Core Processor Based Motherboards
B360/Q370/H310 chipset / Socket H4 Boards
Supermicro's single processor Socket H4 designs feature the Intel® B360/Q370/H310 chipset which support the Intel® 8th Generation Core i7/i5/i3 processor family. With outstanding features that include up to 64GB non-ECC fast DDR4 DRAM in 4 DIMMS, USB 3.0/USB 3.1, PCI-E 3.0 M.2, and SATA 3.0 (6Gbps) HDD. With support for next generation graphics controller, 4K HD graphics resolution and multiple displays. Designed with performance, reliability, manageability and long life in mind, Supermicro's single processor motherboards are the perfect solution for a variety of multi-tasking, heavy loading applications.
Warranty
Limited Warranty: 1 Year
Highlights
With the compatible Intel Pentium processor, experience splendid PC performance; enjoy songs, movies and get your work completed concurrently
DDR4 SDRAM compatible slot - Install memory that synchronizes electrical and clock signals for an efficient data throughput
Supported 0 RAID levels provide data reliability and fault tolerance
HDMI interface enables the user to experience a fantastic sound/video quality at the expense of a single cable
DisplayPort host interface allows audio and video signals to be shared in a single cable transmission to ensure maximum efficiency
Micro ATX form factor for your accessibility convenience and simplicity of usage for Desktop Motherboard
Specifications
Audio
Audio Channels
7.1
General Information
Manufacturer
Supermicro Computer, Inc
Manufacturer Part Number
MBD-X11SCQ-O
Brand Name
Supermicro
Product Model
X11SCQ
Product Name
X11SCQ Desktop Motherboard
Packaged Quantity
1
Package Type
Retail
Product Type
Desktop Motherboard
I/O Controller
Controller Type
Serial ATA/600
RAID Supported
Yes
RAID Levels
0, 1, 5, 10
I/O Expansions
Total Number of Expansion Slots
4
Total Number of PCI Express Slots
4
Number of PCI Express x1 Slots
1
Number of PCI Express x4 Slots
2
Number of PCI Express x16 Slots
1
Interfaces/Ports
Total Number of USB Ports
6
Number of USB 3.1 Ports
4
HDMI
Yes
DisplayPort
Yes
DVI
Yes
Memory
Number of Memory Slots
4
Memory Form Factor
DIMM, UDIMM
Maximum Memory Supported
64 GB
Memory Speed Supported
2666 MHz, 2400 MHz, 2133 MHz, 1866 MHz, 1600 MHz
Memory Technology
DDR4 SDRAM
Network & Communication
Gigabit Ethernet
Yes
Onboard Interfaces
Number of SATA Interfaces
6
Number of M.2 Interfaces
1
Total Number of Onboard USB Ports
6
Number of Onboard USB 3.1 Ports
2
Physical Characteristics
Form Factor
Micro ATX
Width
9.6"
Depth
9.6"
Processor & Chipset
Chipset Manufacturer
Intel
Chipset Model
Q370
Total Processor Supported
1
Processor Socket
Socket H4 LGA-1151
Processor Supported
Celeron, Pentium, Core i7, Core i5, Core i3
Video
Onboard Video
CPU Dependent Video
Warranty
Limited Warranty
1 Year
Miscellaneous
Package Contents
X11SCQ Desktop Motherboard
1 x Motherboard Quick Reference Guide
6 x I/O Cables
1 x Standard I/O Shield for X11SCQ/-L with EMI Gasket
