Supermicro A1SAM-2750F Desktop Motherboard - Intel Chipset - Socket BGA-1283 - Micro ATX
Atom C2750 - 64 GB DDR3 SDRAM Maximum RAM - 4 x Memory Slots - Gigabit Ethernet - 6 x SATA Interfaces
- SKU
- MBD-A1SAM-2750F-O
- Category
- Motherboards
MSRP$510.67
$474.72
Save 7%Back ordered
Back ordered — ships when restocked.
Genuine Supermicro through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.
- SKU
- MBD-A1SAM-2750F-O
- Category
- Motherboards
Overview
C2000 Series BOARDS (System-on-Chip)
Supermicro's motherboards based on Intel® Atom? processor C2000 series System-on-Chip are well-suited for entry-level server platforms and embedded IPC market.
Warranty
Limited Warranty: 3 Year
Highlights
- DDR3 SDRAM compatible slot - Allows the memory to operate at an effective bus speed while using minimal power, resulting in an optimal computer performance and improved memory heat dissipation
- Micro ATX form factor for your accessibility convenience and simplicity of usage for Desktop Motherboard
- With 4 USB 2.0 ports, connect devices for a quick data movement
Specifications
| Product Type | Desktop Motherboard |
|---|---|
| Compatibility | Supermicro SuperChassis 1U Chassis: SC510 SC512 SC813M/TQ 2U Chassis SC823M/TQ |
| Manufacturer Part Number | MBD-A1SAM-2750F-O |
| Maximum Memory Supported | 64 GB |
| Limited Warranty | 3 Year |
| Form Factor | Micro ATX |
| Manufacturer | Supermicro Computer, Inc |
| Product Model | A1SAM-2750F |
| Product Name | A1SAM-2750F Desktop Motherboard |
| Package Type | Retail |
| Controller Type | Serial ATA/600, Serial ATA/300 |
| Processor Socket | Socket BGA-1283 |
| Brand Name | Supermicro |
| Memory Technology | DDR3 SDRAM |
| Memory Standard | DDR3-1600/PC3-12800, DDR3-1333/PC3-10600 |
| Width | 9.6" |
| Depth | 7.5" |
| Chipset Manufacturer | Intel |
| Number of Memory Slots | 4 |
| Graphics Controller Model | AST2400 |
| Gigabit Ethernet | Yes |
| Number of SATA Interfaces | 6 |
| Onboard Video | On-board Video Chipset |
| Number of PCI Express x4 Slots | 1 |
| Number of PCI Express x8 Slots | 1 |
| VGA | Yes |
| Number of Network (RJ-45) Ports | 5 |
| Total Number of USB Ports | 4 |
| Number of USB 2.0 Ports | 4 |
| PCI Express Standard | PCI Express 2.0 |
| Total Number of PCI Express Slots | 2 |
| Integrated Processor Type | Atom |
| Integrated Processor Model | C2750 |
| Integrated Processor Core | Octa-core (8 Core) |
| Memory Form Factor | UDIMM |
| Total Number of Expansion Slots | 2 |
| Memory Speed Supported | 1600 MHz, 1333 MHz |
