High Performance KVM Extender | IP-Based KVM Receiver | IP-Based KVM Transmitter | DVI-D | SFP Cage | USB | Single Head | Dual Head | TAA Compliant
MSRP$2,570.00
$2,011.79
Save 22%In stock: 57
Genuine Vertiv through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.
The Vertiv Avocent HMX5200R - IP KVM Receiver (HMX5200R-001) is a high performance KVM extender that provides access to system computers via a CATx network, allowing users the ability to access and share computing resources. The system enables you to locate critical computing hardware in a secure, temperature-controlled environment, away from the user work station to maintain component integrity. It is ideal for demanding applications such as pre- and post-production editing, control rooms and collaborative environments. The KVM system offers a high degree of security through its ability to disable the use of non-HID devices, eliminating the need to block USB ports to prevent the use of mass storage devices. It provides access to DVI-D video resolution of up to 1920 x 1200 @60Hz. The KVM extender includes four USB-A input ports and one system audio output port. More from the Manufacturer
Seamless Access and Sharing System
The Vertiv Avocent HMX IP KVM System (5000-6000 series) is a high performance KVM extender that provides access to system computers via a CATx network, allowing users the ability to access and share computing resources. It is ideal for demanding applications that require high resolution and zero latency such as in broadcasting, sports venues, pre- and post-production editing, control rooms and collaborative environments. An IP-based KVM (keyboard, video, mouse) extender, it allows critical computing hardware to be housed remotely from the user workstation in a secure, temperature-controlled environment. It is designed to improve productivity, reduce IT costs and produce better business results. This KVM system provides powerful administrative tools and connection-management control for the network resources without compromising quality.
Security via TLS certificate-based encryption
Local area network (LAN) operation with unlimited extension distances; no need for dedicated cabling between user and computer
Onscreen (OSD) display at each user station; remote OSD allows video to be pushed and controlled at another station or video wall
System backups stored internally, externally or via email
Updates may be scheduled hourly, daily or weekly
Hardware security, full access
The Vertiv Avocent HMX 5000/6000 IP KVM Systems are extenders that offer a true matrix solution, allowing critical computer hardware to remain in a secure and temperature-controlled environment away from the user workstation while maintaining desktop resolution. This KVM system allows access to any target computer from any access point with IP network so there is no distance limitation.
Easy to manage and use
Centralized management from a single console eases administrative and user verification tasks and can be accessed via a web browser. Security is verified via Transport Layer Security (TLS) certification. Hotkey switching allows users to quickly select channels. Video and USB switching is extremely fast to enhance the user experience.
Quality video, USB support
They deliver a real-time, high quality experience that is ideal for demanding and exacting applications. Have desktop experience remotely with no compromise on video quality or control. These KVM systems support high quality DVI-D video as well as a comprehensive list of peripheral devices including CD audio, USB mass storage, keyboard, mouse and other devices.
Broadcast and Video Production
These IP KVM systems facilitate the creating and editing high-quality broadcast and professional video productions by providing uncompromised video quality or control. The HMX 5000/6000 KVMs offer one or two video DVI video connections in resolutions of 1920 x 2000 or 2560 x 1600. They can support a variety of single-link and dual-link video resolutions, convert video to analog and scale in single port increments by simply adding a transmitter or receiver.
Speed, Security, and Control
Ideal for security centers, control rooms, labs, workstation extensions and environments that require high level of redundancy. Centralized management from a single point ensures security with user administration and verification functions. They offer quick access to multiple devices from a single access point, provide fast switching time and include hotkey capabilities. With IP technology, they also allow workstations to be in a remote yet secure climate controlled environment.
Remote Access Management
The Vertiv Avocent HMX IP KVM Systems can benefit environments where the distance between the user and the computer cannot be limited, such as campuses, arenas or stadiums. These high performance KVM systems make it easy for cooperative sharing of computers while updating and multicasting video and key information to any receiver destination. Any screen application that requires rapid updating can easily be managed through the matrix system by authorized, verified users.
HMX5000
Transmitter (TX)
HMX5100T
HMX5200
1 x DVI-D (5100’s)
1 X VGA, DVI-D, DP (5150)
2 x DVID (5200’s)
1 x USB type B
2 x 3.5mm audio jack 1 X DB9 port Ethernet: 2 x RJ45
1 x SFP cage (MM/SM Fiber or Copper)
Receiver (RX)
HMX5100R
HMX5200R
1 x DVI-D (5100’s) 2 x DVID (5200’s and 6200’s) 4 x USB type A 2x 3.5mm audio jack sockets, 1x 3.5mm SPDIF socket Ethernet: 2 x RJ45 1 x SFP cage (MM/SM Fiber or Copper)
Single/Dual Head
5100 Series - Single
5200 Series - Dual
USB
Supports USB 2.0 devices (low, full and high speed).
Video Resolution
Up to 1920x1200@60 Hz
Audio
Analog Line in/out 2 channel 16bit 48KHz 1V RMS in / 1V RMS out
Ethernet
1 GB Ethernet for Matrix switching access
10/100 Ethernet for Setup/Administration
Form Feature
Box
Compliance
CE FCC
UL
TAA
HMX6000
Transmitter (TX)
HMX6200T
HMX6210T(VNC)
1 X VGA, DVI-D
2 x DVID (6200’s)
1 x USB type B
2 x 3.5mm audio jack 1 X DB9 port Ethernet: 2 x RJ45 (VNC access on the 6210T)
1 x SFP cage (MM/SM Fiber or Copper)
Receiver (RX)
HMX6200R
1 x DVI-D (5100’s) 2 x DVID (5200’s and 6200’s) 4 x USB type A 2x 3.5mm audio jack sockets, 1x 3.5mm SPDIF socket Ethernet: 2 x RJ45 1 x SFP cage (MM/SM Fiber or Copper)
Single/Dual Head
All Dual Head
USB
Supports USB 2.0 devices (low, full and high speed).
Isochronous devices are not supported (e.g. USB audio or video devices) natively. The USB6000 device can be added for Isochronous device.
Video Resolution
Up to 2560x1600 @ 60 Hz.
Audio
Analog Line in/out 2 channel 16bit 48KHz 1V RMS in / 1V RMS out
Ethernet
1 GB Ethernet for Matrix switching access
10/100 Ethernet for Setup/Administration
Form Feature
Box
Compliance
CE FCC
UL
TAA
HMX8000
Transmitter (TX)
HMX8000T
2 x DisplayPort™,
2 x USB type B
2 x 3.5mm audio jack
1 x DB9 port Ethernet: 2 RJ45
2x SFP+ cages (MM or SM Fiber support)
Receiver (RX)
HMX8000R
2x DisplayPort™, 5x USB type A, 2x 3.5mm audio jack sockets, 1x 3.5mm SPDIF socket Ethernet: 1 RJ45 2x SFP+ cages (MM or SM Fiber support)
Single/Dual Head
All Dual Head
USB
4 ports of USB2.0 with USB True Emulation to support keyboard, mouse and touch. USB device seen as: 7 or 13 port hub
Video Resolution
Supports 4K UHD or DCI and refresh rates to 60Hz 4K video over single 10Gb fiber. Add second 10 Gb fiber for dual head
Audio
Analog Line in/out 2 channel 16bit 48KHz 1V RMS in / 1V RMS out
Ethernet
10 GbE (No 10/100/1000 support)
Form Feature
Box
Compliance
CE FCC
UL
TAA
HMX5150
Transmitter (TX)
HMX5150T
1 x (DP or VGA or DVI-D)
Receiver (RX)
NA
Single/Dual Head
Single Head Only (DP,VGA,DVI-D)
USB
Supports USB2.0 full and low speed (No HS support) USB features: Keyboard, mouse and touch.
USB device seen as: 7 or 13 port hub
Video Resolution
Up to 1920x1200@60 Hz
Audio
Line in/out USB audio 2 channel 16bit 48KHz
Ethernet
1GbE (No 10/100 support)
Form Feature
Dongle
Compliance
CE
FCC
Digital Continuity Solutions Vertiv brings together hardware, software, analytics, and ongoing services to ensure a customer’s digital infrastructure and vital applications run continuously, perform optimally, and scale with business needs Vertiv is a U.S. based, publicly-traded (NYSE: VRT), global manufacturer of power, thermal and IT infrastructure products and services. By bringing together hardware, software and on-going services, Vertiv offers solutions that ensure uninterrupted, reliable, safe operations of vital data applications that run continuously and perform-optimally. Vertiv possesses a rare combination of expertise and solutions that ensures connectivity and availability across any and all network facilities, anywhere in the world. Our portfolio includes the most respected brands in the industry including Avocent (networking and remote management), Geist (rack PDUs, monitors, sensors), and Liebert (UPS, power and thermal). Visit Vertiv.com for more information. Our Brands Avocent The power of being there When you need to take control of multiple IT devices across a room or across geographies, you can rely on market-leading Avocent or Cybex keyboard, video, and mouse (KVM) switches and serial consoles to provide easy, single-point access to valuable system data. Since 1981 Avocent has been developing and manufacturing industry-leading KVM switches and serial consoles to deliver easy, single-point access to valuable system data in order to control and simplify management of multiple IT devices. Vertiv’s Avocent solutions have helped over 200,000 customers worldwide by providing faster provisioning, simplified management, reduced mean time to repair, enhanced security, and lower operating costs. Geist Reliable power management Ensuring data center availability and business continuity requires that the last link in the power chain, the rack power distribution unit (rPDU), operates as intended to support dynamic operations in the areas of power, cooling, monitoring, and overall data center infrastructure management (DCIM). Geist designs and manufactures industry-leading technology and software to power, cool, monitor and manage critical data center infrastructure. On-site engineering, reliability, conformance and compliance allow us to design, manufacture, and ship PDUs so they arrive when you need them. Customers have peace of mind knowing Geist’s dedicated compliance and reliability engineering team ensure conformance to global standards for reliability, safety, and accuracy. Liebert Protecting the power and environment of your mission critical electronic systems Your data center and edge computing sites are the core of your business. Intelligent, efficient power and thermal infrastructure are critical to ensuring continuous access to vital applications and data. Liebert power and thermal management systems are designed to protect your IT environment and adapt to your changing needs. Liebert provides global power and thermal management solutions with a portfolio of most efficient and reliable power and cooling technologies in the market. Liebert offers a complete line of energy-efficient and reliable technologies including UPS, racks, rack enclosures, rack cooling, and PDUs. These award-winning technologies offer unmatched efficiency and reliability for mission-critical applications, as well as controls to optimize uptime. Architects of Continuity As Architects of Continuity, Vertiv solutions help customers build future-ready digital infrastructures that deliver continuity across large infrastructure (AC power, DC power, energy storage, industrial solutions, thermal) and IT and edge infrastructure (edge systems, IT systems, rack, rack PDU, rack thermal, rack UPS) applications. Customers can choose to work with a trusted Vertiv advisor or order products online via their preferred IT distributors, resellers and marketplaces. To learn more, visit Vertiv.com today!
| General Information | |
|---|---|
| Manufacturer | Vertiv |
| Manufacturer Part Number | HMX5200R-001 |
| Brand Name | Vertiv AVOCENT |
| Product Line | HMX |
| Product Series | 5000 |
| Product Model | HMX5200R |
| Product Name | HMX 5000 HMX5200R KVM Extender Receiver |
| Product Type | KVM Extender Receiver |
| Interfaces/Ports | |
| Network (RJ-45) | Yes |
| USB | Yes |
| DVI | Yes |
| Number of Network (RJ-45) Ports | 2 |
| Number of USB Ports | 4 |
| Number of DVI Ports | 2 |
| Physical Characteristics | |
| Form Factor | Desktop, Rack-mountable |
| Receiver Height | 1.76" |
| Receiver Width | 7.92" |
| Receiver Depth | 6" |
| Receiver Weight (Approximate) | 2.70 lb |
| Power Description | |
| Input Voltage | 5 V DC |
| Technical Information | |
| Connectivity Technology | Wired |
| KVM Technology | Digital |
| Number of Remote Users Supported | 1 |
| Maximum Operating Distance | 328.08 ft |
| Device Type | High Performance KVM |
| Video | |
| Graphic Mode | WUXGA |
| Maximum Video Resolution | 1920 x 1200 |
| Miscellaneous | |
| Platform Supported | PC |
| Country of Origin | United Kingdom |
