48 V DC, 57 V DC Input - 1 x 2.5 Gigabit Ethernet Input Port(s) - 1 x 2.5 Gigabit PoE+ Output Port(s) - 30 W
$80.06
Special order — estimated available by September 10, 2026.
Genuine TRENDnet through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.
TRENDnet's Industrial 2.5G PoE+ Injector, model TI-IG215, allows users to add PoE+ power to a non-PoE 2.5G switch. Connect the 2.5G PoE+ injector to a non-PoE switch, and then run an Ethernet cable up to 100 meters (328 ft.) to network a PoE/PoE+ device. This multi-gig industrial PoE+ injector supplies up to 30W of power to a PoE device. The fanless design conveniently eliminates operating noise and lowers energy consumption. The 2.5G PoE+ injector is equipped with an IP50-rated metal enclosure, designed to withstand a high degree of vibration and shock, while operating within an extreme temperature range of -40° - 75° C (-40° - 167° F) for harsh industrial environments.
PoE+
This multi-gig PoE+ injector supplies up to 30W of power to a PoE device.
2.5G Ports
Features a high-speed 2.5G port (data in) and a high-speed 2.5G PoE+ port (data + PoE out).
Industrial Design
IP50-rated metal enclosure with a high degree of vibration and shock resistance, and an extreme operating temperature range of -40° - 75° C (-40° - 167° F).
PoE+
This industrial 802.3at PoE injector supplies up to 30W of power to PoE (IEEE 802.3af) or PoE+ (IEEE 802.3at) devices
Industrial Design
Equipped with an IP50-rated metal enclosure, designed to withstand a high degree of vibration and shock, while operating within an extreme temperature range of -40° - 75° C (-40° - 167° F) for industrial environments
2.5G Port
1 x 2.5G port (data in) and 1 x 2.5G PoE+ port (data + PoE out)
PoE Distance
Provides a PoE network connection up to 100m (328 ft.) away from the multi-gig industrial 802.3at PoE+ adapter
LED Indicators
LED indicators on the industrial PoE injector conveys power and PoE connectivity
Shock and Vibration Resistant
Rated for shock (EN 60068-2-27), freefall (EN 60068-2-32), and vibration (EN 60068-2-6)
Grounding Point
Grounding point protects equipment from external electrical surges Fanless Design Fanless design on the injector conveniently eliminates operating noise and lowers energy consumption
Housing Design
Compact and sturdy metal housing for installation flexibility
More from the Manufacturer
TRENDnet’s Industrial 2.5G PoE+ Injector, model TI-IG215, allows users to add PoE+ power to a non-PoE 2.5G switch. Connect the 2.5G PoE+ injector to a non-PoE switch, and then run an Ethernet cable up to 100 meters (328 ft.) to network a PoE/PoE+ device. This multi-gig industrial PoE+ injector supplies up to 30W of power to a PoE device. The fanless design conveniently eliminates operating noise and lowers energy consumption. The 2.5G PoE+ injector is equipped with an IP50-rated metal enclosure, designed to withstand a high degree of vibration and shock, while operating within an extreme temperature range of -40° – 75° C (-40° – 167° F) for harsh industrial environments.
Industrial 2.5G PoE+ Injector
1 x 2.5G PoE+ port (Data + PoE out)
1 x 2.5G port (Data in)
30W PoE power budget
Supports PoE (15.4W) and PoE+ (30W) devices
Uses IEEE 802.3af and IEEE 802.3at industry PoE standards for greater device interoperability
Network a PoE device located up to 100m (328 ft.) away
Fanless design eliminates operating noise and lowers energy consumption
Extreme operating temperature range - 40° — 75° C (-40° — 167° F)
Redundant power inputs with overload current protection
Includes DIN-Rail mount and wall mount
Power supply sold separately (model: TI-S15052)
NDAA / TAA compliant (U.S. and Canada only)
FEATURES
PoE+
This multi-gig PoE+ injector supplies up to 30W of power to a PoE device.
2.5G Ports
Features a high-speed 2.5G port (data in) and a high-speed 2.5G PoE+ port (data + PoE
Industrial Design
IP50-rated metal enclosure with a high degree of vibration and shock resistance, and an extreme operating temperature range of -40° – 75° C (-40° – 167° F).
PoE+
This industrial 802.3at PoE injector supplies up to 30W of power to PoE (IEEE 802.3af) or PoE+ (IEEE 802.3at) devices
Industrial Design
Equipped with an IP50-rated metal enclosure, designed to withstand a high degree of vibration and shock, while operating within an extreme temperature range of -40° – 75° C (-40° – 167° F) for industrial environments
2.5G Ports
1 x 2.5G port (data in) and 1 x 2.5G PoE+ port (data + PoE out)
PoE Distance
Provides a PoE network connection up to 100m (328 ft.) away from the multi-gig industrial 802.3at PoE+ adapter
LED Indicators
LED indicators on the industrial PoE injector conveys power and PoE connectivity
Shock and Vibration Resistant
Rated for shock (EN 60068-2-27), freefall (EN 60068-2-32), and vibration (EN 60068-2-6)
Grounding Point
Grounding point protects equipment from external electrical surges
Fanless Design
Fanless design on the injector conveniently eliminates operating noise and lowers energy consumption
SPECIFICATIONS
Standards
IEEE 802.3
IEEE 802.3u
IEEE 802.3ab
IEEE 802.3af
IEEE 802.3at
IEEE 802.3bz
Device Interface
1 x 2.5GBASE-T port (10M/100M/1G/2.5G)
1 x 2.5GBASE-T PoE+ port (10M/100M/1G/2.5G)
4-pin removable terminal block
LED indicators
Power
Input: 48 – 57V DC
Compatible power supply: TI-S15052 (sold separately)
Max. consumption: 4.3W @ 57V (with no PD connected)
PoE
PoE budget: 28 – 30W
Pins 1, 2, 3, and 6 for power (mode A)
Terminal Block
Redundant power inputs, 4 pin
Wire range: 0.34mm2 to 2.5mm2
Solid wire (AWG): 12-24/14-22
Stranded wire (AWG): 12-24/14-22
Torque: 5 lb. – In / 0.5Nm / 0.56 Nm
Wire strip length: 7-8mm
MTBF
7,680,000 hours @ 25° C
Housing
IP50 metal case
DIN-Rail mount
Wall mount
Grounding point
Contact 6kV/Air 8kV ESD protection
6kV RJ45 surge protection
Operating Temperature
- 40° — 75° C (-40° — 167° F)
Operating Humidity
Max. 95% non-condensing
Dimensions (L x W x H)
60 x 58 x 26mm (2.36 x 2.28 x 1.02 in.)
Weight
133g (4.7 oz.)
Certifications
CE
FCC
LVD
Shock (IEC 60068-2-27)
Freefall (IEC 60068-2-31)
Vibration (IEC 60068-2-6)
IEC 61000-4-2
IEC 61000-4-4
IEC 61000-4-5
Warranty
3-year
PACKAGE CONTENTS
TI-IG215
Removable terminal block
DIN-Rail and wall mount kit
All references to speed are for comparison purposes only. Product specifications, size, and shape are subject to change without notice, and actual product appearance may differ from that depicted herein.
Limited Warranty: 3 Year
| General Information | |
|---|---|
| Manufacturer | TRENDnet |
| Manufacturer Part Number | TI-IG215 |
| Brand Name | TRENDnet |
| Product Model | TI-IG215 |
| Product Name | Industrial 2.5G PoE+ Injector |
| Product Type | PoE+ Injector |
| Interfaces/Ports | |
| Input Ports | 1 x 2.5 Gigabit Ethernet |
| Output Ports | 1 x 2.5 Gigabit PoE+ |
| Physical Characteristics | |
| Form Factor | DIN Rail/Wall Mountable |
| Height | 1" |
| Width | 2.3" |
| Length | 2.4" |
| Weight (Approximate) | 4.69 oz |
| Power Description | |
| Input Voltage | 48 V DC, 57 V DC |
| Maximum Output Power | 30 W |
| Technical Information | |
| Protection Type | ESD Protection, Surge Protection |
| Warranty | |
| Limited Warranty | 3 Year |
| Miscellaneous | |
| Package Contents |
|
| Certifications & Standards |
|
| Country of Origin | Taiwan |
| TAA Compliant | Yes |
