StarTech 10/100 Fiber to Ethernet Media Converter Multi Mode SC 2 km, TAA
Convert and extend a 10/100 Mbps Ethernet connection up to 2 km over Multi Mode SC fiber - fiber converter - ethernet media converter - fibre converter - 10/100 media converter - utp to fiber
Genuine StarTech.com through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.
SKU
MCM110SC2
Category
Transceivers/Media Converters
Overview
The MCM110SC2 10/100 Multi Mode Fiber Ethernet Media Converter SC 2 km creates an economical, cost-effective Ethernet-fiber link, transparently converting to/from 10Base-T or 100Base-Tx Ethernet signals and 100Base-Fx optical signals to extend an Ethernet network connection over an SC terminated multimode fiber backbone. The converter supports a maximum multimode fiber optic cable distance of 2 kilometers (1.2 miles), providing a simple solution for connecting 10Base-T/100Base-Tx Ethernet networks to remote locations using SC-terminated multimode fiber, while delivering solid network performance and scalability. This versatile Ethernet to Fiber converter is compatible with most 3COM?, Cisco?, Lucent? and Nortel? networks and fully complies with applicable IEEE 802.3 standards. Backed by a StarTech.com 2-year warranty and free lifetime technical support. More from the Manufacturer More from the Manufacturer
Highlights
Supports a maximum multi mode fiber optic cable distance of 2 km
Compatible with most 3com, Cisco, Lucent and Nortel networks
Compact design
Supports transparent Q-in-Q double tagged frames
Supports Link Fault Pass through (LFP)
Supports IEEE 802.1q Tag VLAN pass thru
Supports flow control (Pause)
Provides switch configuration of half/full duplex transfer mode for FX port
LED Indicators for simple Ethernet/Fiber network link monitoring
Forward 9K jumbo packets in converter mode
Specifications
Product Type
Transceiver/Media Converter
Manufacturer Part Number
MCM110SC2
Packaged Quantity
1 Each
Power Source
AC Adapter
Limited Warranty
2 Year
Weight (Approximate)
3 oz
Form Factor
External
Manufacturer
StarTech.com
Product Name
10/100 Fiber to Ethernet Media Converter Multi Mode SC 2 km
Network Technology
10Base-T, 100Base-FX, 100Base-TX
Power Consumption
2.40 W
Brand Name
StarTech.com
Plug/Connector Type
Type M
Country of Origin
Taiwan
Height
0.8"
Width
3"
Depth
3.7"
Environmentally Friendly
Yes
Environmental Certification
EU RoHS
Ethernet Technology
Fast Ethernet
Number of Network (RJ-45) Ports
1
Network (RJ-45)
Yes
Number of SC Ports
1
Media Type Supported
Optical Fiber, Twisted Pair
Fiber Mode Supported
Multi-mode
Total Number of Ports
2
SC Port Type
Duplex
TAA Compliant
Yes
Environmental Compliance
Restriction of Hazardous Substances (RoHS) 2, Registration, Evaluation, Authorization and Restriction of Chemicals (REACH), Waste Electrical and Electronic Equipment Directive (WEEE)
