Overview
Designed to enhance everyday productivity, the Lenovo ThinkPad® USB4 Dock 5000 is the Successor of our famous Universal USB-C Dock equipped with cutting edge USB4 Technology, The dock can connect to your laptop with 40Gbps bandwidth USB4 upstream connectivity, that allows you to extend your monitor setup with more pixels and higher refresh rates. It can output 65W charge power to your laptop with 100W power adapter, or you can choose a 135W power adapter to boost the charge power up to 100W to you laptop.
• The ThinkPad® USB4 Dock 5000 with the latest USB4 technology, makes the connectivity performance quadrupled compare to USB-C 3.2 Gen 2, with up to 40 Gbps bandwidth, you can have up to either one Ultra-High Resolution 8K 60Hz Displays or two 4K 144Hz High Refresh Rate monitor setup to fully extend your Lenovo laptop to a compute platform with all different kinds of Peripheral Devices. It supports PD 3.1 and output up to 100W to give a fast charge to your laptop, you can expand the potential of your workspace with ease
• It is also a Universal Compatible Dock a cross different Operating System
Warranty
Limited Warranty: 3 Year
About Lenovo
Join Lenovo Transformation is a Team Sport When you work at Lenovo, you make powerful things happen here — for you, for Lenovo, and for the world.
Highlights
Wired connectivity technology allows convenient and reliable connectivity for maximum efficiency
Charging capability provides a quicker, worry-free charging experience
USB4 host interface Offers a more refined structure and safer to use connectivity
Monitor device supported for better reliance and optimal performance
5 GB/s maximum data transfer rate for fast, dependable data transfer with added productivity
Power Delivery Pass-through feature for better reliance and usability
Gigabit Ethernet Ethernet technology for increasing efficiency with the quicker transfer and sharing of information
Power Adapter power source type for your docking station provides maximum energy feasibility and added surveillance productivity
Enjoy HD quality videos on your HDTV with the HDMI port facility
6 USB ports offers a more refined structure and safer to use connectivity
Specifications
General Information
Manufacturer
Lenovo Group Limited
Manufacturer Part Number
40BF0100US
Brand Name
Lenovo
Product Line
ThinkPad
Product Name
ThinkPad USB4 Dock 5000
Packaged Quantity
1
Product Type
Docking Station
Interfaces/Ports
Host Interface
USB4
Audio Line In
No
Audio Line Out
No
Total Number of USB Ports
6
Number of USB 3.2 Gen 2 Type-A Ports
4
Number of USB 3.2 Gen 2 Type-C Ports
2
Number of USB Type-C Ports
2
USB Type-A
Yes
USB Type-C
Yes
USB Type-C Detail
1 x USB-C 3.2 Gen 2, AOU 7.5W, 1 x USB-C 3.2 Gen 2 FullFunction 7.5W
Number of USB Type-A Ports
4
Network (RJ-45)
Yes
Number of DisplayPorts
2
DisplayPort
Yes
DisplayPort Version
1.4
Number of HDMI Ports
1
HDMI
Yes
USB Power Delivery
65W
Network & Communication
Ethernet Technology
Gigabit Ethernet
Physical Characteristics
Product Color
Eclipse Black
Height
1.24"
Width
3.15"
Weight (Approximate)
1.04 lb
Power Description
Maximum Power Supply Wattage
100 W
Software
Operating System Supported
Windows 11, macOS Sonoma, macOS Sequoia 15
Technical Information
Connectivity Technology
Wired
Charging Capability
Yes
Number of Displays Supported
4
Device Supported
Monitor, Notebook
Supported Resolutions
3840 x 2160, 7680 x 4320
Screen Mode Supported
4K @ 60Hz, 8K @ 60Hz, 4K @ 144Hz
Warranty
Limited Warranty
3 Year
Miscellaneous
Package Contents
ThinkPad USB4 Smart Dock with integrated 1m USB4 cable
1 x 100W Power Adapter
1 x Power Cord
1 x Setup Poster
1 x Warranty Poster
Compatibility
Lenovo Notebooks: ThinkPad T14 Gen 5 (Intel) ThinkPad T14 Gen 6 (AMD) ThinkPad T14s Gen 5 ThinkPad T14s Gen 6 (AMD) ThinkPad T16 Gen 3 ThinkPad T16 Gen 4 (AMD) ThinkPad X1 2-in-1 Gen 9 ThinkPad X1 Carbon Gen 12 ThinkPad X13 2-in-1 Gen 5 ThinkPad X13 Gen 5 ThinkPad X13 Gen 6 (AMD)
