Genuine Harman International Industries through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.
SKU
FG1015-100
Category
Video Processing/Capturing Modules
Overview
The AMX SCL-1 4K60 Scaler is a small-format scaler that adjusts the output to match the optimal resolution of the display. The scaler includes a single input and a single output, with a size small enough to be mounted behind a display. It was designed to be used in combination with products such as the local HDMI outputs on the AMX Precis 8x8 that do not have built-in scaling. This offers a more flexible, lower cost solution for installations where scaling is needed only on certain outputs.
The scaler is compatible with 4K60 4:4:4 resolutions and HDCP 2.2, offering support for the latest source devices and displays. Because the scaler includes automatic scaling, the device can be configured to automatically scale to the optimal resolution of the display based on its EDID. It can be set to always scale to a particular resolution.
Common Applications
Ideal for a variety of applications where there is no video scaling built into the switcher.
Features
• 4K60 4:4:4 and HDCP 2.2 Support - Both 4K60 and non-4K content is supported
• Single Input/Output - Can be used in combination with products such as presentation switchers which do not have resolution support to match displays.
• Automatic Scaling Option - Can be configured to automatically scale to the optimal resolution of the display based on its EDID, or it can be set to always scale to a particular resolution
Highlights
Converts video signals from a low resolution to a higher resolution (e.g., SD to HD)
To fulfill your needs, this video scaling function is a perfect choice
No hassle of internal installation, install externally
Specifications
General Information
Manufacturer
Harman International Industries, Inc
Manufacturer Part Number
FG1015-100
Brand Name
AMX
Product Model
SCL-1
Product Name
4K60 Scaler
Product Type
Video Scaler
Interfaces/Ports
USB
Yes
HDMI
Yes
Physical Characteristics
Form Factor
External
Height
1"
Width
4.3"
Depth
5.9"
Weight (Approximate)
1.10 lb
Technical Information
Functions
Video Scaling
Maximum Resolution
4096 x 2160
Miscellaneous
Package Contents
4K60 Scaler
1 x 3P-3.5MM Phoenix Connectors
1 x 12V/2A Power Adapter
1 x US Exchangeable Adapters
1 x EU Exchangeable Adapters
1 x UK Exchangeable Adapters
2 x Mounting Ear
4 x M2.5 Screw (For Mounting Ears)
Country of Origin
Mexico
Environmentally Friendly
Yes
Environmental Compliance
Restriction of Hazardous Substances (RoHS), Waste Electrical and Electronic Equipment Directive (WEEE)
