Amer MC-GT/SFP Transceiver/Media Converter
1 x Network (RJ-45) - Gigabit Ethernet - 10/100/1000Base-T, 1000Base-X - 1 x Expansion Slots - SFP - 1 x SFP Slots - AC Adapter - Standalone
- SKU
- MC-GT/SFP
- Category
- Transceivers/Media Converters
MSRP$52.00
$36.36
Save 30%Back ordered — ships when restocked.
Genuine Amer Networks through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.
- SKU
- MC-GT/SFP
- Category
- Transceivers/Media Converters
Overview
The MC-GT/SFP media converter is a highly flexible media conversion device that allows the support of different optics and copper SFP options providing a multitude of applications. The MC-ST/SFP is equipped with 1x Gigabit Ethernet 10/100/1000Base-T RJ-45 port and one SFP Port. With the SFP slot supporting Dual-Speed 100/1000Mbps the MC-GT/SFP may be used with any vendor's optics (SFP Transceiver) providing added compatibility and flexibility in your application.
The Ethernet RJ-45 port supports 10/100/1000Mbps Auto-Negotiation and Auto-MDI/MDIX function allowing for an easy and carefree connection to Ethernet devices. The MC-GT/SFP media convertor is designed as a compact, standalone, cost effective and high performance network solution.
Highlights
- Compliant with IEEE802.3, IEEE802.3u and IEEE802.3ab and IEEE 802.3z standard
- Full-duplex and half-duplex operation with IEEE802.3x flow control and back pressure
- SFP slot supports Dual-Speed (100/1000Mbps)
- SFP port supports Hot Swap
- Supports 9216 byte jumbo packet length forwarding at wire speed
- Standalone, Compact
Specifications
| Product Type | Transceiver/Media Converter |
|---|---|
| Manufacturer Part Number | MC-GT/SFP |
| Power Source | AC Adapter |
| Limited Warranty | 5 Year |
| Form Factor | Standalone |
| Manufacturer | Amer Networks, Inc |
| Product Model | MC-GT/SFP |
| Product Name | MC-GT/SFP Transceiver/Media Converter |
| Network Technology | 10/100/1000Base-T, 1000Base-X |
| Brand Name | Amer |
| Expansion Slot Type | SFP |
| Country of Origin | China |
| Height | 0.9" |
| Width | 3" |
| Depth | 4" |
| Environmentally Friendly | Yes |
| Ethernet Technology | Gigabit Ethernet |
| Number of Network (RJ-45) Ports | 1 |
| Network (RJ-45) | Yes |
| Number of SFP Slots | 1 |
| Media Type Supported | Twisted Pair, Optical Fiber |
| Total Number of Ports | 1 |
| Total Number of Expansion Slots | 1 |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
