Advantech IDS-3217EG-25SXA1E 17" Class LCD Touchscreen Monitor - 5 ms
Advantech

Advantech IDS-3217EG-25SXA1E 17" Class LCD Touchscreen Monitor - 5 ms

17" Viewable - 5-wire Resistive - 1280 x 1024 - SXGA - 16.2 Million Colors - 250 Nit - LED Backlight - DVI - USB - VGA - 2 Year

SKU
IDS-3217EG-25SXA1E
Category
Touchscreen Monitors

$401.60

Back ordered

Back ordered — ships when restocked.

Get a quote

Genuine Advantech through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.

SKU
IDS-3217EG-25SXA1E
Category
Touchscreen Monitors

Overview

The Advantech IDS-3217 Embedded Panel Mount Monitor series offers flexible options for LCD, touchscreen, signal interface and chassis mounting. The series with standard integrated frame design, supports rear and VESA mounting which brings the benefits of easy installation and provide flexibility for different applications.

Highlights

  • 17" SXGA LCD panel with LED backlight for 20% power saving and environmental protection
  • -20 ~ +60° C wide range operating temperature
  • 5-wire resistive touchscreen solution or 3mm tempered smudge resistant protected glass
  • Combo touch interface: RS-232 and USB
  • Dual signal interface with VGA & DVI (on selected models)
  • Standard integrated frame
  • Versatile mounting methods for front mounting and VESA mounting
  • Anti-Reflective treatment (optional)
  • Ultra high brightness solution of 1200 cd/m2 for outdoor applications (optional)

Specifications

Package Contents
  • 17" SXGA Industrial Panel Mount Monitor
  • 1 x M Cable USB-A(M)/USB-A(M) 180CM
  • 1 x VGA cable 15P(M) 1.8 meter
  • 8 x Clamper
  • 8 x Screw of clamper M4_25L
  • 1 x Cable clamp
  • 1 x Screw of cable clamp
  • 1 x Cable tie
Product TypeLCD Touchscreen Monitor
Manufacturer Part NumberIDS-3217EG-25SXA1E
Response Time5 ms
Limited Warranty2 Year
Touchscreen Type5-wire Resistive
Weight (Approximate)9.92 lb
Brightness250 Nit
Color Supported16.2 Million Colors
ManufacturerAdvantech Co., Ltd
Product ModelIDS-3217EG-25SXA1E
Product Name17" SXGA Industrial Panel Mount Monitor
Mount TypePanel Mount
Product SeriesIDS-3217
Viewable Screen Size17"
Maximum Resolution1280 x 1024
Brand NameAdvantech
Screen ModeSXGA
Country of OriginTaiwan
Height14.1"
Width16.7"
Depth1.5"
Environmentally FriendlyYes
USBYes
Backlight TechnologyLED
VESA Mount CompatibleYes
VESA Mount Standard100 x 100
Operating Power Consumption60 W
Native Contrast Ratio1,000:1
DVIYes
VGAYes
Number of USB Ports1
Screen Size Class17"
Environmental ComplianceRestriction of Hazardous Substances (RoHS)
