Advantech FPM-719-R9AE 19" Class LED Touchscreen Monitor
19" Viewable - 5-wire Resistive - 1280 x 1024 - SXGA - Thin Film Transistor (TFT) - 16.7 Million Colors - 350 Nit - LED Backlight - HDMI - USB - VGA - DisplayPort
SKU
Category
Touchscreen Monitors
$1,389.51
Back-ordered
Special order — estimated OEM lead time 3–8 weeks. Order today and we expect to receive stock between Oct 4 and Nov 8, then process your delivery right after.
Genuine Advantech through authorized distribution — NDAA §889 screened before checkout. TAA verified on request.
SKU
Category
Touchscreen Monitors
Country of origin
China
Country of origin is manufacturer-reported and can vary by production lot. Where TAA applies to your purchase, we verify the shipping unit's origin on request.
Overview
In IIoT and Industry 4.0, more and more customers need data to be visualized to help process management and decision making. The FPM-700 series comprises 15" , 17" and 19" industrial-grade monitors with sleek, simple lines and a true-flat touchscreen. Equipped with durable 5-wire resistive touchscreen and an IP66-rated front bezel, FPM-700 series is specifically designed for industrial applications. Moreover, FPM-700 series support a wide operating temperature range (-20 ~ 60 °C/-4 ~ 140 °F) and various mount options to make these monitors ideal for factory and machine automation display applications.
Highlights
19" SXGA TFT LED LCD with 70,000 backlight lifetime
Direct HDMI, DP and VGA input interfaces
Anti-glare screen with tempered glass
Robust system with Die-casting aluminum chassis and IP66-rated aluminum alloy front bezel
Lockable I/O connectors
Slim design enables easy installation
OSD control buttons with 2 user-defined contrast/brightness controls
Combo RS-232 & USB interface for touchscreen functionalit
Supports various mount options: panel, wall, desktop, rack or VESA arm mounting
Specifications
General Information
Manufacturer
Advantech Co., Ltd
Manufacturer Part Number
FPM-719-R9AE
Brand Name
Advantech
Product Series
FPM-700
Product Model
FPM-719-R9AE
Product Name
FPM-719-R9AE Touchscreen LED Monitor
Product Type
LED Touchscreen Monitor
Interfaces/Ports
HDMI
Yes
USB
Yes
VGA
Yes
DisplayPort
Yes
Physical Characteristics
VESA Mount Compatible
Yes
VESA Mount Standard
75 x 75
Height
15"
Width
17.9"
Depth
1.9"
Weight (Approximate)
13.67 lb
Power Description
Maximum Power Consumption
15.44 W
Technical Information
Screen Size Class
19"
Viewable Screen Size
19"
Screen Mode
SXGA
Panel Technology
Thin Film Transistor (TFT)
Horizontal Viewing Angle
170°
Vertical Viewing Angle
160°
Mount Type
Stand Mountable, Wall Mountable, Arm-mountable, Panel Mount, Desk Mountable, Rack-mountable
