Genuine Western Digital through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.
SKU
1ES1069
Category
Drive Cabinets
Overview
The 2U24 Flash Storage Platform is a key element of next generation Software-Defined Storage (SDS) systems. It offers performance advantages as well as flexibility to improve compute-to-capacity ratio by decoupling available storage from CPU resources.
Flash Performance
Depending on the type of SSDs and the number of drives installed, the 2U24 Platform can be configured to deliver the performance you need.
Designed for Enterprise and the Cloud
The 2U24 Flash Storage Platform addresses the demanding storage needs of large enterprises and Cloud service providers. With performance of up to 4.7M IOPS, 23 GB/s and less than 1ms latency, the Platform is the ideal solution for accelerating enterprise workloads such as Database, Virtualization and Scale-Out configurations. The flash platform delivers up to 184TB storage capacity, can be connected to up to six hosts via the 12Gb/s SAS3 interface, and offers enterprise-specific features including:
- Enterprise-class High Availability: hot swappable SSDs, IO Modules, and PSUs
- Fully upgradeable: upgradeable firmware enables drive technology and capacity updates without impacting applications
Warranty
Limited Warranty: 5 Year
Highlights
All-flash platform with up to 24 Ultrastar® 2.5" SAS SSD modules or 24 CloudSpeed Gen II SATA SSD modules
Available SSD capacities: 7.68TB, 3.84TB, 1.92TB, and 960GB
Start with as little as 12 SSDs, upgrade one additional module at a time
Up to 4.7M IOPS, 23 GB/s; <1ms latency
Up to six 12Gb/s SAS3 connections to host
2 rack units
Easy maintenance: SSD modules are front accessible and hot swappable
5-year limited warranty
Specifications
General Information
Manufacturer
Western Digital Corporation
Manufacturer Part Number
1ES1069
Brand Name
HGST
Product Model
2U24-1033
Product Name
2U24 Flash Storage Platform
Product Type
Drive Enclosure
Interfaces/Ports
Host Interface
12Gb/s SAS
Physical Characteristics
Cooling Fan
Yes
Form Factor
Rack-mountable
Rack Height
2U
Height
3.4"
Width
17.6"
Depth
21.1"
Weight (Approximate)
52.25 lb
Technical Information
Number of Solid State Drive Supported
24
Number of Solid State Drive Installed
24
Total Solid State Drive Capacity Installed
11.52 TB
I/O Expansions
Number of Total Expansion Bays
24
Number of 2.5" Bays
24
Warranty
Limited Warranty
5 Year
Miscellaneous
Environmentally Friendly
Yes
Environmental Compliance
Registration, Evaluation, Authorization and Restriction of Chemicals (REACH), Restriction of Hazardous Substances (RoHS) 2
