Genuine SMART Technologies through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.
SKU
QX286-V2-P
Category
Collaboration Displays
Overview
About SMART Technologies
We’ve been innovating and advancing technology focused on the connections that matter since we invented the original SMART Board
®
in 1987. We’re proud that our interactive displays and software solutions are trusted by teachers, students, and business leaders all around the world. We offer the best interaction and collaboration.
Specifications
Audio
Speakers
Yes
Number of Speakers
2
Microphone
Yes
Number of Microphone Array Elements
8
RMS Output Power
35 W
Display & Graphics
Viewable Screen Size
86"
Screen Size Class
86"
Display Screen Type
LCD
Backlight Technology
LED
Screen Mode
4K UHD
Screen Resolution
3840 x 2160
Scan Format
2160p
Aspect Ratio
16:9
Response Time
8 ms
Brightness
490 Nit
Horizontal Viewing Angle
178°
Vertical Viewing Angle
178°
Tempered Glass
Yes
Ambient Light Sensor
Yes
General Information
Manufacturer
SMART Technologies, Inc
Manufacturer Part Number
QX286-V2-P
Brand Name
SMART Board
Product Series
QX (V2) Pro
Product Model
QX086-V2 Pro
Product Name
QX086-V2 Pro Interactive Display with iQ
Product Type
Collaboration Display
Interfaces/Ports
HDMI
Yes
Total Number of USB Ports
13
USB
Yes
Network (RJ-45)
Yes
VGA
Yes
Serial
Yes
S/PDIF Out
Yes
Memory
Standard Memory
8 GB
Network & Communication
Ethernet
Yes
Wireless LAN
Yes
Bluetooth
Yes
Near Field Communication
Yes
Physical Characteristics
VESA Mount Compatible
Yes
VESA Mount Standard
800 x 600
Mount Surface
Wall
Height
47.9"
Width
78.5"
Depth
4.8"
Weight (Approximate)
154.32 lb
Processor & Chipset
Processor Core
Octa-core (8 Core)
Software
Operating System Platform
Android
Operating System
Android 13
Software Included
iQ embedded Android OS
SMART Meeting Pro
SMART Product Drivers and SMART Ink
SMART Remote Management
Touchscreen Information
Touchscreen
Yes
Multi-touch Screen
Yes
Number of Touch Points
50
Touchscreen Technology
HyPr Touch Technology
Power Description
Input Voltage
120 V AC, 230 V AC
Power Consumption
122 W
Storage
Flash Memory Capacity
64 GB
Miscellaneous
Package Contents
QX086-V2 Pro Interactive Display with iQ
1 x Power Cable
1 x 16' 5" (5 m) USB 2.0 A to B Cable
1 x 6' (1.8 m) USB4 Type-C cable, 100W
2 x Stylus with multi-color select and fine eraser
2 x Bar erasers
2 x External dual-band (2.4 and 5 GHz) antennas
1 x Remote control
2 x AAA batteries
1 x SMART Ultra HD Camera with mounting and cable accessories
1 x Illustrated installation instructions
1 x Important information document
Energy Star
Yes
Environmental Compliance
Registration, Evaluation, Authorization and Restriction of Chemicals (REACH), Restriction of Hazardous Substances (RoHS), Waste Electrical and Electronic Equipment Directive (WEEE)
