13.75 ft LCD - ARM Cortex A55 1.50 GHz - 4 GB - 1920 x 1080 - 16:9 - Direct View LED - 500 Nit - 1080p - Speakers - HDMI - USB - SerialEthernet - Android 13
Request pricing
Confirmed with stock and TAA status before any payment.
Genuine Sharp Electronics through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.
Sharp's new LD-AF Series of direct view LED displays offer a streamlined, user-friendly solution that differs from standard LED walls. Unlike traditional direct view LED displays, which often require additional components like external controllers or speakers, Sharp's LD-AF Series features built-in speakers, remote control functionality, and an intuitive interface for easy setup and operation. Designed for simplicity and convenience, these displays provide a unified user experience across Sharp's line of system-on-chip (SoC) displays, and a streamlined installation process. Available in 138" and 165" diagonal sizes, they deliver Full HD (1920x1080) imagery, making them perfect for environments like conference rooms and meeting spaces that need a high-quality, hassle-free display.
• Full HD (1920x1080) native resolution with a 165" class diagonal for crystal clear and immersive imagery
• Quick and easy installation process with a single power cable and a hassle-free installation process, the Sharp LD-AF Series can be implemented in as little as two hours
• Powerful System-on-Chip for versatile functionality powered by Android 13 with a high-end integrated media player, as well as support for third-party applications (APKs) as needed
• Integrated USB-C connection that not only allows for DP-Alt mode, but also upstream cababilities for controlling peripherals through the separate USB-A downstream connection
• NaViSet Administrator is Sharp's proprietary software solution that greatly eases administration and management of larger disply device installations. Control your entire Sharp display ecosystem through this optional software
• Fully compatible with Crestron Connected software as well as Crestron XiO Cloud Service
Limited Warranty: 2 Year
Powered by GfK Etilize ABOUT SHARP Sharp is dedicated to improving people's lives through the use of advanced technology and a commitment to innovation, quality, value, and design. We invite you to find out more about us, the value we place upon Corporate Social Responsibility, our on-going commitment to strong business ethics, and the numerous awards won by our innovative products. COMMITTED TO THE ENVIRONMENT At Sharp, we're very passionate about environmental conservation. Our environmentally friendly LCD television manufacturing facility in Kameyama, Japan, features one of the worlds largest roof-mounted solar systems. Our appliances and business products are among the industrys most energy efficient. Weve long been a world leader in solar cell production. Furthermore, all Sharp factories are working to eliminate waste and greenhouse gases, and achieve other environmental targets in 21 key areas. ENVIRONMENTAL POLICIES Sharp's dedication to environmental stewardship is a long standing corporate core value that's demonstrated in our products and our business activities, not a response to the latest trends. Sharp's business philosophy revolves around attaining mutual prosperity with stakeholders by contributing to the culture, benefits, and welfare of people throughout the world. To realize the business philosophy, all employees hold to and follow our business creed, which calls for "Sincerity and Creativity". We are proud of the many ways that Sharp is following its business philosophy and business creed of "Sincerity and Creativity" by working to fulfill the environmental and societal aspects of its corporate social responsibility. ENVIRONMENTAL PROGRAMS The industry leadership of Sharp extends to a number of partnerships and organizations that encourage our own company and others with strong environmental records to go above and beyond their legal environmental requirements.
| Audio | |
|---|---|
| Speakers | Yes |
| Display & Graphics | |
| Number of Screens | 1 |
| Viewable Screen Size | 13.75 ft |
| Screen Size Class | 13.75 ft |
| Display Screen Type | LCD |
| Display Resolution | 1920 x 1080 |
| Module Resolution | 320 x 180 |
| Orientation | Landscape |
| Backlight Technology | Direct View LED |
| Aspect Ratio | 16:9 |
| Maximum LED Life | 11.4 Year |
| Environmental Conditions | |
| Minimum Operating Temperature | 32°F (0°C) |
| Maximum Operating Temperature | 104°F (40°C) |
| Minimum Storage Temperature | -4°F (-20°C) |
| Maximum Storage Temperature | 140°F (60°C) |
| Minimum Operating Humidity | 10% |
| Maximum Operating Humidity | 80% |
| Minimum Storage Humidity | 10% |
| Maximum Storage Humidity | 80% |
| General Information | |
| Manufacturer | Sharp Electronics |
| Manufacturer Part Number | LD-A1651F |
| Brand Name | Sharp |
| Product Series | LD-AF |
| Product Model | LD-A1651F |
| Product Name | 165" LD-AF Series All-in-one FHD LED |
| Product Type | Digital Signage Display |
| Interfaces/Ports | |
| USB | Yes |
| HDMI | Yes |
| Serial | Yes |
| Number of USB 2.0 Ports | 1 |
| Number of USB 3.0 Ports | 2 |
| Number of HDMI Inputs | 3 |
| RS-232C Input | Yes |
| Number of HDMI 2.0 Ports | 3 |
| Memory | |
| Standard Memory | 4 GB |
| Network & Communication | |
| Ethernet | Yes |
| Physical Characteristics | |
| Mount Type | Wall Mountable |
| Height | 85.7" |
| Width | 12.1 ft |
| Depth | 3" |
| Weight (Approximate) | 459 lb |
| Processor & Chipset | |
| Processor Manufacturer | ARM |
| Processor Type | Cortex A55 |
| Processor Speed | 1.50 GHz |
| Processor Core | Quad-core (4 Core) |
| Software | |
| Operating System | Android 13 |
| Technical Information | |
| Ingress Protection (IP) Rating | IP20 |
| Video | |
| Scan Format | 1080p |
| Dynamic Contrast Ratio | 6,500:1 |
| Brightness | 500 Nit |
| Warranty | |
| Limited Warranty | 2 Year |
| Miscellaneous | |
| Package Contents |
|
| Application/Usage | Conference Room, Meeting Room |
| Indoor/Outdoor | Indoor |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
