Genuine PNY Technologies through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.
SKU
VCG508016TFXPB1-O
Category
Graphic Cards
Overview
GAME CHANGER
Gear up for game-changing experiences with the NVIDIA GeForce RTX 5080 and AI-powered DLSS 4. Built with NVIDIA® Blackwell and equipped with blistering-fast GDDR7 memory, it lets you run the most graphically demanding games and creative applications with stunning fidelity and performance. With NVIDIA Studio you can bring your creative projects to life faster than ever.
NVIDIA Blackwell Architecture
The Ultimate Platform for Gamers and Creators
Fifth-Gen Tensor Cores
Max AI performance with FP4 and DLSS 4
Fourth-Gen Ray Tracing Cores
Built for Mega Geometry
SOLID PHYSICAL CONNECTION
The top two screws shown in the picture above are physically mounted to the cooler, providing a solid physical connection between the mounting bracket and the cooling solution.
EXCELLENT PERFORMANCE
Excellent thermal performance keeping the GPU temperature lower during operating, and super quiet.
TRIPLE FAN COOLING
With three fans working together, heat is distributed and dissipated more efficiently across the GPU surface
Warranty
Limited Warranty: 3 Year
About PNY Technologies
Our Solutions
PNY offers solutions for a wide variety of Consumer, Commercial and OEM customers worldwide.
Highlights
NVIDIA DLSS 4
NVIDIA Reflex 2
GDDR7 Graphics Memory
NVIDIA® App
PCI Express® Gen 5
NVIDIA Broadcast
Specifications
General Information
Manufacturer
PNY Technologies
Manufacturer Part Number
VCG508016TFXPB1-O
Brand Name
PNY
Product Name
GeForce RTX 5080 Overclocked Triple Fan GPU Graphic Card
Product Type
Graphic Card
Interfaces/Ports
Host Interface
PCI Express 5.0 x16
DisplayPort
Yes
Number of DisplayPort Outputs
3
HDMI
Yes
Number of HDMI Outputs
1
Memory
Standard Memory
16 GB
Memory Technology
GDDR7
Bus Width
256 bit
Maximum Memory Bandwidth
960 GB/s
Physical Characteristics
Slot Space Required
Triple
Form Factor
Plug-in Card
Card Height
Full-height
Cooler Type
Fan Cooler
Height
2.4"
Width
5.4"
Length
12.9"
Processor & Chipset
Chipset Manufacturer
NVIDIA
Chipset Line
GeForce
Chipset Series
RTX
Chipset Model
RTX 5080
GPU Clock
2.30 GHz
GPU Boost Clock
2.73 GHz
Technical Information
Number of Monitors Supported
4
Maximum Digital Display Resolution
7680 x 4320
CUDA Cores
10752
Features
Triple-fan Cooler
AI-powered
Yes
Warranty
Limited Warranty
3 Year
Power Description
Power Supply Wattage
850 W
Power Connector
1x 16-pin, 3x 8-pin
Miscellaneous
Package Contents
GeForce RTX 5080 Overclocked Triple Fan GPU Graphic Card
