Genuine Perle Systems through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.
SKU
05061480
Category
Transceivers/Media Converters
Overview
Installed in a high density Perle Media Converter Chassis, Perle's feature rich C-1000MM Gigabit Fiber to Fiber Media Converter Modules enable transparent fiber extension of 1000Base-SX multimode fiber to 1000Base-SX multimode or 1000Base-LX/EX/ZX/BX single mode fiber.
Perle's advanced features make the end to end fiber link completely transparent. This allows for more efficient troubleshooting and less on-site maintenance. In addition, a lifetime warranty and free worldwide technical support make Perle's C-1000MM Gigabit Fiber to Fiber Media Converter Modules the smart choice for IT professionals.
Warranty
Limited Warranty: Lifetime
Highlights
Supports optical fiber cable to span longer distances and provides data transmission rates par excellence between networks and different devices
Attach multiple devices together or expand the number of devices connected to your existing network by using 2 transceiver/media converter
With 1000Base-SX technology get up to 1000Mbps data transfer rate over optical fiber cable
The Internal provides convenient installation
Specifications
General Information
Manufacturer
Perle Systems, Inc
Manufacturer Part Number
05061480
Brand Name
Perle
Product Model
C-1000MM-M2LC2
Product Name
C-1000MM-M2LC2 - Gigabit Ethernet Fiber to Fiber Media Converter Module
Product Type
Transceiver/Media Converter
Interfaces/Ports
Total Number of Ports
2
DVI
No
USB
No
Management Port
No
Number of LC Ports
2
LC Port Type
Duplex
Media & Performance
Media Type Supported
Optical Fiber
Fiber Mode Supported
Multi-mode
Maximum Distance Supported
2 km
Fiber Optic Cable Core/Cladding Specification
62.5/125 µm, 50/125 µm
Network & Communication
Network Technology
1000Base-SX, 1000Base-LX
Physical Characteristics
Form Factor
Internal
Weight (Approximate)
5.28 oz
Warranty
Limited Warranty
Lifetime
Miscellaneous
Environmentally Friendly
Yes
Environmental Compliance
Registration, Evaluation, Authorization and Restriction of Chemicals (REACH), Restriction of Hazardous Substances (RoHS), Waste Electrical and Electronic Equipment Directive (WEEE)
