Genuine Lantronix through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.
SKU
SPS-2460-SA
Category
Power Supplies
Overview
Multiple form factors allow flexibility to meet your application. The stand-alone form factor can be used with all Lantronix' stand-alone media converters. The piggy back form factor allows the power supply to attach directly to the converter and eliminate the power cable commonly found between the power supply and the converter. Once the piggy back supply is attached to the converter, the combined assembly is much easier to wall mount or attach to DIN Rail environments than using a separate supply. NDAA Compliant, TAA Compliant
Warranty
Limited Warranty: Lifetime
Highlights
Lantronix' wide input external power supplies allow you to provide a wide range of input voltages to power your stand-alone converters and chassis. Input voltages of 24 - 60 VDC and 24 - 42 VRMS allow for installation of any of Lantronix' stand-alone media converters in most industrial, telecom and commercial applications, as well as HVAC and building controlled environments.
Specifications
Environmental Conditions
Minimum Operating Temperature
-4°F (-20°C)
Maximum Operating Temperature
149°F (65°C)
General Information
Manufacturer
Lantronix, Inc
Manufacturer Part Number
SPS-2460-SA
Brand Name
Transition Networks
Product Model
SPS-2460-SA
Product Name
SPS-2460-SA Proprietary Power Supply
Product Type
Proprietary Power Supply
Physical Characteristics
Form Factor
Standalone
Height
1"
Width
3.8"
Depth
3.1"
Weight (Approximate)
1 lb
Power Description
Output Voltage
12.25 V DC
Output Current
1 A
Output Power
12 W
Reliability
MTBF
250000 Hour
Technical Information
Efficiency
80%
Protection Type
Over Loading, Transient, No Load
Warranty
Limited Warranty
Lifetime
Miscellaneous
Compatibility
Transition Networks Stand-alone Media Converters
Country of Origin
United States
Environmentally Friendly
Yes
Environmental Compliance
Waste Electrical and Electronic Equipment Directive (WEEE)
